BEFORE YOU BEGIN

Read these instructions completely and

carefully.

Installation Instructions

Built-In Dishwasher

If you have questions, call 800.GE.CARES (800.432.2737) or visit our website at: GEAppliances.com

IMPORTANT – The dishwasher MUST be

installed to allow for future removal from the

enclosure if service is required.

If you received a damaged dishwasher, you should

immediately contact your dealer or builder.

Optional Accessories – See the Owner’s Manual for

available custom panel kits.

FOR YOUR SAFETY

Read and observe all CAUTIONS and WARNINGS

shown throughout these instructions. While

performing installations described in this booklet,

gloves and safety glasses should be worn.

READ CAREFULLY.

KEEP THESE INSTRUCTIONS.

IMPORTANT – Observe all governing codes

and ordinances.

• Note to Installer – Be sure to leave these

instructions for the consumer and local inspector’s

use.

• Note to Consumer – Keep these instructions with

your Owner’s Manual for future reference.

• Skill Level – Installation of this dishwasher requires

basic mechanical, electrical and plumbing skills.

Proper installation is the responsibility of

the installer. Product failure due to improper

installation is not covered under the GE

Appliance Warranty. See warranty information.

• Completion Time – 1 to 3 Hours. New installations

require more time than replacement installations.

31-31547-1 02-15 GE

In Canada, call 1.800.561.3344 or visit www.GEAppliances.ca

GE Appliances

TOOLS YOU WILL NEED:

• Safety glasses

• 1/4" and 5/16" nutdrivers

• Flashlight

• Gloves

• Adjustable wrench (6”)

• Phillips-head screwdriver

• Measuring tape

• Level

• Carpenter’s square

• Bucket to catch water when flushing water

line

• Tubing cutter

• 15/16" socket wrench

FOR NEW INSTALLATIONS:

• Hole saw set

• Drill and appropriate bits

PARTS SUPPLIED IN INSTALLATION

PACKAGE:

• Two 8-18 x 5/8" Phillips-head wood screws

• Junction box cover and #10 hex head screw

• Drain hose (78" long) and hose clamp

• Cord protector (Power Cord Models Only)

• Conversion leads (Power Cord Models Only)

• Literature, product samples and/or coupons

MATERIALS YOU WILL NEED:

• WX09X70910 or WX09X70911 power cord

if applicable to your installation

• UL-Listed wire nuts (3)

• Thread seal tape

• Depending on model, 90° elbow (¾” hose

internal thread on one end, opposite end

sized to fit water supply) -OR- ferrule,

compression nut and 90° elbow (3/8” NPT

external thread)

• GPF65 Side-mount bracket kit for use with

granite countertops

FOR NEW INSTALLATIONS:

• Electrical cable

• Water line–3/8" minimum copper tubing

(including ferrule and compression nut)

• Strain relief for electrical connection

• Hand shut-off valve (recommended)

• Air gap for drain hose, if required

• Waste tee for house plumbing, if applicable

• GPF10S drain hose (10' long), if needed

• Screw-type hose clamps

Hose Clamp

78" Drain Hose

Thread

Seal Tape

3 Wire Nuts Hot Water Line–3/8"

Minimum Copper

Tubing

Electrical Cable

or WR09X70910

or WX09X70911

Power Cord

Air

Gap

Screw-Type

Hose Clamps

Strain Relief

Phillips-Head

Screwdriver

Level Carpenter’s

Square

Measuring Tape

Safety Glasses Flashlight

Gloves

Hole Saw Set

Drill and

Bits

6KXW2ȹ

Valve

1/4" and 5/16" Nutdrivers

Adjustable

Wrench

Tubing

Cutter

GPF65 Side-Mount

Bracket Kit

Phillips-Head

Wood Screws

5/8" long

Screw Kit

#10

Hex Head

Junction Box Screw

1/2" long Junction Box Cover

Cord Protector

(Power Cord Models Only)

Conversion Leads

(Power Cord Models Only)

15/16"

Socket Wrench

Bucket

Optional 10'

Drain Hose

GPF10S

Waste Tee

Coupler for

optional drain

hose

90° Elbow or Ferrule

and Compression Nut

(depending on model)
