Side 1/56

ENDaily Reference Guide

CONTROL PANEL

THANK YOU FOR BUYING A HOTPOINT/ARISTON PRODUCT.

In order to receive a more complete assistance, please

Before using the appliance carefully read Safety

and Installation Instructions. More information about your product

available on website: docs.hotpoint.eu

After installation, please remember to remove all transport protection

parts from the dishwasher.

SETTING MENU

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings (Half Load ) button for 3 seconds until you hear

a beep.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press button to scroll through the list of available settings (see table

below), then press START/Pause to view and change the value of the

currently selected setting.

5. Press to change the value, then press START/Pause to save the

new value.

6. To change another setting, repeat points 2 and 5.

7. Press ON-OFF or wait 30 seconds to exit the menu.

LETTER

SETTING

VALUES

(Default - in bold)

Water Hardness Level

(see “SETTING THE WATER HARDNESS” and

“WATER HARDNESS TABLE”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

ActiveDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included

in the settings menu.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and the

machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the con-

trol panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 0,5 kg); it is not un-

usual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair). Run a program every time as soon as you complet-

ed relling the salt reservoir to avoid corrosion.

Setting the water hardness

To allow the water softener to work in a perfect way, it is essential that the

water hardness setting is based on the actual water hardness in your house.

This information can be obtained from your local water supplier. The facto-

ry setting is “3”. See „WATER HARDNESS TABLE”.

To change, follow instructions in section „SETTING MENU”.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (soft) 0 - 6 0 - 10 0 - 7

2 (medium) 7 - 11 11 - 20 8 - 14

3 (average) 12 - 16 21 - 29 15 - 20

4 (hard) 17 - 34 30 - 60 21 - 42

5 (very hard) 35 - 50 61 - 90 43 - 62

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Use of salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning ef-

ciency. This system regenerates itself with salt, therefore it is required

to rell the salt container when empty. The frequency of regeneration

depends on the water hardness level setting - regeneration takes place

once per 4-6 Eco cycles with the water hardness level set to 3. The regen-

eration process occurs at the beginning of the cycle with additional fresh

water.

• Single regeneration consumes: ~3L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be lled

when the RINSE AID REFILL indicator light in the control panel is lit.

1. Open the dispenser B by

pressing and pulling up the

tab on the lid.

2. Pour in the rinse aid (max. 110

ml), making sure it does not

overow from the dispenser.

If this happens, clean the spill

immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

Adjusting the dosage of rinse aid

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow the instructions in the section „SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 6 levels can be set according to the dishwasher model.

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set a mid-

range number (4-5).

FIRST TIME USE

1. ON-OFF/Reset button with indicator light

2. Eco program button with indicator light

3. Auto Intensive program button with indicator light

4. Auto Mixed program button with indicator light

5. Auto Fast program button with indicator light

6. Rapid program button with indicator light

7. Delicates program button with indicator light

8. Soak program button with indicator light

9. Salt reservoir empty indicator light

10. Rinse Aid reservoir empty indicator light

11. Display

12. Program number and remaining time indicator

13. Closed water tap indicator light

14. DESCALE indicator light

15. 3D Zone Wash option button with indicator light

16. Half Load option button with indicator light/ Settings - 3 sec. press

17. Extra Dry option button with indicator light

18. Silent option button with indicator light/ Key lock - 3 sec. press

19. Sani Rinse option button with indicator light

20. Self-Clean program button with indicator light

21. Delay option button with indicator light

22. START/Pause button with indicator light

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	H7F HS41 X
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	600 mm
Dybde:	590 mm
Højde:	850 mm
Vægt:	47000 g
Kontroltype:	Berøring
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.3 m
Pakkevægt:	49000 g
Pakkedybde:	675 mm
Pakkebredde:	625 mm
Pakkehøjde:	880 mm
Placering af apparat:	Fritstående
Installationsrum dybde:	590 mm
Tilsluttet belastning:	1900 W
Støjniveau:	41 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	8
Forsinket start-timer:	Ja
Vaskeprogrammer:	Forvask
Justerbare fødder:	Ja
Dør farve:	Rustfrit stål
Vaskeklasse:	A
Indikator for LED-programfase:	Ingen
Vandforbrug pr. cyklus:	9.5 L
Bestik rum type:	Skuffe
Farve på kontrolpanel:	Grå
Antal kuverter:	15 kuverter
Cyklustid:	210 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Self-Clean 65°C, Eco 50°C, Soak, Auto-Mixed, Quick, Quick 45min, Intensive 65°C, Delicate 45°C
Halv belastning:	Ja
Tørringsklasse:	A
Indikator for afspændingsmiddel:	Ja
Energieffektivitetsskala:	A til G
Selvrensende:	Ja
AquaSensor funktion:	Ingen
AquaStop funktion:	Ingen
Indikator for resterende tid:	Ja
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Vandpåfyldning:	Cold, Hot
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	C
Energiforbrug pr. 100 cyklusser:	76 kWh
Brugerdefineret panel klar:	Ingen
Temperatur (maks):	65 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Kurves indstillelige placering:	Øvre
Doseringsassistent:	Ingen
Selvrensende filter:	Ingen
Antal kurve:	2 kurv(e)
Automatisk belastningsgenkendelse:	Ingen
Automatisk døråbning:	Ja
Maksimal varmtvandsforsyning temperatur:	60 °C
Ready-indikator:	Ja
Gulvindikatorlys:	Ingen
Fodjusteringstype:	Front
Garantiperiode:	2 År
Aftagelig bestikkurv:	Ja
