Side 1/32
GE Consumer & Industrial
Appliances
Installation Instructions
Built-In Dishwasher
If you have questions, call 800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.com
In Canada call 1.800.561.3344 or www.GEAppliances.ca
imagination at work
IMPORTANT – The dishwasher MUST
be installed to allow for future removal from the enclosure
if service is required.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories – See the Owner’s Manual for available
custom panel kits.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS
shown throughout these instructions. While performing
installations described in this booklet, gloves and either
safety glasses or goggles should be worn.
ANTI
BACTERIA
ST AR T
RESET
TO LOCK CONTRO LS
PRESS HEATED
DRY
FOR 3 S E
CONDS
ENHANCEMENTS
SELECTIONS
SEN SIN
GWAS HIN
GRINS IN
GDRY IN
GSAN IT
IZE DCLEAN
COOK
WARE
NORMAL
WASH
SP EED
CYCLE
CHINA
CRYS TAL
RINSE
ONLY 2 4 8
DELAY
HOURS
ADDED
HEAT
PRE
WASH
HEATED
DRY
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
Stainless Steel Tub Models
IMPORTANT – Observe all governing codes and
ordinances.
• Note to Installer – Be sure to leave these instructions for the
consumer’s and local inspector’s use.
• Note to Consumer – Keep these instructions with your
Owner’s Manual for future reference.
• – Installation of this dishwasher requires Skill Level
basic mechanical, electrical and plumbing skills. Proper
installation is the responsibility of the installer. Product
failure due to improper installation is not covered under
the GE Appliance Warranty. See warranty information.
• . New installations require Completion Time – 1 to 3 Hours
more time than replacement installations.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
STOP
PARTS SUPPLIED WITH
INSTALLATION KIT:
Two #8-18 x 5/8" Phillips special head screws, to
secure dishwasher to underside of countertop or
sides of cabinets.
Junction box cover and #10-1/2" hex-head screw
Side and top trim
Trim Panel Accessory Kit (not shown)
(Custom panel models only)
Sound upgrade kit (some models)
Drain hose (78") , drain hose hanger and hose
clamp
Literature, product samples and/or coupons
Hard water test strip (Models with Bulk Dispenser)
Installation Preparation
TOOLS YOU WILL NEED:
Phillips-head screwdriver
1/4" and 5/16" nutdriver
6" Adjustable wrench
Level
Carpenter’s square
Measuring tape
Safety glasses
Flashlight
Bucket to catch water when flushing the line
15/16" socket
Gloves
For New Installations Only:
Tubing cutter
Drill and appropriate bits
Hole saw set
MATERIALS YOU WILL NEED:
Ferrule, compression nut and 90° Elbow (3/8" NPT
external thread on one end, opposite end sized to
fit water supply)
Thread seal tape
UL-listed wire nuts (3)
Materials For New Installations Only:
Air gap for drain hose, if required
Waste tee for house plumbing, if applicable
Electrical cable or power cord, if applicable
Screw-type hose clamps
Strain relief for electrical connection
Hand shut-off valve
Water line 3/8" min. copper
Coupler for extending drain line, if applicable
GPF10L 10' drain hose, if needed
#8 Phillips
Special Head Screws
5/8” long
Hose Clamp
Drain Hose (78")
Trim Pieces
Hand
Shut-Off
Valve
90° Elbow,
Ferrule and
Compression Nut
Thread
Seal Tape
Wire Nuts (3)
Hot Water Line
Electrical Cable
(or Power Cord, if applicable)
Waste Tee
Coupler
Air
Gap
Screw-Type
Hose Clamps
Strain Relief
Phillips-
Head
Screwdriver
1/4" and
5/16" Nutdriver
Level
Carpenter’s
Square
1/4" and
15/16" Socket
6" Adjustable
Wrench
Tubing Cutter
Measuring Tape
Safety GlassesFlashlight
Gloves Bucket Hole Saw Set Drill and Bits
2
Drain Hose Hanger
#10 Hex-Head
J-Box Screw
1/2" long
Sound Upgrade Kit
(Some Models)
GPF10L
10' Drain Hose
Junction
Box Cover
Screw Kit
Hard Water Test Strip
(Models with
Bulk Dispenser)
Side Trim
Top Trim
Side Trim
