Side 1/40

- Risk of Fire

• Clothes dryer installation must be performed by a

qualified installer.

• Install the clothes dryer according to these instructions

and local codes.

• DO NOT install a clothes dryer with flexible plastic venting

materials. If flexible metal (semi-rigid or foil-type) duct is

installed, it must be UL-listed and installed in accordance

with the instructions found in “Connecting the Dryer

to House Vent” later in this manual. Flexible venting

materials are known to collapse, be easily crushed and

trap lint. These conditions will obstruct dryer airflow and

increase the risk of fire.

• DO NOT install or store this appliance in any location

where it could be exposed to water or weather.

• To reduce the risk of severe injury or death, follow all

installation instructions.

• Save these instructions. (Installers: Be sure to leave

these instructions with the customer.)

In the Commonwealth of Massachusetts,

the following installation instructions apply:

• Installation must be performed by a qualified or

licensed contractor, plumber, or gasfitter qualified

or licensed by the State.

• If using a ball valve, it shall be a T-handle type.

• A flexible gas connector, when used, must not

exceed 4 feet.

FOR GAS DRYERS ONLY

BEFORE YOU BEGIN

Read these instructions completely and carefully.

IMPORTANT – Save these instructions for local electrical

inspector’s use.

IMPORTANT –

Observe all governing codes and

ordinances.

• Install the clothes dryer according to the manufacturer’s

instructions and local codes.

• Note to Installer – Be sure to leave these instructions

with the Consumer.

• Note to Consumer – Keep these instructions for future

reference.

• Clothes dryer installation must be performed by a qualified

installer.

• This dryer must be exhausted to the outdoors.

• Before the old dryer is removed from service or discarded,

remove the dryer door.

• Do not allow children on or in the appliance. Close

supervision of children is necessary when the appliance

is used near children.

• Proper installation is the responsibility of the installer.

• Product failure due to improper installation is not

covered under the Warranty.

• Install the dryer where the temperature is above 50°F for

satisfactory operation of the dryer control system.

• Remove and discard existing plastic or metal foil duct

and replace with UL-listed duct.

• Service information and the wiring diagram are located

in the control console.

31-16775-4 02-20 GEA

Questions? Call GE Appliances at 800.GE.CARES (800.432.2737) or visit our Web site at: GEAppliances.com

Dryers

Installation

Instructions

WARNING

234D2318P005

Installation Instructions

Tilt the dryer sideways and remove the foam

shipping pads by pulling at the sides and breaking

them away from the dryer legs. Be sure to remove

all of the foam pieces around the legs.

Remove the bag containing the literature.

UNPACKING YOUR DRYER

ROUGH-IN

DIMENSIONS

GE Appliances strongly recommends the use of factory

specified parts. These hoses are manufactured and tested

to meet GE Appliances specifications.

GE Appliances strongly recommends the use of new water

supply hoses. Hoses degrade over time and need to be

replaced every 5

years to reduce the risk of hose failures

and water damage.

Parts and Accessories

Order on-line at , 24 hours a day GEApplianceparts.com

or by phone at during normal business hours.877.959.8688

STEAM WATER HOSES (for steam dryer models only):

ACCESSORIES:

Order on-line at , 24 hours a day or GEApplianceparts.com

by phone at during normal business hours.877.959.8688

Part Number Accessory

PM14X10056

Dryer door opening vent brush

WX14X10007

LintEater™ Dryer rotary tube brush

PM08X10085

Flexible Metal Dryer Transition Duct

Part Number Accessory

WE25X20060

Complete Kit (hoses, Y-adapter, washers)

WE49X25794

Kit (Short hose, Y-adapter, washers)

and

WE1M847 Long Hose

OR SEPARATELY

WE1M847 Long Hose and

WE1M848 Short Hose

4 5/8”

(11.7 cm)

6 1/2”

(16.5 cm)

with Riser

27”

(68.8 cm)

4 1/4”

(10.8 cm)

Side ViewFront View

Cubic

Foot X Y

6.2 43 3/8”

(110 cm)

26 3/4”

(68 cm)

7.2 43 3/8”

(110 cm)

29 1/2”

(75 cm)

7.4 43 3/4”

(111 cm)

30 1/2”

(78 cm)

7.4

(with

Riser)

45 1/2”

(116 cm)

30 1/2”

(78 cm)
