2011
Honda VT750C/A
Shadow Aero
OWNER’S MANUAL
−
Introduction
Introduction
Congratulations on choosing your Honda
motorcycle.
When you own a Honda, you’re part of a
worldwide family of satisfied customers
people who appreciate Honda’s
reputation for building quality into every
product.
Before riding, take time to get acquainted
with your motorcycle and how it works.
To protect your investment, we urge you
to take responsibility for keeping your
motorcycle well maintained. Scheduled
service is a must, of course. But it’s just as
important to observe the break-in
guidelines, and perform all pre-ride and
other periodic checks detailed in this
manual.
We also recommend that you read this
owner’s manual before you ride. It’s full
of facts, instructions, safety information,
and helpful tips. To make it easy to use,
the manual contains a detailed list of
topics at the beginning of each section and
an index at the back of the book.
As you read this manual, you will find
information that is preceded by a
symbol. This information is
intended to help you avoid damage to your
Honda, other property, or the environment.
Introduction
Introduction
WARNING:
Read the Warranties Booklet (page )
thoroughly so you understand the
coverages that protect your new Honda
and are aware of your rights and
responsibilities.
If you have any questions, or if you ever
need special service or repairs, remember
that your Honda dealer knows your
motorcycle best and is dedicated to your
complete satisfaction.
Please report any change of address or
ownership to your dealer so we will be
able to contact you concerning important
product information.
You may also want to visit our website at
www.honda.com.
Happy riding!
This product contains or
emits chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
California Proposition 65 Warning
209
A Few Words About Safety
Safety Messages
Safety Labels
Safety Messages
DANGER, WARNING, CAUTION
Your safety, and the safety of others, is very important. And operating this motorcycle safely
is an important responsibility.
To help you make informed decisions about safety, we have provided operating procedures
and other information on labels and in this manual. This information alerts you to potential
hazards that could hurt you or others.
Of course, it is not practical or possible to warn you about all hazards associated with
operating or maintaining a motorcycle. You must use your own good judgment.
You will find important safety information in a variety of forms, including:
–– on the motorcycle.
–– preceded by a safety alert symbol and one of three signal words:
or .
These signal words mean:
You WILL be KILLED or SERIOUSLY HURT if you
don’t follow instructions.
You CAN be KILLED or SERIOUSLY HURT if you don’t
follow instructions.
You CAN be HURT if you don’t follow instructions.
A Few Words About Safety
Safety Messages
Safety Headings
Safety Section
Instructions
–– such as Important Safety Reminders or Important Safety Precautions.
–– such as Motorcycle Safety.
–– how to use this motorcycle correctly and safely.
This entire manual is filled with important safety information –– please read it carefully.
1
Motorcycle Safety
Motorcycle Safety
This section presents some of the most
important information and
recommendations to help you ride your
motorcycle safely. Please take a few
moments to read these pages. This section
also includes information about the
location of safety labels on your
motorcycle.
................Important Safety Information .
.................Accessories & Modifications .
..........................................Safety Labels .
2
5
7
−
2
Important Safety Information
Motorcycle Safety
Always Wear a HelmetYour motorcycle can provide many years
of service and pleasure if you take
responsibility for your own safety and
understand the challenges you can meet
while riding.
There is much that you can do to protect
yourself when you ride. You’ll find many
helpful recommendations throughout this
manual. The following are a few that we
consider to be most important.
It’s a proven fact: helmets significantly
reduce the number and severity of head
injuries. So always wear an approved
motorcycle helmet and make sure your
passenger does the same. We also
recommend that you wear eye protection,
sturdy boots, gloves, and other protective
gear (page ).26
3
Important Safety Information
Motorcycle Safety
Take Time to Learn & Practice
Ride Defensively
Make Yourself Easy to See
You and
Your Motorcycle Riding Tips,
Always pay attention to other vehicles
around you, and do not assume that other
drivers see you. Be prepared to stop
quickly or make an evasive maneuver. For
other riding tips, see the booklet,
which came
with your new motorcycle (USA only).
Even if you have ridden other motorcycles,
take time to become familiar with how
this motorcycle works and handles.
Practice in a safe area until you build your
skills and get accustomed to the
motorcycle’s size and weight.
Because many crashes involve
inexperienced or untrained riders, we urge
all riders to take a motorcycle operator
course approved by the Motorcycle Safety
Foundation (MSF). See page .
The most frequent motorcycle collision
happens when a car turns left in front of a
motorcycle. Another common situation is
a car moving suddenly into your lane.
Some drivers do not see motorcycles
because they are not looking for them. To
make yourself more visible, wear bright
reflective clothing, position yourself so
other drivers can see you, signal before
turning or changing lanes, and use your
horn when it will help others notice you.
28
4
Ride within Your Limits
Don’t Drink and Ride
Keep Your Honda in Safe Condition
Important Safety Information
Motorcycle Safety
Pushing limits is another major cause of
motorcycle crashes. Never ride beyond
your personal abilities or faster than
conditions warrant. Remember that
alcohol, drugs, fatigue, and inattention can
significantly reduce your ability to make
good judgments and ride safely.
Alcohol and riding don’t mix. Even one
drink can reduce your ability to respond to
changing conditions, and your reaction
time gets worse with every additional
drink. So don’t drink and ride, and don’t
let your friends drink and ride either.
It’s important to keep your motorcycle
properly maintained and in safe riding
condition. To help avoid problems, inspect
your motorcycle before every ride and
perform all recommended maintenance.
Never exceed load limits (page ), and
do not modify your motorcycle (page )
or install accessories that would make
your motorcycle unsafe (page ).
6
5
33
Improper accessories or
modifications can cause a crash in
which you can be seriously hurt or
killed.
Follow all instructions in this
owner’s manual regarding
accessories and modifications.
5
Accessories
Accessories & Modifications
Motorcycle Safety
Modifying your motorcycle or using non-
Honda accessories can make your
motorcycle unsafe. Before you consider
making any modifications or adding an
accessory, be sure to read the following
information.
We strongly recommend that you use only
Honda Genuine Accessories that have
been specifically designed and tested for
your motorcycle. Because Honda cannot
test all other accessories, you must be
personally responsible for proper selection,
installation, and use of non-Honda
accessories.
Check with your dealer for assistance and
always follow these guidelines:
(cont’d)
Make sure the accessory does not
obscure any lights, reduce ground
clearance and lean angle, limit
suspension travel or steering travel, alter
your riding position, or interfere with
operating any controls.
