31-6000222 Rev. 0 05-19 GEA
1
COMBINED NON-RETURN/SAFETY VALVE
This valve is a pressure release mechanism used in pressure systems. It has a non-return valve integrated. The
use of these valves is strictly required due to safety regulations. The safety valve opens at a pressure of 72 psi to
reduce excess pressure.
WARNING BURN HAZARD
Do NOT touch hot water outlet pipes. Failure to do so can result in severe burns.
2
VENTILATION VALVE
This valve ensures that no vacuum is created when draining the water tank.
In the event of negative pressure, the ventilation valve automatically supplies the system with air.
This ventilation valve must comply with ANSI Z21.22
WARNING BURN HAZARD
Do NOT touch hot water outlet pipes. Failure to do so can result in severe burns.
4
COLD WATER SUPPLY ISOLATION VALVE
This valve should stay open to allow water from the public water system to fill the GeoSpring Solar System
water tank. When this valve is closed, the GeoSpring Solar System and the supplemental water heater are
disconnected from the pressurized mains of the public water system.
5
HOT WATER SUPPLY ISOLATION VALVE
Keep this valve open to assure that hot water can drain or escape in case of overheating. This valve can
temporarily be closed for maintenance purposes.
6
DRAIN VALVE
These water heater drains are normally closed and capped. Use these valves to drain the GeoSpring Solar
System. Attach a garden hose to both drain valves. Terminate the hoses in either a service basin or an
appropriate spot outside the house. Open both water heater drains at once to drain the unit.
WARNING
SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
6
DRAIN VALVE
These water heater drains are normally closed and capped. Use these valves to drain the GeoSpring Solar
System. Attach a garden hose to both drain valves. Terminate the hoses in either a service basin or an
appropriate spot outside the house. Open both water heater drains at once to drain the unit.
WARNING SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
7
THERMOSTATIC MIXING VALVE
This valve controls the temperature of the warm water output. According to local standards, the valve must have
a scald safe function. Scald safe means that in the case of a cold water failure, the hot water supply shuts off
automatically.
An ASSE 1017 rated mixing valve to avoid severe burns or death from scalding temperatures IS REQUIRED PER
SRCC OG-300.
8
PRESSURE REDUCING VALVE
This valve should ensure a constant output pressure of 60 psi independent of the input pressure delivered from
any source.
9
3 WAY BALL VALVE
This valve provides solar system cold water shut off without interrupting normal cold water service.
31-6000222 Rev. 0 03-19 GEA
Freeze Protection:
32ºF for 8 consecutive hours
When these environmental conditions are lower than the stated value, the GeoSpring Solar System must be
manually drained in accordance with the Care and Cleaning instructions.
Drain Procedure:
VALVE 4 COLD WATER SUPPLY ISOLATION VALVE
VALVE 6 DRAIN VALVE
Valve 4 is normally open and allows cold water to fill the GeoSpring Solar System. When the valve is closed, the
GeoSpring Solar System is isolated from the pressurized cold water supply line piping. To drain the system, open
valve 6.
WARNING SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
No other fluid shall be used that would change the original classification of this system.
Unauthorized alterations to this system could result in a hazardous health condition.
WARNING SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
No other fluid shall be used that would change the original classification of this system.
Unauthorized alterations to this system could result in a hazardous health condition.
WARNING SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
No other fluid shall be used that would change the original classification of this system.
Unauthorized alterations to this system could result in a hazardous health condition.
WARNING SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
No other fluid shall be used that would change the original classification of this system.
Unauthorized alterations to this system could result in a hazardous health condition.
WARNING SCALD RISK
WATER MAY BE DISCHARGED AT VERY HIGH TEMPERATURES. TO AVOID SCALDING, EXERCISE
MAXIMUM CAUTION WHEN DRAINING THE HOT WATER FROM THE GEOSPRING SOLAR SYSTEM. DO
NOT POINT HOSE AT PERSONS OR PETS. ALWAYS DISCHARGE THE HOT WATER TO A SAFE PLACE.
Printed in Austria
