Harman Kardon Champagne Manual

Harman Kardon Højttaler Champagne

Læs gratis den danske manual til Harman Kardon Champagne (14 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 42 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 21.5 anmeldelser. Har du et spørgsmål om Harman Kardon Champagne, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/14
Page 1
User’s Guide
harman/kardon
Champagne
950-0010
English
German
Italian
S
p
anish
Page 2
Safety Instructions
Please read the following operation precautions before use:
Introduction
The HK 695 is the latest innovation from harman/kardon, a long time leader in the manufacture of
high-end component and computer audio systems. harman/kardon’s audio heritage combined with
continual research has provided the unique technologies included in the HK 695.
These technologies include Vmax, a Harman International audio image-processing algorithm that
seamlessly supports both two and four channel sound cards. This audio hologram creates a four
speaker sound field from two speakers through the use of a head related transfer function when used
with a four channel sound card. In addition, the algorithm provides enhanced stereo when used with
a two channel sound card.
The Harman Multimedia Odyssey I transducer is another technology critical to the HK 695. This
unique full range transducer was designed specifically for extremely small speaker enclosures while
providing significant mid bass. In addition to the bass, the small, rigid and light inverted aluminum
cone provides performance that will rival any tweeter used in multimedia speakers today. The result
is a small and elegant satellite speaker that perfectly integrates with the subwoofer while providing
superior midrange and highs.
The Magnum series subwoofer transducer provides deep bass. This Magnum series of woofers are
designed specifically to match with the Harman Multimedia Odyssey I transducers. The same
approach of providing solid bass from a small enclosure guided the development of these Magnum
transducers.
As described in the Using the speaker system section of the user’s guide, the top of the control/right
speaker features
- and + buttons. Briefly pressing the appropriate button will cause a small step
increase or decrease in the system volume. Holding down the appropriate button for more than 0.5
seconds will cause the volume to decrease or decrease rapidly while that button is held down.
Treble, Bass and Surround level adjust knobs are located on top of the subwoofer unit. A system
on/off switch is also provided on the rear of the subwoofer unit. The system includes two desktop
speakers and a subwoofer that can be placed either on the floor or on your desk. Both satellite
speakers and the subwoofer are magnetically shielded to provide the greatest protection against
computer monitor image distortion.
• Read instructions ---All the safety and operating instructions should be read thoroughly before attempting to operate this audio
system.
• Retain instructions for future reference.
• Heed warnings --- All warnings on this audio system and in the operating instructions should be adhered to.
• Follow instructions --- All operating and use instructions should be followed.
• TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). THERE ARE NO USER
SERVICEABLE PARTS INSIDE THIS UNIT, PLEASE REFER SERVICING TO QUALIFIED HARMAN/KARDON
CORPORATION SERVICE PERSONNEL.
• Do not expose the speakers to liquid or solvent.
• Never remove grille covers in order to service the speaker system. The speaker system does not contain any user serviceable
parts. Refer all servicing to the Harman/Kardon Technical Support Group.
• Do not expose the speaker system to temperature or humidity extremes, direct sunlight, excessive dust, or vibrations.
• Place the speaker system on a stable, level surface. Do not drop, apply excessive force to the controls, or put heavy objects on
top of the speaker.
• If cleaning is required, use a soft dry cloth. If necessary, use a damp cloth without any solvents.
• In order to protect the speaker system, avoid microphone feedback, continuous output from electronic musical instruments, or
distorted output from any signal source.
• Do not place the speakers close to fluorescent light sources, or neon light fixtures.
• Although the speakers are magnetically shielded, keep magnetic storage media (disks and tapes) at least four inches from the
speaker system in order to avoid data loss.
• WARNING: To reduce the risk of fire or electric shock, do not expose this speaker system to rain or moisture.

Produkt Specifikationer

Mærke: Harman Kardon
Kategori: Højttaler
Model: Champagne