6
Modifications
Accessories & Modifications
Motorcycle Safety
We strongly advise you not to remove any
original equipment or modify your
motorcycle in any way that would change
its design or operation. Such changes
could seriously impair your motorcycle’s
handling, stability, and braking, making it
unsafe to ride.
Removing or modifying your lights,
exhaust system, emission control system,
or other equipment can also make your
motorcycle illegal.
Do not install any fairing or windscreen
unless it was designed and tested by
Honda for your motorcycle. Some
fairings or windscreens, even smaller
ones, can cause unstable handling of
your motorcycle. This is especially true
if the fairing or windscreen is poorly
designed or improperly mounted.
Do not add any electrical equipment
that will exceed the motorcycle’s
electrical system capacity (page ).
A blown fuse can cause a loss of lights
or engine power (page ).
Do not pull a trailer or sidecar with your
motorcycle. This motorcycle was not
designed for these attachments, and
their use can seriously impair your
motorcycle’s handling.
190
172
7
Safety Labels
Motorcycle Safety
Safety labels on your motorcycle either warn you of potential hazards that could cause
serious injury or they provide important safety information. Read these labels carefully and
don’t remove them.
If a label comes off or becomes hard to read, contact your dealer for a replacement.
8
Safety Labels
Motorcycle Safety
9
Instruments & Controls
Instruments & Controls
This section shows the location of all
gauges, indicators, and controls you would
normally use before or while riding your
motorcycle.
The items listed on this page are described
in this section. Instructions for other
components are presented in other sections
of this manual where they will be most
useful.
...........Operation Component Locations .
...............Gauges, Indicators & Displays .
......................................Digital Clock .
.............................Turn Signal Switch .
.................Headlight Dimmer Switch .
............................Engine Stop Switch .
.........................................Start Button .
...................................Ignition Switch .
................................Controls & Features .
........................................Horn Button .
Odometer/Tripmeter/Digital Clock
................................................Display .
10
13
18
19
21
21
22
22
23
23
24
throttle grip
clutch lever engine stop
switch
front brake
lever
start button
turn signal switch
horn button
headlight
dimmer switch
10 Instruments & Controls
Operation Component Locations
steering lock
rear brake pedal
11
Instruments & Controls
Operation Component Locations
ignition switch
helmet holder
shift lever
12 Instruments & Controls
Operation Component Locations
(6)(8)
(2)(1)
(7)
(4)(3) (5)
(11) (10) (9)
13
Instruments & Controls
Gauges, Indicators & Displays
The indicators on your motorcycle keep
you informed, alert you to possible
problems, and make your riding safer and
more enjoyable. Refer to the indicators
frequently. Their functions are described
on the following pages.
Canada: Odometer & tripmeter read in
kilometers.
USA: Odometer & tripmeter read in miles.
(1) speedometer
(2) fuel reserve indicator
(3) turn signal indicator
(4) high beam indicator
(5) Anti-lock Brake System (ABS)
indicator (VT750C ABS)
(6) PGM-FI malfunction indicator
lamp (MIL)
(7) high coolant temperature indicator
(8) odometer/tripmeter/digital clock
display
(9) low oil pressure indicator
(10) neutral indicator
(11) select/reset button
−
14 Instruments & Controls
Gauges, Indicators & Displays
Lamp
Check.
Lamp Check
The low oil pressure indicator, high
coolant temperature indicator and PGM-FI
malfunction indicator lamp (MIL) come
on when you turn the ignition switch ON
so you can check that they are working.
The low oil pressure indicator remains on
until after the engine is started. The high
coolant temperature indicator and PGM-FI
malfunction indicator lamp (MIL) light
for a few seconds and then go off when
you turn the ignition switch ON. These
indicators are identified in the table on
pages with the words:
The Anti-lock Brake System (ABS)
indicator comes on when you turn the
ignition switch ON. This indicator goes
off after you ride the motorcycle at a
speed above 6 mph (10 km/h).
When applicable, the high beam and
neutral indicators come on when you turn
the ignition switch ON and remain on until
you select the low beam or shift out of
neutral.
If one of these indicators does not come
on when it should, have your dealer check
for problems.
1715
0.92 US gal (3.5 )
15
Instruments & Controls
Gauges, Indicators & Displays
Anti-lock Brake System
(ABS) Indicator
Lamp
Check.
Shows riding speed in miles (USA) or kilometers
(Canada) per hour.
speedometer
high beam indicator
(blue)
Lights when the headlight is on high beam.
Flashes when either turn signal operates.turn signal indicator
(green)
When this indicator comes on while riding, fuel
reserved in the tank is about:
fuel reserve indicator
(amber)
Anti-lock Brake
System (ABS)
indicator (amber)
1
2
3
4
5 Lights when there is any abnormality in the Anti-
lock Brake System (ABS). Normally, this indicator
comes on when the ignition switch is turned ON, and
goes off after you ride the motorcycle at a speed
above 6 mph (10 km/h). If the indicator comes on
while riding, stop the motorcycle in a safe place and
turn off the engine. Refer to
, page . For information about
Anti-lock Brake System (ABS), see page .
(VT750C ABS)
47
46
16
Gauges, Indicators & Displays
Instruments & Controls
Lamp Check.
Lamp Check.
Lights when there is any abnormality in the PGM-FI
(Programmed Fuel Injection) system. Should also
light for a few seconds and then go off when the
ignition switch is turned ON and the engine stop
switch is at RUN. If the indicator comes on at any
other time, reduce speed and take your motorcycle to
your dealer as soon as possible.
PGM-FI malfunction
indicator lamp (MIL)
(amber)
Lights when the coolant is over the specified
temperature. If the indicator comes on, pull safely to
the side of the road. See page for instructions
and cautions.
high coolant temperature
indicator (red)
6
7
169
17
Gauges, Indicators & Displays
Instruments & Controls
Lamp Check
odometer
tripmeter 1 & 2
Shows the total miles (USA) or kilometers (Canada)
ridden (page ).
odometer/tripmeter/
digital clock display
Shows the number of miles (USA) or kilometers
(Canada) ridden since you last reset the meter. The
tripmeter has two sub modes, ‘‘TRIP 1’’ and ‘‘TRIP
2.’’ To zero (0) the tripmeter, push and hold the
select/reset button (page ).
8
9
10
11
digital clock Shows hour and minute (page ).
Lights when engine oil pressure is low enough to
cause engine damage. If the low oil pressure
indicator lights during operation, pull safely to the
side of the road. See page for instructions and
cautions. .
