Side 1/16
GE Consumer & Industrial
Appliances
I
n
s
t
a
l
l
a
i
o
n
I
n
s
t
r
u
c
t
i
o
n
s
Bu
ilt-In Dishwasher
I
f you have questions, call 800.GE.CARES (800.432.27
37) or visit our website at
: www.ge.com
IMPORTANT
– The dishwasher MUST be installed
to allow for future removal from the enclosure if service is
required.
f you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner’s Manual for available
custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS shown
throughout these instructions. While performing
installations described in this booklet, gloves, safety glasses
or goggles should be worn.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
IMPORTANT
– Observe all governing codes and
ordinances.
•
Note to Installer
– Be sure to leave these instructions for the
consumer’s and local inspector’s use.
•
Note to Consumer
– Keep these instructions with your
Owner’s Manual for future reference.
•
Skill Level
– Installation of this dishwasher requires
basic mechanical, electrical and plumbing skills.
Proper
installation is the responsibility of the installer. Product
failure due to improper installation is not covered under
the GE Appliance Warranty. See warranty information.
•
Completion Time – 1 to 3 Hours
. New installations require
more time than replacement installations.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
TOOLS YOU WILL NEED:
®
Phillips head screwdriver
®
1/4" and 5/16" nutdriver
®
6" Adjustable wrench
®
Level
®
Carpenters square
®
Measuring tape
®
Safety glasses
®
Flashlight
®
Bucket to catch water when fl ushing the line
®
15/16" socket (optional for skid removal)
®
Gloves
For New Installations Only:
®
Tubing cutter
®
Drill and appropriate bits
®
Hole saw set
90° Elbow,
Ferrule and
Compression Nut
Wire Nuts (3)
Waste Tee
Electrical Cable
(or Power Cord, if applicable)
Hot Water Line
Hand
Shut-Off
Valve
Side and Top Trim Pieces on some models
Hole Saw Set
Level
Thread
Seal Tape
Air Gap
Strain Relief
Drain Hose
Hose Clamp
1/4" and 5/16"
Nutdriver
15/16" Socket
Bucket
Tubing Cutter
Drill and Bits
Flashlight
Gloves
Phillips
Head
Screwdriver
Carpenters
Square
6"
Adjustable
Wrench
Safety Glasses
Installation Preparation
2
Drain Hose Hanger
Measuring Tape
PARTS SUPPLIED
IN INSTALLATION PACKAGE:
Two #8-18 x 5/8" Phillips special head screws, to
secure dishwasher to underside of countertop.
Junction box cover and #10 hex head screw
Hose Clamp
Drain hose (approximately 78" long)
Drain hose hanger
Side and top trim pieces (some models)
Literature, samples and/or coupons
MATERIALS YOU WILL NEED:
Ferrule, compression nut and 90° Elbow (3/8"NPT
external thread on one end, opposite end sized
to fit water supply)
Thread seal tape
UL Listed wire nuts (3)
GPF65 side mount kit if countertop is
granite or similar material
Materials Needed for
New Installations:
Air gap for drain hose, if required
Waste tee for house plumbing, if applicable
Electrical cable or power cord
Screw type hose clamp
Strain relief for electrical connection
Hand shut-off valve (recommended)
Water line–3/8" minimum copper tubing
GPF10L drain hose
(10' long
)
, if needed
Junction
Box Cover
GPF65
Side-Mount
Bracket Kit
#8 Phillips
Special
Head Screws
5/8" long
Screw Kit
#10
Hex- Head
J-Box Screw
1/2" long
Optional
10' Drain Hose
GPF10L
Hose Clamp
