Side 1/8

Before using the appliance carefully read Health and Safety guide.

APPLIANCE

PRODUCT DESCRIPTION

1. Upper rack

2. Foldable aps

3. Upper rack height adjuster

4. Upper spray arm

5. Lower rack

6. Cutlery basket

7. Lower spray arm

8. Filter Assembly

9. Salt reservoir

10. Detergent and Rinse Aid dispensers

11. Rating plate

12. Control panel

0000 000 00000

Service:

1011

1 2 3 4 5 6 7 8

1. On-O/Reset button with indicator light

2. Tablet (Tab) button with indicator light

3. Salt rell indicator light

4. Rinse Aid rell indicator light

DAILY REFERENCE

GUIDE

CONTROL PANEL

5. Program selection knob

6. Delay indicator light

7. Delay button with indicator light

8. Start/Pause button with indicator light / Drain out

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance,

please register your appliance on:

www.hotpoint.eu/register

You can download the Safety Instructions and the

Use and Care Guide, by visiting our website

docs.hotpoint.eu and following the Instructions

on the back of this booklet.

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the reta-

ining elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and should be lled when the

SALT REFILL

indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2. -Only the rst time you do this: ll the salt re

servoir with water.

3. Position the funnel (see gure) and ll the salt

reservoir right up to its edge (approximately

1 kg); it is not unusual for a little water to leak

out.

4. Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for average (3) water hardness.

• Switch on the appliance by pressing the button.ON/OFF

• Switch o the appliance by pressing the button.ON/OFF

• Hold down button START/Pause for 5 seconds, until you hear a

beep.

• Switch on the appliance by pressing the button.ON/OFF

• The ON/OFF LED light will ash as many times as the level that was set.

• Set the desired water hardness level using the PROGRAM SELECTION

knob (see WATER HARDNESS TABLE).

• Switch o the appliance by pressing the button.ON/OFF

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indi-

cator light switches o.

If the salt container is not lled, the water softener and the

heating element may be damaged as a result.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser should A

be lled when the in the control RINSE AID REFILL indicator light

panel is lit.

1. Open the dispenser B by pressing and pulling up the tab on the lid.

2. Pour in the rinse aid (max.110 ml), making sure it does not overow

from the dispenser. If this happens, clean the spill immediately with

a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can ad-

just the quantity of rinse aid used.

• Switch the dishwasher on using the button.ON/OFF

• Switch it o using the button.ON/OFF

• Press button START/Pause three times - a beep will be heard.

• Switch it on using the button.ON/OFF

• The START LED light will ash as many times as the level that was set.

• Set the level of rinse aid quantity to be supplied using the PROGRAM

SELECTION knob (see PROGRAMS TABLE).

• Switch it o using the buttonON/OFF

Setting is complete!

If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied. The

LOW RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 5 levels can be set according to the dishwasher model.

The factory setting is specic to the model, please follow instruction

above to check this for your machine.

• If you see bluish streaks on the dishes, set a low number (2-3).

• If there are drops of water or limescale marks on the dishes, set a

mid-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device A.

Introduce the detergent into the dry dispenser B only. Place the

amount of detergent for pre-washing directly inside the tub.

1. When measuring out the detergent

refer to the mentioned earlier infor-

mation to add the proper quantity.

Inside the dispenser there are B

indications to help the detergent

dosing.

2. Remove detergent residues from

the edges of the dispenser and clo-

se the cover until it clicks.

3. -Close the lid of the detergent di

spenser by pulling it up until the

closing device is secured in place.

The detergent dispenser automatically opens up at the right time

according to the program.

If all-in-one detergents are used, we recommend using the TABLET

button, because it adjusts the program so that the best washing and

drying results are always achieved.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 Hard 17 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Opvaskemaskine
Model:	HSFE 1B19 UK
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	450 mm
Dybde:	590 mm
Højde:	850 mm
Vægt:	34900 g
Kontroltype:	Buttons,Rotary
Strøm:	13 A
Pakkevægt:	36700 g
Energieffektivitetsklasse (gammel):	A+
Årligt energiforbrug:	238 kWh
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Tilsluttet belastning:	1900 W
Støjniveau:	49 dB
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Hvid
Vaskeklasse:	A
Vandforbrug pr. cyklus:	11.5 L
Antal kuverter:	10 kuverter
Cyklustid:	240 min.
Forsinket start (maks.):	8 t
Opvaskeprogrammer:	Eco,Glass/delicate,Intensive,Normal,Soak
Halv belastning:	Ja
Tørringsklasse:	A
Årligt vandforbrug:	3220 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.83 kWh
Energieffektivitetsskala:	A+++ til D
Produktstørrelse:	Slimline (45 cm)
Temperatur (maks):	60 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Strømforbrug (fortsat-tændt):	5 W
Tørresystem:	Statisk
Varighed af tilstanden fortsat-tændt:	12 min.