Lights when the transmission is in neutral.neutral indicator (green)
select/reset button Adjusts the time, resets the tripmeter or selects the
operation mode: digital clock, tripmeter or odometer
(page ).
low oil pressure indicator
(red)
18
18
19
171
18
(1)
(5)
(2)
(3)
(1) odometer
(2) tripmeter 1
(3) tripmeter 2
(4) digital clock
(5) select/reset button
(6) tripmeter reset
(4)
(6)
18
Odometer/Tripmeter/
Digital Clock Display
Instruments & Controls
Gauges, Indicators & Displays
The odometer ( ) shows the total miles
ridden.
Push the select/reset button ( ) to select
the ‘‘ODO’’, ‘‘TRIP 1’’, ‘‘TRIP 2’’ or
clock mode.
To reset the tripmeter, push and hold the
select/reset button for more than 2 seconds
with the display in the ‘‘TRIP 1’’ or
‘‘TRIP 2’’ mode.
Tripmeter 1 ( ) and tripmeter 2 ( ) show
number of miles ridden since you last reset
the meter.
5
32
1
(1)
(1) select/reset button
19
Digital Clock
Gauges, Indicators & Displays
Instruments & Controls
Shows hour and minute. To adjust the time,
proceed as follows:
Turn the ignition switch ON.
(cont’d)
Select the digital clock mode.
Push and hold the select/reset button
( ) for more than 2 seconds. The clock
will be set in the adjust mode with the
hour display flashing.
To set the hour, push the select/reset
button until the desired hour is
displayed.
1.
2.
3.
4.
1
20
Gauges, Indicators & Displays
Instruments & Controls
Push and hold the select/reset button for
more than 2 seconds. The minute
display will start flashing.
To set the minute, push the select/reset
button until the desired minute is
displayed. The minute display will
return to ‘‘00’’ when ‘‘60’’ is reached
without affecting the hour display.
To end the adjustment, push and hold
the select/reset button for more than 2
seconds or turn the ignition switch OFF.
The display will stop flashing
automatically and will exit the
adjustment mode if the button is not
pressed for about 30 seconds.
7.
6.
5.
ON
OFF
Electrical circuits on.
No electrical
circuits function.
LEFT SIDE
(1) ignition switch
(1)
OFF ON
Key Position Function
21
Ignition Switch
Controls & Features
Instruments & Controls
The ignition switch ( ) is used for starting
and stopping the engine (page ). The
ignition key is also used to lock the
steering for theft prevention (page ).
Insert the key and turn it to the right for
the ON position.
If a key ring is used, we recommend a
fabric or leather type with just the key
attached. The use of a metal key ring or
the attachment of additional keys to any
type of key ring may damage the finish of
the side cover and engine cover while
inserting the key or riding.
1
51
37
RIGHT HANDLEBAR
(1) start button
(2) engine stop switch OFF
RUN
(1)
(2)
22
Start Button Engine Stop Switch
Instruments & Controls
Controls & Features
Starting Procedure,
The engine stop switch ( ) is used to stop
the engine in an emergency. To operate,
push the switch to the OFF position. The
switch must be in the RUN position to
start the engine, and it should normally
remain in the RUN position even when the
engine is OFF.
The start button ( ) is used for starting the
engine. Pushing the button in starts the
engine. See page .
When the start button is pushed, the starter
motor will crank the engine; the headlight
will automatically go out, but the taillight
will stay on.
The starter motor will not operate if the
engine stop switch is in the OFF position
when the start button is pushed.
2
1
38
(2)
(1)
LEFT HANDLEBAR
(1) headlight dimmer switch
(2) turn signal switch
(3) horn button
HI
LO
(3)
23
Headlight Dimmer Switch
Turn Signal Switch
Controls & Features
Instruments & Controls
If your motorcycle is stopped with the
ignition switch ON and the engine stop
switch OFF, the headlight and taillight
will remain on, resulting in battery
discharge.
The turn signal switch ( ) is used to signal
a turn or a lane change. To operate, move
the switch all the way in the proper
direction and release it. The appropriate
turn signal lights will start blinking. To
cancel the light, push the switch in.The headlight dimmer switch ( ) is used
to change between the high and low beams
of the headlight. To operate, turn the
switch to HI for high beam, LO for low
beam.
1
2
24
Horn Button
Controls & Features
Instruments & Controls
The horn is used to alert other motorists.
To operate, push the horn button ( ).3
25
Before Riding
Before Riding
Before each ride, you need to make sure
you and your Honda are both ready to ride.
To help get you prepared, this section
discusses how to evaluate your riding
readiness, what items you should check on
your motorcycle, and adjustments to make
for your comfort, convenience, or safety.
This section also includes important
information about loading.
For information about adjusting the
suspension on your Honda, see page .
........................Are You Ready to Ride? .
..............................Protective Apparel .
....................................Rider Training .
......Is Your Motorcycle Ready to Ride? .
.............................Pre-ride Inspection .
......................Load Limits & Guidelines .
...............................................Loading .
........................................Load Limits .
............................Loading Guidelines .
110
26
26
28
29
29
32
32
33
33
26
Protective Apparel
Are You Ready to Ride?
Before Riding
Before you ride your motorcycle for the
first time, we urge you to:
Read this owner’s manual.
Make sure you understand all the safety
messages.
Know how to operate all the controls.
You feel well and are in good physical
and mental condition.
Before each ride, be sure: For your safety, we strongly recommend
that you always wear an approved
motorcycle helmet, eye protection, boots,
gloves, long pants, and a long-sleeved
shirt or jacket whenever you ride.
Although complete protection is not
possible, wearing proper gear can reduce
the chance of injury when you ride.
Following are suggestions to help you
choose the proper gear.
You are wearing an approved
motorcycle helmet (with chin strap
tightened securely), eye protection, and
other protective clothing.
Make sure your passenger is ready to ride,
too, and is wearing proper gear including a
helmet.
You don’t have any alcohol or drugs in
your system.
If you must carry an extra helmet while
riding, use a commercially available
elastic cord, strap, or net to secure the
helmet to the seat.
Improperly maintaining this
motorcycle or failing to correct a
problem before riding can cause a
crash in which you can be
seriously hurt or killed.
Always perform a pre-ride
inspection before every ride and
correct any problems.
29
Pre-ride Inspection
Before Riding
Is Your Motorcycle Ready to Ride?
Tires
&
Wheels
Before each ride, it’s important to inspect
your motorcycle and make sure any
problem you find is corrected. A pre-ride
inspection is a must, not only for safety,
but because having a breakdown, or even
a flat tire, can be a major inconvenience.
Check the following items before you get
on the motorcycle:
Look at the tires. If a tire
appears low, use an air
pressure gauge to check its
pressure. Also look for
signs of excessive wear
(page ) or damage to
the tires, rims and spokes.
