Side 1/14

BIOS Setup Manual

BIOS Setup

BIOS (Basic Input and Output System) is a UEFI interface that allows you to setup and configure your system for optimum use.

Using your mouse and keyboard, users can change BIOS settings, monitor CPU temperature, select the boot device priority and

view system information such as the CPU name, DRAM capacity, and the BIOS version.

To access the BIOS setup program, press the <Delete> key during the POST (Power-On Self-Test) when the power is turned on.

BIOS Setup Program Function Keys

< >< > ↑ ↓ Move the selection bar to select an item

< >< > ← → Move the selection bar to select the screen

<Enter> or <Double Click> Execute command or enter the submenu

<Esc> or <Right Click> Main Menu: Exit the BIOS Setup program

Submenus: Exit current submenu

<+> Increase the numeric value or make changes

<-> Decrease the numeric value or make changes

<F1> General Help

<F2> Restore the previous BIOS settings for the current submenus

<F3> Load the Optimized BIOS default settings for the current submenu

<F4> Save all the changes and exit the BIOS Setup program

Main

This setup page includes all the items in standard compatible BIOS

Advanced

This setup page includes all the items of BRIX enhanced features.

Chipset

Platform Controller Hub additional features configuration.

Security

Change, set or disable supervisor and user password. Configuration supervisor password allows you to restrict access to the

system and BIOS Setup.

A supervisor password allows you to make changes in BIOS Setup.

A user password only allows you to view the BIOS settings but not to make changes.

Boot

This setup page provides items for configuration of boot sequence.

Save & Exit

Save all the changes made in the BIOS Setup program to and exit. (Pressing can also carry out this task.)<F10>

Abandon all changes and the previous settings remain in effect. Pressing to the confirmation message will exit BIOS Setup. <Y>

(Pressing can also carry out this task.) <Esc>

Produkt Specifikationer

Mærke:	Gigabyte
Kategori:	Skrivebord
Model:	GB-BXCEH-2955
Produktfarve:	Sort
Produkttype:	Mini PC barebone
Wi-Fi:	Ja
Bluetooth:	Ja
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	4
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Processorkerner:	2
Panel montering grænseflade:	75 x 75, 100 x 100 mm
Dimensioner (BxDxH):	42.8 x 107.6 x 114.4 mm
Operativsystem installeret:	Ingen
Bluetooth-version:	4.0
Effektkrav:	100 - 240V AC
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	1.4 GHz
Processorserie:	Intel® Celeron®
Processortråde:	2
Maksimal intern hukommelse:	16 GB
On-board grafikkort, model:	Intel® HD Graphics
On-board grafikkort:	Ja
S/PDIF-udgang:	Ja
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ingen
Intel® Turbo Boost Teknologi:	Ingen
Lydsystem:	Realtek ALC269
Processorproducent:	Intel
Processormodel:	2955U
Antal produkter inkluderet:	1 stk
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	1
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ingen
Intel® Virtualization Technology (VT-x):	Ja
Indbygget processer:	Ja
Grænseflade til lagerdisk:	Serial ATA III
Antal understøttede lagerdiske:	1
Antal installerede processorer:	1
Kabinettype:	Net-top
Intel® Trusted Execution Teknologi:	Ingen
Intel® TSX-NI:	Ingen
Intel® Stabil Billede Platformsprogram (SIPP):	Ingen
Intel® klar video teknologi:	Ja
Strømforsyning:	65 W
Processor sokkel:	BGA 1168
Processor litografi:	22 nm
Thermal Design Power (TDP):	15 W
PCI Express slots version:	2.0
PCI Express-konfigurationer:	1x2, 1x4, 4x1
Processor kodenavn:	Haswell
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ja
Intel® Insider™:	Ingen
Intel® Sikker Nøgle:	Ja
Intel® Smart Connect Teknologi:	Ja
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Smart Response Teknologi:	Ingen
Intel® Identity Protection Teknologi (Intel® IPT):	Ingen
Intel® Mindre Forretnings-fordele (Intel® SBA):	Ingen
Intel® Matrix Storage Teknologi (Intel® MST):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ingen
Intel® OS Guard:	Ingen
Termiske overvågningsteknologier:	Ja
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ja
Intel® Smart Cache:	Ja
Kompatibel processor serie:	Intel® Celeron®
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	2
Hukommelses slots type:	SO-DIMM
Understøttede hukommelsesclock-hastigheder:	1333,1600 Mhz
LAN Kontroller:	Realtek RTL8111G
Intel HD Audio Teknologi:	Ja
Antal understøttede processorer:	1
Grafikadapter familie:	Intel
Understøttede lagerdisk størrelser:	2.5 "
Antal mini DisplayPorts:	1
Antal strømforsyninger:	1
Intel® ME Firmware Version:	9.5
Understøttet processorfrekvens (maks.):	1.4 GHz
Mini PCI ekspres slots:	1
