Assembly Instructions: (Bijoux)1998-5/5SF

IMPORTANT:

• ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

• SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

• USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes

above. Remove the old xture from the ceiling, including the old

mounting strap.

1. Take the mounting strap assembly from the parts bag. One end of

nipple (F) should be attached to mounting strap (A) with washer and hex

nut (C) and (D) in place. Canopy loop (H) should be on the other end.

2. Use a screwdriver and mounting screws (B) to attach mounting strap

(A) to the junction box. (Note: When mounting strap (A) is properly

installed, about half of the exterior threads of nipple (F) are exposed,

allowingcanopyloop(H)totsnuglyontonipple(F).Youmaywantto

testtoensurethatwithcanopy(G)inplace,canopyloop(H)tsonto

nipple (F). After testing, remove everything from the nipple and place

aside for later.) until the desired height is reached.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, please

contact the place of purchase.

FINISHING THE INSTALLATION

6. Push canopy (G) up to the ceiling and slide canopy loop collar (I) up beneath the canopy. Tightly thread canopy loop collar (I) onto

canopy loop (H) to secure canopy (G) in place.

7.Slidecandlesleeves(O)overthesockets.Installlightbulbsinaccordancewiththexture’sspecications.Donotexceedthemaximum

wattage.

8.Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

3.Placeshade(N)ontoaatsurface.Threadtoploop(L)ontopost

(M). Measure to determine the correct number of chain links (J) needed

for proper hanging height. If necessary, use a pair of pliers to open and

remove any excess chain. For the semi-ush installation, thread the wires

through canopy (G). Open one of chain connectors (K) and use it to connect

directly top loop (L) to canopy loop (H).

CONNECTING THE WIRES

5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cut

awaytheexcesswires.Threadthexture’swiresthroughthecanopyloopand

nipple.Refertothewiringdiagramandattachthexture’swirestothepower

supply wires from the junction box. Connect Hot to Hot, Neutral to Neutral, and

Ground to Ground. Twist the ends of the wire pairs together, and then twist on

a wire connector. Make sure all twists are in the same direction. If there is no

house ground wire coming from the junction box, locate ground screw (E) on

themountingbracket/mountingstrapandwrapthexture’sgroundwirearound

the ground screw. Use a screwdriver to tighten the top of ground screw (E) onto

the wires and into the mounting bracket/mounting strap. Tuck the wires into the

junction box.

How to Identify the Fixture’s Wires

Hot Neutral Ground

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

House Wires

Fixture Wires

Hot

4. Attach one of chain connector (K) to each end of chain (J). Use one of chain connectors (K) to attach chain (J) to top loop (L) and close

thechainconnector.Feedthexture’swiresupthroughthechain(everythreelinksorso),pullingthewiresuntiltaut.Slidecanopyloop

collar (I) and canopy (G) onto the chain and wires. Use the free chain connector (K) to attach chain (J) to canopy loop (H).