(cont’d)
123
30
Is Your Motorcycle Ready to Ride?
Before Riding
Leaks,
Loose
Parts
Lights
Load Limits
Cargo
Adjustments
Walk around your
motorcycle and look for
anything that appears
unusual, such as a leak or
loose cable.
Make sure the headlight,
brakelight, taillight, and
turn signals are working
properly.
If you are carrying a passenger or cargo,
also check the following:
Make sure you do not
exceed the load limits
(page ).
Check that all cargo is
secure.
Adjust the rear suspension
(page ) according to
your load.
33
110
31
Is Your Motorcycle Ready to Ride?
Before Riding
Periodic MaintenanceThrottle
Brakes
Indicators
If you haven’t ridden the motorcycle in
over a week, you should also check other
items, such as the oil level and other fluids.
See (page ).
Periodic maintenance should also be done
at least once a month, no matter how often
you ride.
Remember, be sure to take care of any
problem you find, or have your dealer
correct it before you ride.
Check these items after you get on the
motorcycle:
Rotate the throttle to check
it moves smoothly without
binding.
Pull the brake lever and
press on the brake pedal to
check that they operate
normally.
Turn the ignition on and
check for normal operation
of the indicators (page ).13
60
Overloading or improper loading
can cause a crash and you can be
seriously hurt or killed.
Follow all load limits and other
loading guidelines in this manual.
32
Loading
Load Limits & Guidelines
Before Riding
Your motorcycle has been designed to
carry you and one passenger. When you
carry a passenger, you may feel some
difference during acceleration and braking.
But so long as you keep your motorcycle
well-maintained, with good tires and
brakes, you can safely carry loads within
the given limits and guidelines.
How much weight you put on your
motorcycle, and how you load it, are
important to your safety. Anytime you
ride with a passenger or cargo, you should
be aware of the following information.
However, exceeding the weight limit or
carrying an unbalanced load can seriously
impair your motorcycle’s handling,
braking, and stability. Non-Honda
accessories, improper modifications, and
poor maintenance can also reduce your
safety margin.
401 lb (182 kg)
40 lb (18 kg)
33
Loading GuidelinesLoad Limits
Load Limits & Guidelines
Before Riding
maximum weight capacity:
maximum cargo weight:
Your motorcycle is primarily intended for
transporting you and a passenger. You
may wish to secure a jacket or other small
items to the seat when you are not riding
with a passenger.
If you wish to carry more cargo, check
with your dealer for advice, and be sure to
read the information regarding accessories
on page .
Following are the load limits for your
motorcycle:
includes the weight of the rider,
passenger, all cargo, and all accessories.
The weight of added accessories will
reduce the maximum cargo weight you
can carry.
5
34
Load Limits & Guidelines
Before Riding
Improperly loading your motorcycle can
affect its stability and handling. Even if
your motorcycle is properly loaded, you
should ride at reduced speeds and never
exceed 80 mph (130 km/h) when carrying
cargo.
Follow these guidelines whenever you
carry a passenger or cargo:
Check that both tires are properly
inflated, and that pressure in the rear
tire is increased to suit the load
(page ).
If you change your normal load, you
may need to adjust the rear suspension
(page ).
To prevent loose items from creating a
hazard, make sure that all cargo is tied
down securely before you ride.
Place cargo weight as low and close to
the center of your motorcycle as
possible.
Balance cargo weight evenly on both
sides.
Do not attach large or heavy items (such
as a sleeping bag or tent) to the
handlebar, forks, or fender.
110
121
35
Basic Operation & Riding
Basic Operation & Riding
This section gives basic riding instructions,
including how to start and stop your
engine, and how to use the throttle, clutch,
and brakes. It also provides important
information on riding with a passenger or
cargo.
To protect your new engine and enjoy
optimum performance and service life,
refer to Break-in Guidelines (page ).
.........................Safe Riding Precautions .
.............Starting & Stopping the Engine .
..........................................Preparation .
..............................Starting Procedure .
..................................Flooded Engine .
To protect the catalytic converters in your
motorcycle’s exhaust system, avoid
extended idling and the use of leaded
gasoline. ..........Riding with a Passenger or Cargo .
........................Theft-prevention Tips .
....................................................Parking .
.....................................ABS Indicator .
.........Anti-lock Brake System (ABS) .
...................................................Braking .
.........................................Shifting Gears .
.....................How to Stop the Engine .
Bank Angle Sensor Ignition Cut-off
................................................System .
193
36
37
37
38
39
39
40
41
43
46
47
48
51
52
36
Safe Riding Precautions
Basic Operation & Riding
Motorcycle Saf ety
Bef ore Riding
Before riding your motorcycle for the first
time, please review the
section beginning on page 1, and the
section beginning on
page .
Even if you have ridden other motorcycles,
take time to become familiar with how
this motorcycle works and handles.
Practice in a safe area until you build your
skills and get accustomed to the
motorcycle’s size and weight.
Make sure flammable materials such as
dry grass or leaves do not come in contact
with the exhaust system when riding,
idling, or parking your motorcycle.
25
37
Preparation
Starting & Stopping the Engine
Basic Operation & Riding
Always follow the proper starting
procedure described below.
For your safety, avoid starting or operating
the engine in an enclosed area such as a
garage. Your motorcycle’s exhaust
contains poisonous carbon monoxide gas
which can collect rapidly in an enclosed
area and cause illness or death.
Your motorcycle can be started with the
transmission in gear by pulling in the
clutch lever before operating the starter.
Your motorcycle is equipped with a side
stand ignition cut-off system. If the side
stand is down –– the engine cannot be
started unless the transmission is in neutral.
If the side stand is up –– the engine can be
started in neutral, or in gear with the
clutch lever pulled in. After starting with
the side stand down, the engine will stop if
the transmission is put in gear before
raising the side stand.
Before starting, insert the key, turn the
ignition switch ON, and confirm the
following:
The transmission is in neutral (neutral
indicator is ON).
The engine stop switch is set to RUN.
The low oil pressure indicator is ON.
The PGM-FI malfunction indicator
lamp (MIL) is OFF.
The high coolant temperature indicator
is OFF.
The ABS indicator light is ON.
(VT750C ABS)
38
Starting Procedure
Starting & Stopping the Engine
Basic Operation & Riding
The engine will not start if the throttle is
fully open (because the electronic control
module cuts off the fuel supply).
Any Air Temperature
Snapping the throttle or fast idling for
more than about 5 minutes may cause
exhaust pipe discoloration.
The low oil pressure indicator should go
off a few seconds after the engine starts.
If the low oil pressure indicator lights
during operation, stop the engine
immediately and check the engine oil level.
