Hannspree HO 165 PGB Manual

Hannspree Skærm HO 165 PGB

Læs gratis den danske manual til Hannspree HO 165 PGB (8 sider) i kategorien Skærm. Denne vejledning er vurderet som hjælpsom af 21 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 11 anmeldelser. Har du et spørgsmål om Hannspree HO 165 PGB, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

39,6 cm / 15.6“

Part. No..: HO 165 PGB

CONNECTIVITY, IP LEVELSIZE, RESOLUTION VIEWING ANGLE, VESA OTHER FEATURES

Technical Specifications >>>

178°Ultra-Wide

Viewing Angle

VESA

Wall-Mountable

• 1920 x 1080 Resolution Full HD 1080P

• 10-Point Touch P-Cap Technology

• High Brightness 500 cd/m² Panel

• 178° °/ 178 Ultra-Wide Viewing Angle

• Triple Input: HDMI + DP + VGA

• IP65 Rating Level

• Display Protection: Thickness 7.3mm

• Built for 24/7

• 50.000 Hours Backlight Lifetime

• Built-in Speakers

• Operating Temperature: -10~60℃

• Sturdy Metal Case

• VESA Mount and Multiple Mounting Options

• Edge to Edge glass without raised frame

• Orientation: Landscape, Portrait, Face-Up

Open Frame Touch Monitor

HO 165 PGB

39,6 cm / 15.6“ Diagonal

LED Backlight Format 16:9–

15.6”

16:9 Aspect Ratio

Full HD

1920 x 1080

HO 165 PGB

15.6” Open Frame Touch Monitor

Operating

24 Hours / 7 Days

50.000 Hours

Lifetime

VGA

HDMI

Display Port

IP 65

Water & Dust

Protection

PART. NO.:

HO 165 PGB

Display Size 39,6 cm / 15.6“ Diagonal

Panel Type TFT LED Backlight, IPS Panel Type–

Aspect Ratio 16:9

Resolution (H x V) 1920 x 1080 Full HD

Brightness 500 cd/m² (Panel) 425 cd/m² (Monitor)–

Contrast (Typ.) 1000:1 (Typical) 10M:1 (Active Contrast)–

Display Area 345,23 x 194,54 mm

Viewing Angle L/R; U/D 178°H / 178°V (CR > 10)

Response Time 25 msec

Pixel Pitch 0,17925 (H) X 0,17925 (V) mm

Touch Type Projected Capacitive Type 10 Point Touch–

Material Glass + Glass

Cover Glass+LOCA+ITO (Indium Tin Oxide) Glass

Display Colors 16.2M Colors

Horizontal Frequency 31.5 ~ 80 kHz

Vertical Frequency 60 ~ 75 Hz

Max Display Frequency 1920 x 1080 @ 60Hz

Input 1 VGA

Input 2 HDMI

Input 3 / 4 Display Port / USB for Touch

Speakers Yes, 1,5W x 2

Power Consumption On: 12,7W; Stand-by: 0,3W; Off: 0,2W

AC Power Range External Power Supply: 12 Volt / 2,5A

Input: AC 100 ~ 240 Volt; 50 ~ 60 Hz

Product Dimensions 387,3 x 44,3 x 236,4 mm (W x D x H)

Packing Dimensions 464 x 100 x 325 mm (W x D x H)

Net / Gross Weight 3,4 Kg / 4,7 Kg

VESA Mounting 100x100mm. Screws: M4, 10mm(Max), pitch 0,7 mm

Display Protection TP Module Protection Thickness 7,3mm

Hardness / Transmittance 6H Toughened hard panel surface / ≥ ≥85%

IP Rating Level IP 65 (Front), Water and Dust Protection *

Control Menu/Exit,Bri (+),Vol (-) , Input/Enter,Power

LED Backlight life 50.000 hours

On Screen Display 8 Languages

Color 9300, 6500, 5300, User Mode

Preset Mode Standard, Text, Movie, Game Modes

Operating Temperature -10°~60℃

Orientation Landscape, Portrait, Face-Up

Accessory Power Adaptor; EU and UK Power Cables (1,5mt);

HDMI Cable (1,5mt); USB 2.0 (B-A) Cable for Touch

(1,8mt).

slightly from those illustrated on this promotion material. Please refer to actual samples for final selection. The products displayed on this promotion material may not be available for

purchase in your particular country or locality. Please check with your local HANNspree authorized representatives for the av ailability of specific products in your area. All brand, product,

Service names and logos are trademarks and/or registered trademarks of their respective manufactures and Companies.

