Side 1/6

Models 7222, 7224, 7322 & 7324

FIRE RESISTANT VERTICAL FILE CABINETS

Read this manual carefully and never store it inside the cabinet!

Models 7222, 7224, 7322 & 7324

FIRE RESISTANT VERTICAL FILE CABINETS

Note: During shipment, the gypsum insulation of your Honeywell file

cabinet may create a film of dust on the exterior and interior of the file.

This is a normal settling process. Simply wiping the cabinet and drawers

with a damp cloth will remove the dust. Honeywell files are asbestos free.

PACKAGE CONTENTS

1 – Vertical File Cabinet

1 – Operation Manual

2 – Entry Keys

For missing parts or difficulty operating your

cabinet, please contact our Consumer

Assistance Department by telephone.

US/Canada 1-877-354-5457 (Toll Free)

Australia 0011-800-5325-7000 (Toll Free)

Germany 00-800-5325-7000 (Toll Free)

IMPORTANT: DO NOT RETURN CABINET TO STORE!

Store will not accept returned products without prior authorization. You must

first contact our consumer assistance department.

CABINET SERIAL NUMBER

Whenever contacting our Consumer Assistance Department, you will need to

provide them with the serial number of your cabinet.

The serial number tag is located on the

lower right front corner of the cabinet.

IMPORTANT: Do Not Remove Tags!

These are needed if you lose your keys.

UNPACKING & MOVING CABINET

CAUTION! Honeywell file cabinets and drawers are heavy! For safety

always use proper moving equipment and padding when moving cabinets.

Remove Cabinet from the Pallet

1. Remove rubber stops from the front and sides of the pallet.

2. Spin the cabinet to set sideways across the pallet.

3. Slide the cabinet so that the back of the cabinet will tilt and rest on the floor.

4. Push back on the front of the cabinet to raise front of the bottom of the

pallet.

5. Slide pallet out of the way and set cabinet on the floor

Moving The File Into Place

x Do not use the file’s handle to lift or move the file; damage to the latching

system may result.

x For the lock to function properly, the file must be leveled from side to side

and front to back. Place shims at the bottom corners of the file as

necessary to level the file.

x Moving Honeywell file cabinets into position may be facilitated by removing

the drawers.

DRAWER REMOVAL & INSTALLATION

IMPORTANT: Drawers are very heavy. Two or more persons are required

when handling the drawers. Note that each drawer has a drawer number decal

on the right side of the drawer. Drawers are numbered from top to bottom and

each must be replaced in the same cavity from which it was removed.

Fig. 1 .

DRAWER REMOVAL & INSTALLATION CONTINUED

To Remove Drawers

1. Extend drawer fully out.

2. Grasp front of drawer on each side and lift to release front tabs of slides

from drawer. (Fig. 1)

3. Place one hand underneath the drawer for support and pull one slide

forward to release the rear tab.(Fig. 1), repeat for other slide

4. Holding drawer head with both hands, pull drawer clear of slides and out of

cavity.

5. Push suspensions and stabilizers back into the drawers

To Install Drawers

1. Pull suspensions and stabilizers out until they are fully extended.

2. Place drawer into opening in between slides and align rear tab of slide with

the appropriate notch and insert.

3. Pull drawer forward until front tabs are aligned, insert front tabs

4. Close drawer and check for free movement and equal gap on both sides of

drawer.

If necessary, lightly loosen stabilizer screws and move drawer in direction of

excessive gap. Tighten screws and recheck gap.

LOCKING & UNLOCKING DRAWERS

Do not attempt to close drawer when the lock bolt is extended; damage to

cabinet and/or lock may result.

To Lock

1. Make sure all drawers are

closed before locking

2. Push the lock plunger in until

it snaps into place.

To Unlock

1. Insert key into lock.

2. Turn to the right or left until

the plunger pops out.