This motorcycle has a fuel-injected engine
with an automatic choke. Follow the
procedure indicated below.
With the throttle completely closed,
press the start button.
1.
−
39
Flooded Engine Bank Angle Sensor Ignition
Cut-off System
Starting & Stopping the Engine
Basic Operation & Riding
If
Your Engine Quits or Won’t Start,
If the engine fails to start after repeated
attempts, it may be flooded with excess
fuel. To clear a flooded engine:
Leave the engine stop switch set to
RUN.
Open the throttle fully.
Press the start button for 5 seconds.
Follow the normal starting procedure.
If the engine starts, open the throttle
slightly if idling is unstable.
If the engine does not start, wait 10
seconds, then follow steps again.
Your motorcycle’s banking (lean angle)
sensor system is designed to automatically
stop the engine and fuel pump if the
motorcycle is overturned.
Before restarting the engine, you must
turn the ignition switch to the OFF
position and then back to ON. The engine
will not restart until you perform this
procedure.
If the engine still won’t start, refer to
page .
1.
4.
5.
2.
3.
1 4
149
40
How to Stop the Engine
Starting & Stopping the Engine
Basic Operation & Riding
Normal Engine Stop
To stop the engine, shift into neutral and
turn the ignition switch OFF.
The engine stop switch should normally
remain in the RUN position even when the
engine is OFF.
If your motorcycle is stopped with the
engine stop switch OFF and the ignition
switch ON, the headlight and taillight
will remain on, resulting in battery
discharge.
Emergency Engine Stop
To stop the engine in an emergency, use
the engine stop switch. To operate, press
the switch to the OFF position.
42
Shifting Gears
Basic Operation & Riding
Shif ting Up:
Shif ting Down:
Avoid downshifting to help slow your
motorcycle when engine rpm is high.
Downshifting when engine speed is
near its allowable maximum may over-
rev the engine and cause possible
damage.
To prevent transmission damage, do not
coast or tow the motorcycle for long
distances with the engine off.
Recommended Shift Points
Ride in the highest gear that lets the
engine run and accelerate smoothly. This
will give you good fuel economy and
effective emissions control. When
changing gears under normal conditions,
use these recommended shift points:
From 1st to 2nd:
From 2nd to 3rd:
From 3rd to 4th:
From 4th to 5th:
12 mph (20 km/h)
19 mph (30 km/h)
25 mph (40 km/h)
31 mph (50 km/h)
From 5th to 4th:
From 4th to 3rd:
28 mph (45 km/h)
22 mph (35 km/h)
Pull the clutch lever in when speed drops
below 15 mph (24 km/h), when engine
roughness is evident, or when engine
stalling is imminent; and shift down to 1st
gear for acceleration.
43
Braking
Basic Operation & Riding
Your motorcycle is equipped with a
hydraulically activated disc brake in front
and a mechanically activated drum brake
at the rear. Operating the brake lever
applies the front disc brake. Depressing
the brake pedal applies the rear drum
brake.
Your motorcycle is equipped with a
Combined Braking System. Operating the
front brake lever applies the front brake.
Operating the rear brake pedal applies the
rear brake and a portion of the front brake.
For full braking effectiveness, use both
the lever and pedal simultaneously, as you
would with a conventional motorcycle
braking system.
This model is also equipped with an Anti-
lock Brake System (page ).
(VT750C) (VT750C ABS)
46
44
Braking
Basic Operation & Riding
Gradually increase braking as you feel the
brakes slowing your speed. The increase
in engine compression from downshifting
will help slow your motorcycle.
To prevent stalling the engine, pull the
clutch lever in before coming to a
complete stop. For support, put your left
foot down first, then your right foot when
you have finished braking.
Applying the brakes too hard may cause
the wheels to lock and slide, reducing
control of your motorcycle. If this happens,
release the brake controls, steer straight
ahead until you regain control, then
reapply the brakes more gently.
As a general rule, the front braking system
provides about 70 percent of total stopping
power.
For full braking effectiveness, use both
the pedal and lever simultaneously. Using
both braking systems will stop your
motorcycle faster with greater stability.
To slow or stop, apply the brake lever and
brake pedal smoothly, while downshifting
to match your speed.
45
Braking
Basic Operation & Riding
When possible, reduce your speed or
complete braking before entering a turn.
Avoid braking or closing the throttle
quickly while turning. Either action may
cause one or both wheels to slip and
reduce your control of your motorcycle.
Your ability to brake in a turn and to brake
hard in an emergency situation are
important riding skills. We suggest
attending a Motorcycle Safety Foundation
experienced rider training course
(page ) to retain these skills.
When descending a long, steep grade, use
engine compression braking by
downshifting, with intermittent use of
both brakes. Continuous brake application
can overheat the brakes and reduce their
effectiveness.
Riding with your foot resting on the brake
pedal or your hand on the brake lever may
actuate the brakelight, giving a false
indication to other drivers. It may also
overheat the brakes, reducing
effectiveness.
When riding in wet or rainy conditions, or
on loose surfaces, the ability to maneuver
and stop will be reduced. All of your
actions should be smooth under these
conditions. Rapid acceleration, braking or
turning may cause loss of control.
For your safety, exercise extreme caution
when braking, accelerating or turning.
28
−
46
Anti-lock Brake System (ABS)
Braking
Basic Operation & Riding
This model is also equipped with an Anti-
lock Brake System (ABS) designed to help
prevent wheel lock up during hard braking
on uneven or other poor surfaces while
running straight. Although the wheel may
not lock up if you are braking too hard
in a turn the motorcycle can still lose
traction, causing a loss of control.
In some situations, a motorcycle with ABS
may require a longer stopping distance to
stop on loose or uneven surfaces than an
equivalent motorcycle without ABS.
ABS cannot make up for road conditions,
bad judgment, or improper operation of
the brakes. It is still your responsibility to
ride at reasonable speeds for weather, road
surface, and traffic conditions, and to
leave a margin of safety.
ABS is self-checking and is always on.
ABS may be activated by riding over a
sharp drop or rise in the road level.
It is important to follow the tire
recommendations (page ). The ABS
computer works by comparing wheel
speed. Non-recommended tires can affect
wheel speed and may confuse the ABS
computer.
ABS does not function at low speeds
(approximately 6 mph (10 km/h) or
below).
ABS does not function if the battery is
discharged.
128
(VT750C ABS)
48
Parking
Basic Operation & Riding
Catalytic
Converters
Look for a level parking area. If you
can’t park on a paved surface, make
sure the ground surface is firm,
especially under the side stand.
