Side 1/24
I&W #07.05.208.00
GLO-RAY
®
Max Watt Infrared Strip Heaters
GRAM and GRAML Series
Installation and Operating Manual
Do not operate this equipment unless
you have read and understood the
contents of this manual! Failure to follow
the instructions contained in this manual
may result in serious injury or death.
This manual contains important safety
information concerning the
maintenance, use, and operation of this
product. If you’re unable to understand
the contents of this manual, please bring
it to the attention of your supervisor.
Keep this manual in a safe location for
future reference.
No opere este equipo al menos que haya
leído y comprendido el contenido de este
manual! Cualquier falla en el
seguimiento de las instrucciones
contenidas en este manual puede
resultar en un serio lesión o muerte. Este
manual contiene importante información
sobre seguridad concerniente al
mantenimiento, uso y operación de este
producto. Si usted no puede entender el
contenido de este manual por favor
pregunte a su supervisor. Almacenar
este manual en una localización segura
para la referencia futura.
© 2008 Hatco Corporation
i
CONTENTS
Form No. GRAMM-0508
INTRODUCTION
Hatco Glo-Ray
®
Max Watt Strip Heaters ensure
maximum food holding and minimize the risk of food-
borne illness. Optimum safety and quality is the result
of food held at the proper serving temperatures using
Glo-Ray’s pre-focused heat patterns. The pre-focused
heat pattern prevents foods from being over-cooked in
the middle and cooling off around the edges by
concentrating higher temperatures to the outer edges
of holding surfaces where heat loss is the greatest.
Utilizing specially designed reflectors to direct the heat
from the element, Glo-Ray Strip Heaters safely
maintain peak serving temperatures longer without
cooking the food beyond the point of excellence.
Glo-Ray Max Watt Strip Heaters are available from the
factory with or without shatter-resistant incandescent
lights to illuminate the warming area. These bulbs
have a special coating that guards against injury and
food contamination in the event of breakage.
Glo-Ray Max Watt Strip Heaters are a product of
extensive research and field testing. The materials
used were selected for maximum durability, attractive
appearance, and optimum performance. Every unit is
inspected and tested thoroughly prior to shipment.
This manual provides the installation, safety, and
operating instructions for Glo-Ray Max Watt Strip
Heaters. Hatco recommends all installation,
operating, and safety instructions appearing in this
manual be read prior to installation or operation of
the Strip Heaters.
Safety information that appears in this manual is
identified by the following signal word panels:
WARNING indicates a hazardous situation
which, if not avoided, could result in death or
serious injury.
CAUTION indicates a hazardous situation which,
if not avoided, could result in minor or moderate
injury.
NOTICE is used to address practices not related
to personal injury.
NOTICE
CAUTION
WARNING
Important Owner Information...............................i
Introduction ...........................................................i
Important Safety Information..............................1
Model Designations .............................................2
Model Descriptions..............................................3
Specifications.......................................................4
Electrical Rating Charts...................................4
Dimensions......................................................6
Installation ............................................................7
General............................................................7
Minimum Clearance Requirements .................8
Recommended Mounting Heights ...................8
Assembly.........................................................9
Permanent Surface Mount ..............................9
Undershelf Mounting .....................................10
Overhead Mounting.......................................11
Electrical Wiring Hook-Up .............................12
Operation ............................................................13
Maintenance .......................................................14
General..........................................................14
Replacing Display Light Bulbs ......................14
Accessories........................................................15
Troubleshooting Guide......................................16
Hatco Limited Warranty.....................................18
Authorized Parts Distributors...........Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number
(identification decal located on the underside of the
unit), voltage, and purchase date of your strip heater
in the spaces below. Please have this information
available when calling Hatco for service assistance.
Model No. ________________________________
Serial No. ________________________________
Voltage __________________________________
Date of Purchase __________________________
Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time
(Summer Hours: June to September –
8:00 a.m. to 5:00 p.m. C.S.T.
Monday through Thursday
8:00 a.m. to 2:30 p.m. C.S.T. Friday)
Telephone: (800) 558-0607; (414) 671-6350
Fax: (800) 690-2966 (Parts and Service)
(414) 671-3976 (International)
24 Hour 7 Day Parts and Service
Assistance available in the
United States and Canada
by calling (800) 558-0607.
Additional information can be found by visiting our
web site at www.hatcocorp.com.