HO 165 PGB

15.6” Open Frame Touch Monitor

* IP65: The IP Code classifies how resistant a device is to foreign objects and moisture. IP65 means that the monitor is protected

from total dust ingress and it is protected against low pressure water jets from any direction Limited ingress permitted

Supplier‘s Name HANNspree

Model Name HO165PGB

Energy efficiency class for standard

Dynamic Range (SDR) F

Annual Energy Power Consumption

(kWh/1000h) 13 kWh/1000h

On mode power demand for Standard

Dynamic Range (SDR) 12,7 W

Off mode power demand (W) 0,2 W

Standby mode power demand (W) 0,3 W

Screen Diagonal (cm / inches) 39,6cm / 15.6“

Resolution 1920 x 1080

Produkt Specifikationer

Mærke:	Hannspree
Kategori:	Skærm
Model:	HO 165 PGB
Kode for international beskyttelse (IP):	IP65
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50/60 Hz
Bredde:	387.3 mm
Dybde:	40 mm
Højde:	236.4 mm
Vægt:	3400 g
Produktfarve:	Sort
Skærm diagonal:	15.6 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ja
Wi-Fi:	Ingen
USB-port:	Ja
HD-type:	Fuld HD
Skærmteknologi:	IPS
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	425 cd/m²
Responstid:	25 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm diagonal (metrisk):	39.6 cm
LED-baggrundsbelysning type:	LED
Smart funktioner:	Game,Movie,Standard
Indbyggede højttaler(e):	Ja
Udgangseffekt (RMS):	3 W
Antal HDMI-porte:	1
DVI-port:	Ingen
Ethernet LAN:	Ingen
Skærmvisning (OSD):	Ja
Antal OSD sprog:	8
VESA montering:	Ja
Panel montering grænseflade:	100 x 100 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	35 W
Driftstemperatur (T-T):	10 - 60 °C
Strømforbrug (slukket):	0.3 W
Kabler inkluderet:	USB
Energiforbrug (SDR) pr. 1000 timer:	13 kWh
Certificering:	CE, EU
Energieffektivitetsklasse (SDR):	F
Energiforbrug (HDR) pr. 1000 timer:	- kWh
Energieffektivitetsskala:	A til G
DC-in-stik:	Ja
Harmoniseret systemkode (HS):	85285210
Glasbeskyttelse:	Ja
LED-baggrundsbelysning:	Ja
Antal indbyggede højttalere:	2
Understøttet placering:	Indendørs
Bæredygtighedscertifikater:	RoHS
Paneltype:	IPS
Formål:	Universel
Vis antal farver:	16,2 millioner farver
Plug and play:	Ja
Indgangsstrøm:	2.5 A
Kontrastforhold (typisk):	1000:1
Kontrastforhold (dynamisk):	10000000:1
Pixel pitch:	0.17925 x 0.17925 mm
Horisontal scanningsområde:	31.5 - 80 kHz
Antal DisplayPorts:	1
Ekstern strømadapter:	Ja
Spænding:	12 V
Indbygget processer:	Ingen
Aktiv skærmområde (B x H):	345.23 x 194.54 mm
Vertikalt scanningsområde:	60 - 70 Hz
VGA (D-Sub) indgangsporte:	1
Skærmens lysstyrke (spidsbelastning):	500 cd/m²
Panel levetid:	50000 t
Driftstimer (timer/dage):	24/7
Computersystem:	Ingen
Antal simultane touchpunkter:	10
Orientering:	Horisontal/vertikal
Multi-touch:	Ja
Hårdhed:	6H
Gennemsigtighed:	85 %