If you must park on a hill, leave the
transmission in gear and position the
rear tire against the curb at a 45 degree
angle.
To lower the side stand, use your foot
to guide it down. Remember that
lowering the side stand with the
transmission in gear will stop the
engine, even if the clutch lever is
pulled in. That is a function of the
side stand ignition cut-off system.
Check that the side stand is down all
the way so that the side stand ignition
cut-off system (page ) is activated.
If you have to park on a soft surface,
insert something solid under the side
stand for support.
Use the side stand to support the
motorcycle while parked.
Make sure flammable materials such as
dry grass or leaves do not come in contact
with the exhaust system when parking
your motorcycle. Refer to
, page .
1. 2.
37
201
51
Theft-prevention Tips
Parking
Basic Operation & Riding
If you decide to use an anti-theft device,
select one of good quality and be sure to
follow the manufacturer’s instructions.
Park your motorcycle in a locked
garage whenever possible. If a garage
isn’t available, park in a concealed area
or in a well-lit area with enough
pedestrian traffic to discourage a thief.
Always take the ignition key with you.
Always use the steering lock (page ),
even if you’re parking for just a minute
or two. A thief can easily push an
unlocked motorcycle to a waiting truck.
In addition to the steering lock, use a
good quality anti-theft device made
specifically to lock a motorcycle to a
secure object.
Keep your owner’s manual, current
registration, and insurance information
with your motorcycle. This will make it
easier for the authorities to find you if
your motorcycle is stolen and recovered.
49
52
Riding with a Passenger or Cargo
Basic Operation & Riding
Load Limits,
Loading Guidelines,
Your motorcycle is designed to carry you
and one passenger. Whenever you add a
passenger or cargo, you must be careful
not to exceed the total load limits for this
vehicle ( page ). Make
sure your cargo is properly secured
( page ).
Also consider adjusting the suspension
(page ) for the extra load.
Be aware that carrying a passenger or
heavy cargo can affect acceleration,
braking, and handling.
Before riding with a passenger, make sure
your passenger is wearing the proper
protective apparel (page ).
Tell your passenger to hold the seat strap
or your waist, lean with you in the turns,
and keep their feet on the passenger
footpegs at all times, even when the
motorcycle is stopped at a traffic light.
33
110
33
26
53
Servicing Your Honda
Servicing Your Honda
Maintenance, replacement or repair of
the emission control devices and
systems may be performed by any
motorcycle repair establishment or
individual using parts that are
‘‘certified’’ to EPA standards.
Bef ore You Service Your Honda
To help keep your motorcycle in good
shape, this section includes a Maintenance
Schedule for required service, a list of
periodic checks you should perform at
least once a month, and step-by-step
instructions for specific maintenance tasks.
You’ll also find important safety
precautions, information on fuels and oils,
and tips for keeping your Honda looking
great.
For information about the exhaust
emission and noise emission requirements
of the U.S. Environmental Protection
Agency (EPA), the California Air
Resources Board (CARB), and
Environment Canada (EC), see page .
(cont’d)
USA only
............The Importance of Maintenance .
................................Maintenance Safety .
.............Important Safety Precautions .
.............................Periodic Maintenance .
...........................Maintenance Schedule .
...............................Maintenance Record .
For information about replacing fuses, see
page .172
194
56
57
58
60
62
67
54
Servicing Your Honda
Servicing Your Honda
Service Procedures
Service Preparations Engine
Fluids & Filters
......Maintenance Component Locations .
...................................................Tool Kit .
...............................Side Cover Removal .
.........................................................Fuel .
.................................Engine Oil & Filter .
....................................................Coolant .
.............................................Air Cleaner .
................................Crankcase Breather .
........................................Final Drive Oil .
........................Owner’s Manual Storage .
.............................Storage Compartment .
..........................................Seat Removal .
...............................................Throttle .
.....................................Clutch System .
.........................................Spark Plugs .
Chassis
..........................................Suspension .
.................................................Brakes .
....................................................Tires .
...........................................Side Stand .
Electrical
................................................Battery .
................................Appearance Care .
69
72
73
74
75
76
77
80
90
94
96
97
100
102
106
130
135
109
112
121
129
＊
＊＊
＊
＊＊
55
Servicing Your Honda
Servicing Your Honda
The following table summarizes the three types of inspections and servicing
recommendations for your motorcycle. Both the pre-ride inspection and the scheduled
maintenance at the recommended intervals are necessary to assure safe and dependable
performance. The periodic checks provide additional confidence in your motorcycle’s
performance.
more often if you ride frequently or long distances; or anytime you clean your motorcycle
unless you have the proper tools and service data and are mechanically qualified
Type of Inspection/Service
Maintenance Schedule
Periodic Maintenance
Pre-ride Inspection
Refer to page:
interval on schedule
monthly
before every ride
your dealer
you
you
Who PerformsWhen Performed
29
60
62
Failure to properly follow
maintenance instructions and
precautions can cause you to be
seriously hurt or killed.
Always follow the procedures and
precautions in this owner’s
manual.
57
Maintenance Safety
Servicing Your Honda
This section includes instructions on how
to perform some important maintenance
tasks. If you have basic mechanical skills,
you can perform many of these tasks with
the tools provided with your motorcycle.
Other tasks that are more difficult and
require special tools are best performed by
professionals. Wheel removal should
normally be handled only by a Honda
technician or other qualified mechanic.
Instructions are included in this manual
only to assist in emergency service.
Some of the most important safety
precautions follow. However, we cannot
warn you of every conceivable hazard that
can arise in performing maintenance. Only
you can decide whether or not you should
perform a given task.
58
Important Safety Precautions
Maintenance Safety
Servicing Your Honda
Carbon monoxide poisoning from
engine exhaust.
Burns from hot motorcycle parts.
Injury from moving parts.
Read the instructions before you begin,
and make sure you have the tools and
skills required.
To help prevent the motorcycle from
falling over, park it on a firm, level
surface, using the side stand or a
maintenance stand to provide support.
To reduce the possibility of a fire or
explosion, be careful when working
around gasoline. Use only
non-flammable solvent, not gasoline, to
clean parts. Keep cigarettes, sparks, and
flames away from all fuel-related parts.
Make sure the engine is off before you
begin any maintenance or repairs. This
will help eliminate several potential
hazards:
Be sure there is
adequate ventilation whenever you
operate the engine.
Let
the engine and exhaust system cool
before touching.
Do not run
the engine unless instructed to do so.
