Heated Zone Merchandisers
HZMH and HZMS Series
Installation and Operating Manual
P/N 07.04.569.00
Register Online!
(see page 2)
www.hatcocorp.com
Do not operate this equipment unless you
have read and understood the contents of
this manual! Failure to follow the
instructions contained in this manual may
result in serious injury or death. This
manual contains important safety
information concerning the maintenance,
use, and operation of this product. If
you’re unable to understand the contents
of this manual, please bring it to the
attention of your supervisor. Keep this
manual in a safe location for future
reference.
No opere este equipo al menos que haya
leído y comprendido el contenido de este
manual! Cualquier falla en el seguimiento
de las instrucciones contenidas en este
manual puede resultar en un serio lesión
o muerte. Este manual contiene
importante información sobre seguridad
concerniente al mantenimiento, uso y
operación de este producto. Si usted no
puede entender el contenido de este
manual por favor pregunte a su
supervisor. Almacenar este manual en
una localización segura para la referencia
futura.
Ne pas utiliser cet équipement sans avoir
lu et compris le contenu de ce manuel !
Le non-respect des instructions
contenues dans ce manuel peut entraîner
de graves blessures ou la mort. Ce
manuel contient des informations
importantes concernant l'entretien,
l'utilisation et le fonctionnement de ce
produit. Si vous ne comprenez pas le
contenu de ce manuel, veuillez le signaler
à votre supérieur. Conservez ce manuel
dans un endroit sûr pour pouvoir vous y
référer plus tard.
WARNING
ADVERTENCIA
AVERTISSEMENT
Form No. HZMM-0812
2
CONTENTS
Safety information that appears in this manual is identified by
the following signal word panels:
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to personal
injury.
NOTICE
CAUTION
WARNING
INTRODUCTION
Hatco Heated Zone Merchandisers with Spot On
®
technology
are perfect for holding hot packaged food in convenience
stores, on a buffet line, or at temporary serving areas. Instant-
on, individually-zoned overhead ribbon elements are combined
with heated shelves that have separate front and rear heating
elements to significantly reduce energy consumption. Hot
wrapped products are kept at optimum serving temperatures
without affecting quality. These units feature an LCD controller,
LED lighting on each shelf, and come with a cord and plug set.
Hatco Heated Zone Merchandisers are products of extensive
research and field testing. The materials used were selected
for maximum durability, attractive appearance, and optimum
performance. Every unit is inspected and tested thoroughly prior
to shipment.
This manual provides the installation, safety, and operating
instructions for Heated Zone Merchandisers. Hatco
recommends all installation, operating, and safety instructions
appearing in this manual be read prior to installation or
operation of the warmer.
Important Owner Information ..............................................2
Introduction...........................................................................2
Important Safety Information...............................................3
Model Description.................................................................4
All Models............................................................................4
HZMH-XX and HZMH-XXD Models ....................................4
HZMS-XX and HZMS-XXD Models ....................................4
Model Designation................................................................4
Specifications........................................................................5
Plug Configurations.............................................................5
Electrical Rating Charts.......................................................5
Factory Setpoints — Slanted Shelf Models ........................6
Factory Setpoints — Horizontal Shelf Models ....................6
Overall Dimensions — HZMH Models ................................7
Overall Dimensions — HZMS Models ................................8
Shelf and Zone Dimensions................................................9
Overhead Zone Identification..............................................9
Installation ...........................................................................10
General .............................................................................10
Operation .............................................................................11
General..............................................................................11
Changing Shelf Setpoint Temperatures ............................12
Changing Element Power Percentages ............................13
Changing Operating Mode................................................15
Changing Between Fahrenheit and Celsius .....................15
Maintenance ........................................................................16
General .............................................................................16
Cleaning ............................................................................16
Troubleshooting Guide ......................................................17
Options and Accessories...................................................18
Limited Warranty.................................................................19
Addendum ...........................................................................20
LCD Controller Flow Chart — Horizontal Shelf Model......20
LCD Controller Flow Chart — Slanted Shelf Model..........21
Authorized Parts Distributors............................Back Cover
