ENQuick Guide

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance, please register

your appliance on: www.hotpoint.eu/register

Before using the appliance carefully read Safety Instructions

guide.

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 1 kg); it is not unu-

sual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently prevent-

ing scale buildup on heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per Eco cycles with water hardness level set to . 6 3

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser Ashould be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the ap-

pliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device . Introduce the C

detergent into the dry dispenser only. Place the amount of detergent for D

pre-washing directly inside the tub.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved Usage of detergent not designed for dishwashers

may cause malfunction or damage to the appliance.

CONTROL PANEL

FIRST TIME USE

PROGRAMS TABLE

1. On-O/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet (Tab) indicator light

7. Display

8. 3D Zone Wash indicator lights

9. 3D Zone Wash button

10. Delay button

11. START/Pause button with indicator light

/ Tablet (Tab)

1 2 3 4 5 6 7 8 9 10

Program Programs description

Drying

phase

ActiveDry

Available options

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Eco program is suitable to clean normally soiled table-

ware. that for this use. it is the most ecient program in terms of

its combined energy and water consumption. and that it is used to

assess compliance with the EU Ecodesign legislation.

3:10 9,5 0,75

Auto Intensive 65° - Automatic program for heavily soiled dishes

and pans (not to be used for delicate items).

2:00 - 3:10 14,0 - 17,0 1,50 - 1,85

Auto Mixed 55° - Automatic program for normally soiled pans and

dishes.

1:30 - 2:30 14,5 - 16,0 1,15 - 1,30

Auto Fast Wash 50° - Automatic program for limited quantity of

normally soiled crockery. Ensures optimal cleaning performance in

shorter time.

- -

0:55 - 1:20 13,0 - 14,5 1,15 - 1,25

Rapid 30’ 45° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Does not have drying phase.

0:30 9,0 0,50

Silent - 50° Suitable for night-time operation of the appliance.

With the lowest noise.

3:30 15,0 1,15

Sanitizing - 65° Normally or heavily soiled crockery, with addi-

tional antibacterial wash. Can be used to perform maintenance of

the dishwasher.

1:40 10,0 1,30

Soak - Use to refresh crockery planned to be washed later.

No detergent to be used with this program.

0:12 4,5 0,01

Self- Clean 65° - Program to be used to perform maintenance ofthe

dishwasher, to be carried out only when the dishwasher is EMPTY

using specic detergents designed for dishwasher maintenance.

0:50 8,0 0,85

Quick Guide

TABLET (Tab) If you use powder or liquid detergent, this option -

should be o.

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

3D ZONE WASH - Option works with one rack at once. In particular,

we recommend to use it with Mixed and Intensive cycles - thanks to

the additional 3D water jets placed on the bottom o the cavity,

3D ZONE WASH option allows to save energy or to increase the washing

performance of the dishwasher.

OPTIONS AND FUNCTIONS

Please scan the on your product in order to have more detailed information. QR code

ActiveDry - is a convection drying system which automatically opens the

door during/after the drying phase to ensure exceptional drying perfor-

mance every day. The door opens at a temperature that is safe to your kitch-

en furniture.

DELAY - The start time of the program may be delayed for a period of

time between and hours.1 12

The DELAY function cannot be set once a program has been started.

UPPER RACK

Load delicate and light

dishes: glasses, cups,

saucers, low salad

bowls.

(loading example for the

upper rack)

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc.

Large plates and lids should ideally be placed

at the sides to avoid interferences with the

spray arm.

The lower rack has tip-up supports which can

be used in avertical position when arranging

plates or in a horizontal position (lower) to

load pans and salad bowls easily.

(loading example for the lower rack)

LOADING THE RACKS

CAPACITY: 14 standard place-settings

CUTLERY BASKET

The basket is equipped with top grilles

for improved cutlery arrangement. The

cutlery basket should be positioned

only at the front of the lower rack.

Knives and other utensils with sharp

edges must be placed in the cutlery

basket with the points facing down-

wards or they must be positioned

horizontally in the tip-up compart-

ments on the upper rack.

SLIDING TRAY

The upper rack is tted with

a sliding tray which can be

used to hold small crockery

and cutlery. For optimum

washing performance, avoid

positioning bulky crockery

directly below the tray. The

tray is removable.

ZONE WASH 3D

3D Zone Wash uses addi-

tional water jets located

both: in the lower and up-

per part of the dishwasher

(marked with orange

color) to wash more inten-

sively heavily soiled items

by increasing water cover-

age on dishes.

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)

please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may be

removed by pulling it up-

wards.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.