59
Maintenance Safety
Servicing Your Honda
Remember that your Honda dealer knows
your motorcycle best and is fully equipped
to maintain and repair it. To ensure the
best quality and reliability, use only new
Honda Genuine Parts or their equivalents
for repair and replacement. If you have the
tools and skills required for additional
maintenance jobs, you can purchase an
official Honda Service Manual
(page ).206
61
Periodic Maintenance
Servicing Your Honda
Fluids
Fuses Make sure you have a full supply of spare fuses.
Check the major fasteners and tighten as needed.Nuts & Bolts
Check the air pressure with a gauge and add air if needed (page ).
Examine the tread for wear (page ).
Look closely for nails, embedded objects, cuts, and other types of
damage (page ). Roll your motorcycle so you can inspect the
entire surface.
Check the condition of the rims and spokes.
Check the levels of the engine oil (page ), coolant (page ),
brake fluid (page ), and final drive oil (page ). Add the
correct fluid as necessary, and investigate the cause of any low fluid
level.
Check the freeplay of the clutch lever (page ), rear brake pedal
(page ), and throttle grip (page ).
Freeplay
Make sure the headlight, brakelight, taillight, and turn signals are
working properly.
Lights
Tires
&
Wheels
84 91
97
102
100
113
121
123
123
117
62 Servicing Your Honda
Maintenance Schedule
The required Maintenance Schedule that
follows specifies how often you should
have your motorcycle serviced, and what
things need attention. It is essential to have
your motorcycle serviced as scheduled to
maintain safe, dependable performance
and proper emission control.
Some items in the Maintenance Schedule
can be performed with basic mechanical
skills and hand tools. Procedures for these
items are provided in this manual. Other
items involve more extensive procedures
and may require special training, tools,
and equipment. We recommend that you
have your dealer perform these tasks
unless you have advanced mechanical
skills and the required tools and equipment.
Procedures for such items in this schedule
are provided in an official Honda Service
Manual available for purchase (page ).
The service intervals in this Maintenance
Schedule are based on average riding
conditions. Some items will need more
frequent service if you ride in unusually
wet or dusty areas or at full throttle.
Consult your dealer for recommendations
applicable to your individual needs and
use.
206
＊ ＊＊
＊
＊＊
63
Maintenance Schedule
Servicing Your Honda
If you do not feel capable of performing a
given task or need assistance, remember
that your Honda dealer knows your
motorcycle best and is fully equipped to
maintain and repair it. If you decide to do
your own maintenance, use only Honda
Genuine Parts or their equivalents for
repair or replacement to ensure the best
quality and reliability.
Perform the pre-ride inspection (page )
and owner maintenance (page ) at each
scheduled maintenance period.
Each item on the maintenance schedule
requires some mechanical knowledge.
Certain items (particularly those marked
and ) may require more technical
information and tools. Consult your dealer.
Should be serviced by your dealer,
unless you have the proper tools and
service data and are mechanically
qualified. Refer to the official Honda
Service Manual (page ).
In the interest of safety, we recommend
these items be serviced only by your
dealer.
29
62
206
64 Servicing Your Honda
Maintenance Schedule
Summary of Maintenance Schedule Notes
& Procedures:
At higher odometer readings, repeat at
the frequency interval established here.
Service more frequently if the
motorcycle is ridden in unusually wet or
dusty areas.
Maintenance Procedures:
I: inspect and clean, adjust, lubricate,
or replace, if necessary
C: clean
A: adjust
L: lubricate
R: replace
Service more frequently if the
motorcycle is ridden often at full
throttle or in the rain.
Replace every 2 years, or at indicated
odometer interval, whichever comes
first. Replacement requires mechanical
skill.
California type only.
NOTES:
1.
2.
3.
4.
5.
×
×
−
−
−
−
−
−
＊
＊
＊
＊
＊
＊
＊
1,000 mi
1,000 km
Refer to
page
94
96
106
80
85
90
FUEL LINE
THROTTLE OPERATION
AIR CLEANER
CRANKCASE BREATHER
SPARK PLUGS
VALVE CLEARANCE
ENGINE OIL
ENGINE OIL FILTER
RADIATOR COOLANT
COOLING SYSTEM
SECONDARY AIR SUPPLY
SYSTEM
EVAPORATIVE EMISSION
CONTROL SYSTEM
NOTE
2
3
4
5
4
6.4
C
I
12
19.2
R
C
I
I
16
25.6
I
I
C
R
I
R
I
I
I
20
32.0
C
I
24
38.4
I
I
R
C
R
I
R
R
I
I
I
8
12.8
I
I
C
R
I
R
I
I
I
0.6
1.0
I
R
INITIAL = 600 mi (1,000 km) or 1 month: R
REGULAR = EVERY 8,000 mi (12,800 km)
or 12 months: R
ODOMETER READING (Note 1)
ITEM
FREQUENCY
EMISSIONS-RELATED ITEMS
65
Servicing Your Honda
Maintenance Schedule
Should be serviced by your dealer, unless you have the proper tools and service data and are mechanically
qualified. Refer to the official Honda Service Manual (page ).206
67
Maintenance Record
Servicing Your Honda
Miles (km) Odometer Date Performed By: Notes
Keeping an accurate maintenance record will help ensure that your motorcycle is properly
maintained. Retain detailed receipts to verify the maintenance was performed. If the
motorcycle is sold, these receipts should be transferred with the motorcycle to the new owner.
Make sure whoever performs the maintenance completes this record. All scheduled
maintenance, including the 600 mile (1,000 km) initial maintenance, is considered a normal
owner operating cost and will be charged for by your dealer. Use the space under Notes to
record anything you want to remind yourself about or mention to your dealer.
600 (1,000)
4,000 (6,400)
8,000 (12,800)
12,000 (19,200)
16,000 (25,600)
20,000 (32,000)
fuel fill cap
front brake fluid reservoir
throttle grip
clutch lever front brake lever
69
Servicing Your Honda
Maintenance Component Locations
spark plugs
rear brake pedal
front brake caliper
rear suspension
spring pre-load
adjuster
air cleaner
crankcase breather tube
owner’s manual
battery
rear brake fluid reservoir
(VT750C ABS)
main fuse
(VT750C)
fuse box
FI fuse
(VT750C)
engine oil fill cap/dipstick
70 Servicing Your Honda
Maintenance Component Locations
(1)
(1) tool kit (2) storage compartment
(2)
(2)
(1)
LEFT SIDE (VT750C)
LEFT SIDE (VT750C ABS)
72
Tool Kit
Servicing Your Honda
The tool kit ( ) is stored in the storage
compartment ( ) (page ) behind the
left side cover (page ).
An optional, larger tool kit may be
available. Check with your dealer’s parts
department.
