Hotpoint Ariston LDF 12314 X EU/HA.R Manual

Hotpoint Ariston Opvaskemaskine LDF 12314 X EU/HA.R

Læs gratis den danske manual til Hotpoint Ariston LDF 12314 X EU/HA.R (36 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 14 personer og har en gennemsnitlig bedømmelse på 3.9 stjerner ud af 7.5 anmeldelser. Har du et spørgsmål om Hotpoint Ariston LDF 12314 X EU/HA.R, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/36

Operating instructions

Contents

Installation, 2-3

Positioning and levelling

Connecting the water and electricity supplies

Advice regarding the first wash cycle

Technical data

Description of the appliance, 4

Overall view

Control panel

Loading the racks, 5

Lower rack

Cutlery basket

Upper rack

Start-up and use, 6-7

Starting the dishwasher

Measuring out the detergent

Wash options

Wash cycles, 8

Table of wash cycles

Rinse aid and refined salt, 9

Measuring out the rinse aid

Measuring out the refined salt

Care and maintenance, 10

Shutting off the water and electricity supplies

Cleaning the dishwasher

Preventing unpleasant odours

Cleaning the sprayer arms

Cleaning the water inlet filter

Cleaning the filters

Leaving the machine unused for extended periods

Precautions, advice and Assistance,11

General safety

Disposal

Saving energy and respecting the environment

Assistance

Troubleshooting, 12

English,1

LDF 12314

DISHWASHER

Français, 13

Español, 49

Deutsch, 25

Português, 61

Polski, 73

Nederland, 37

Installation

Keep this instruction manual in a safe place for future

reference. If the appliance is sold, given away or moved,

please ensure the manual is kept with the machine, so that the

new owner may benefit from the advice contained within it.

Please read this instruction manual carefully: it contains

important information regarding the safe installation, use and

maintenance of the appliance.

If the appliance must be moved at any time, keep it in an

upright position; if absolutely necessary, it may be tilted onto

its back.

Positioning and levelling

1. Remove the appliance from all packaging and check that it

has not been damaged during transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Check the dishwasher by placing it so that its sides or back

panel are in contact with the adjacent cabinets or even with the

wall. This appliance can also be recessed under a single

worktop* (see the Assembly instruction sheet).

3. Position the dishwasher on a level and sturdy floor. If the

floor is uneven, the front feet of the appliance may be adjusted

until it reaches a horizontal position. If the appliance is levelled

correctly, it will be more stable and much less likely to move or

cause vibrations and noise while it is operating.

4.* Adjust the height of the rear foot from the front of the

appliance* on the central lower part of the dishwasher, turning

a hexagonal spanner (red color) with an opening of 8 mm in a

clockwise direction to increase the height or in an

anticlockwise direction to decrease the height.

Connecting the water and electricity

supplies

Connection to the water and electricity supplies should

only be performed by a qualified technician.

The dishwasher should not stand on top of the water

hoses or the electricity supply cable.

The appliance must be connected to the water supply

network using new hoses.

Do not use old hoses.

The water inlet (A) and outlet (B) hoses and the electricity

supply cable may be positioned towards the right or the left in

order to achieve the best possible installation (see figure).

Connecting the water inlet hose

 To a suitable cold water connection point: before attaching

the hose, run the water until it is perfectly clear so that any

impurities that may be present in the water do not clog the

appliance; after performing this operation, screw the inlet

hose tightly onto a tap with a ¾ gas threaded connection.

 To a suitable hot water connection point: your dishwasher

may be supplied with hot water from the mains supply (if

you have a central heating system with radiators) provided

that it does not exceed a temperature of 60°C.

Screw the hose to the tap as described for connection to a

cold water supply.

If the inlet hose is not long enough, contact a specialist

store or an authorised technician (see Assistance).

The water pressure must be within the values indicated in

the Technical data table (see adjacent information).

The hose should not be bent or compressed.

Anti-flooding protection

To ensure floods do not occur, the dishwasher:

- is provided with a special system which blocks the water

supply in the event of anomalies or leaks from inside the

appliance.

Some models are also equipped with the supplementary

safety device New Acqua Stop*, which guarantees anti-

flooding protection even in the event of a supply hose rupture.

WARNING: HAZARDOUS VOLTAGE!

Under no circumstance should the water inlet hose be cut as it

contains live electrical parts.

* Only available in selected models.

Produkt Specifikationer

Mærke:	Hotpoint Ariston
Kategori:	Opvaskemaskine
Model:	LDF 12314 X EU/HA.R
Bredde:	600 mm
Dybde:	600 mm
Højde:	850 mm
Skærmtype:	LCD
Energieffektivitetsklasse (gammel):	A
Årligt energiforbrug:	238 kWh
Placering af apparat:	Fritstående
Støjniveau:	42 dB
Antal vaskeprogrammer:	12
Forsinket start-timer:	Ja
Dør farve:	Rustfrit stål
Vaskeklasse:	A
Vandforbrug pr. cyklus:	13 L
Antal kuverter:	14 kuverter
Cyklustid:	155 min.
Forsinket start (maks.):	24 t
Tørringsklasse:	A
Årligt vandforbrug:	2860 L
Energiforbrug pr. cyklus:	1.08 kWh
Integreret timer:	Ja
Quick wash:	Ja
