GE Consumer & Industrial
Appliances
Installation Instructions
Built-In Dishwasher
If you have questions, call 800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.com.
In Canada, please call 1.800.561.3344 or visit www.geappliances.ca
IMPORTANT – The dishwasher MUST be installed
to allow for future removal from the enclosure if service is
required.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner’s Manual for available
custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS shown
throughout these instructions. While performing
installations described in this booklet, gloves, safety glasses
or goggles should be worn.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
IMPORTANT – Observe all governing codes and
ordinances.
• Note to Installer – Be sure to leave these instructions for the
consumer’s and local inspector’s use.
• Note to Consumer – Keep these instructions with your
Owner’s Manual for future reference.
• – Installation of this dishwasher requires Skill Level
basic mechanical, electrical and plumbing skills. Proper
installation is the responsibility of the installer. Product
failure due to improper installation is not covered under
the GE Appliance Warranty. See warranty information.
• . New installations require Completion Time – 1 to 3 Hours
more time than replacement installations.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
206C1559P197 31-30258 07-09 JR
TOOLS YOU WILL NEED:
Phillips-head screwdriver
1/4" and 5/16" nutdriver
6" Adjustable wrench
Level
Carpenter's square
Measuring tape
Safety glasses
Flashlight
Bucket to catch water when fl ushing the line
15/16" socket (optional for skid removal)
Gloves
For New Installations Only:
Tubing cutter
Drill and appropriate bits
Hole saw set
90° Elbow,
Ferrule and
Compression Nut
Hot Water Line
Hand
Shut-Off
Valve
Side and Top Trim Pieces on some models
Hole Saw Set
Level
Thread
Seal Tape
Air Gap
Strain Relief
Drain Hose Hose Clamp
1/4" and 5/16"
Nutdriver
15/16" Socket
Bucket
Tubing Cutter
Drill and Bits
Flashlight
Gloves
Phillips-Head
Screwdriver Carpenter's
Square
6"
Adjustable
Wrench
Safety Glasses
Installation Preparation
2
Measuring Tape
PARTS SUPPLIED
IN INSTALLATION PACKAGE:
Two #8-18 x 5/8" Phillips special head screws, to
secure dishwasher to underside of countertop
Junction box cover and #10 hex-head screw
Hose clamp
Drain hose (approximately 78" long)
Zip ties
Side and top trim pieces (some models)
Literature, samples and/or coupons
2 Side-mounting brackets with four #8 pan-head
mounting screws for non-wood countertops
(some models)
MATERIALS YOU WILL NEED:
Ferrule, compression nut and 90° elbow (3/8"NPT
external thread on one end, opposite end sized
to fit water supply)
Thread seal tape
UL-listed wire nuts (3)
GPF65 side-mount kit if countertop is
granite or similar material
Materials Needed for
New Installations:
Air gap for drain hose, if required
Waste tee for house plumbing, if applicable
Electrical cable or power cord
Screw-type hose clamps
Strain relief for electrical connection
Hand shut-off valve (recommended)
Water line–3/8" minimum copper tubing
GPF10L drain hose (10' long), if needed
Junction Box Cover
GPF65
Side-Mount
Bracket Kit
#8 Phillips
Special
Head Screws
5/8" long
Screw Kit
#10
Hex-Head
J-Box Screw
1/2" long
Optional
10' Drain Hose
GPF10L
Zip Ties
Hose Clamps
#8 Phillips
Pan-head Screws
3/8" long for
side-mounting
Side-
Mounting
Brackets
Side Mount Kit
(some models)
Waste Tee Electrical Cable
(or Power Cord, if applicable)
Wire Nuts (3)