1
2 74
75
(1)
LEFT SIDE
(4)
(3)
(2)
(1) storage compartment
(2) tool kit
(3) ignition key
(4) storage compartment lid
74
Storage Compartment
Servicing Your Honda
The storage compartment ( ) is located
behind the left side cover (page ).
To open the storage compartment, remove
the left side cover (page ). Insert the
ignition key ( ) and turn it 90 degrees
counterclockwise. Open the storage
compartment lid ( ).
To close the storage compartment, close
the storage compartment lid. Turn the
ignition key 90 degrees clockwise and
remove it. Install the left side cover
(page ).
The tool kit ( ) should be stored in the
storage compartment.
75
75
75
2
1
3
4
(VT750C)
(1) side cover
(1)
LEFT SIDE
75
Side Cover Removal
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
The right side cover must be removed to
service the fuses.
The left side cover must be removed to
access the storage compartment and check
the color label.
Push the cover in place.
Position the cover so the prongs on the
inside of the cover are line up above
their securing slots.
Installation
Grasp the side cover ( ).
Removal
The right and left side covers can be
removed in the same manner.
The left side cover must be removed to
access the storage compartment, to service
the fuses, or to check the color label.
Pull out.
1.
2.
1.
2.
58
1
(VT750C)
(VT750C ABS)
3.70 US gal (14.0 )
(3)
(2)
(1)
(1) ignition key
(2) fuel fill cap
(3) filler neck
78
Refueling Procedure
Fuel Capacity
Fuel
Servicing Your Honda
Saf ety Precautions
Never use stale or contaminated gasoline
or an oil/gasoline mixture. Avoid getting
dirt, dust, or water in the fuel tank.
Refer to on page .
Insert the ignition key ( ) in the fuel
fill cap ( ) and turn it clockwise.
The tank should be refilled as soon as
possible when the fuel reserve indicator
comes on.
Fuel tank capacity:
1.
58
1
2
Gasoline is highly flammable and
explosive. You can be burned or
seriously injured when handling
fuel.
Stop the engine and keep heat,
sparks and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
79
Fuel
Servicing Your Honda
Open the cap.
Add fuel until the level reaches the
bottom of the filler neck ( ). Avoid
overfilling the tank. There should be no
fuel in the filler neck.
After refueling, align the latch in the
cap with the slot in the filler neck. Push
the cap into the filler neck until it snaps
and locks.
Remove the ignition key from the cap.
2.
3.
5.
4.
3
80
Engine Oil & Filter
Servicing Your Honda
Engine oil quality is a major factor that
affects both the performance and the
service life of the engine.
When running in very dusty conditions, oil
changes should be performed more
frequently than specified in the
maintenance schedule.
Using the proper oil (page ) and filter,
and regularly checking, adding, and
changing oil will help extend your
engine’s life. Even the best oil wears out.
Changing oil helps get rid of dirt and
deposits in the engine. Operating the
engine with old or dirty oil can damage
your engine. Running the engine with
insufficient oil can cause serious damage
to the engine and transmission.
Change the engine oil as specified in the
maintenance schedule on page .65
81
−
−
RIGHT SIDE
(2)
(1)
(3)
(3) lower level mark
(1) oil fill cap/dipstick
(2) upper level mark
84
Checking & Adding Oil
Engine Oil & Filter
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Hold the motorcycle in an upright
position.
Remove the oil fill cap/dipstick ( ) and
wipe it clean.
Stop the engine and wait 2 3 minutes.
Start the engine and let it idle for 3 5
minutes. Make sure the low oil pressure
indicator goes off. If the indicator
remains on, stop the engine
immediately.
Park your motorcycle on its side stand
on a firm, level surface.
Insert the oil fill cap/dipstick until it
seats, but don’t screw it in.
2.
3.
4.
5.
6.
1.
58
1
85
Changing Engine Oil & Filter
Engine Oil & Filter
Servicing Your Honda
Saf ety Precautions
Using the wrong oil f ilter may result in
leaks or engine damage.
Refer to on page .
Your motorcycle’s oil filter has very
specific performance requirements. Use a
new Honda Genuine oil filter or a filter of
equal quality specified for your model.
If the oil is at or near the upper level
mark ( ) –– you do not have to add
oil.
If the oil is below or near the lower
level mark ( ) –– add the
recommended oil until it reaches the
upper level mark. (Do not overfill.)
Reinstall the oil fill cap/dipstick.
Check for oil leaks.
Remove the oil fill cap/dipstick and
check the oil level.
7.
8.
9.
2
3
58
(3)
(3) oil filter
RIGHT REAR, UNDER ENGINE
87
Engine Oil & Filter
Servicing Your Honda
Install a New Oil Filter:
Improper disposal of drained f luids is
harmf ul to the environment.
Remove the oil filter ( ) with a filter
wrench and let the remaining oil drain
out. Discard the oil filter in an approved
manner (page ).
(cont’d)
Pour the drained oil into a suitable
container and dispose of it in an
approved manner (page ).
5.
6.
3
146
146
Removing the radiator cap while
the engine is hot can cause the
coolant to spray out, seriously
scalding you.
Always let the engine and radiator
cool down before removing the
radiator cap.
93
Coolant
Servicing Your Honda
You & the Environment,
Improper disposal of drained f luids is
harmf ul to the environment.
To properly dispose of drained coolant,
refer to
page .146
101
Throttle Inspection
Throttle
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Check that the throttle assembly is
positioned properly and the securing
bolts are tight.
Check for smooth rotation of the
throttle from fully open to fully closed
in all steering positions. If there is a
problem, see your dealer.
1.
2.
58
Produkt Specifikationer
| Mærke: | Honda |
| Kategori: | Motor |
| Model: | Shadow Aero VT750CLB (2011) |
Har du brug for hjælp?
Hvis du har brug for hjælp til Honda Shadow Aero VT750CLB (2011) stil et spørgsmål nedenfor, og andre brugere vil svare dig
Motor Honda Manualer
8 Januar 2025
8 Januar 2025
2 Januar 2025
31 December 2025
31 December 2025
31 December 2025
14 December 2024
13 Oktober 2024
3 Oktober 2024
3 Oktober 2024
Motor Manualer
- Derbi
- Joy-It
- Bajaj
- Reebok
- Moto Guzzi
- Indian
- Texas
- Beta
- GasGas
- CRRCpro
- Husqvarna
- Danfoss
- Hero
- Sherco
- Juki
Nyeste Motor Manualer
15 Januar 2025
10 Januar 2025
31 December 2025
30 December 2025
30 December 2025
30 December 2025
29 December 2024
4 December 2024
15 Oktober 2024
15 Oktober 2024
