User Guide

CONTROL PANEL

1. ON/OFF button

2. DRYING LEVEL button

3. DRY ONLY button

4. MULTI RINSE button

5. STEAM HYGIENE button

6. ACTIVE CARE button

7. START/PAUSE button and indicator light

8. KEY LOCK button

9. DELAY TIMER button

10. SPIN button

11. TEMPERATURE button

12. AUTO CLEAN button

13. WASH CYCLE SELECTOR KNOB

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

DETERGENT DISPENSER DRAWER

Compartment *:

Do not insert detergent in this compartment.

Compartment 1: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition (supplied) should be used for proper A

dosage.

If powder detergent is used, place the partition

into slot .B

Compartment 2: Additives (fabric softeners, etc.)

The fabric softener must not exceed the “MAX” level.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

13 78910

1112

1 2 4

DISPLAY

5 6

For all testing institutes:

2) Long cotton cycle: set programme COTTON at temperature 40°C.

3) Long synthetics cycle: set cycle SYNTHETICS at a temperature of 40°C.

* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

**** The display will show the suggested spin speed as default value.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected.The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation

2019/2014. The most ecient programme in terms of energy and water consumption for

washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the table.

4) Eco 40-60 (Wash & Dry)-

Test

wash and

drying cycle in compliance with EU Ecodesign

regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash programme

and set “Drying level” to

“

Cupboard

”.

The most ecient programme in terms of energy and

water consumption for washing and drying normally soiled cotton laundry. At the end of cycle

the garments can be immediately stored to the cupboard.

Maximum washing load 9 kg. Maximum drying load 7 kg.

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(***)

Energy

consumption

kWh

Total water lt

Laundry

temperature °C

Wash cycle Temperature Max.

spin

speed

(rpm)

Max.

load for

washing

(kg)

Duration

(h : m)

Drying

Max.

load for

drying

(kg)

Wash Fabric

softener

Powder

Liquid

Setting Range 1 2

Wash & Dry Mixed 30 °C - 30 °C 1200 3.5 ** 3.5   –– – – –

Wash & Dry XL Bed & Bath 60 °C - 60 °C 1600 7.0 ** 7.0   –– – – –

Cotton (2) 40 °C - 60 °C 1600 9.0 3:55 7.0     49 1.14 107 45

Synthetics (3) 40 °C - 60 °C 1200 5.5 2:55 5.5     35 0.83 80 43

Wool 40 °C - 40 °C 800 2.5 ** 2.5   –– – – –

Delicates 30 °C - 30 °C 600 ( ) 1.0 ****** 1.0   –– – – –

Anti Allergy 60°C 1600 5.5 **40 °C - 60 °C 5.5     – – – –

Anti Stain 20 °C - 20 °C 1600 9.0 ** 7.0   –– – – –

Steam Refresh – – – 2.0 ** – – – – – – – – – –

Spin & Drain *– – 1600 9.0 ** 7.0 – – – – – – – –

Rinse & Spin – – 1600 9.0 ** 7.0 – – – – – – –

Wash 20°C 20 °C - 20 °C 1600 9.0 1:50 – –   –54,5 0.20 95 22

Eco 40-60 (1)

(Wash) 40 °C 40°C

1551 9.0 3:48 

7.0

    44 0.82 59.5 29

1551 4.5 2:50      44 0.53 57.5 27

1551 2.5 2:25      44 0.38 37.5 22

Intense 60-90°C 60 °C - 90 °C 1600 9.0 2:40 7.0     54 1.90 100 55

Rapid Wash 30 °C - 30 °C 1200 ( ) 5.5 0:30 – –****   –71 0.21 50 27

Wash & Dry XS Rapid 30 °C 1600 1.0 **30 °C 1.0   –– – – –

  Required dosage Optional dosage

Eco 40-60 (4)

(Wash & Dry) 40 °C 40 °C 1551 7.0 9:50 7.0     0 5.10 75 33

1551 3.5 6:00 3.5     0 2.70 53 33

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on

www.hotpoint.eu/register

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Wash & Dry Mixed

Use this cycle to wash and dry mixed garments (cotton and synthetics) in

less than 4 hours. This cycle may be used to wash and dry loads of up to half

of the machine drying capacity; we recommend the use of liquid detergent.

Wash & Dry XL Bed & Bath

This cycle is suitable for washing and drying without interruption cotton

bulky items, like bed linens and towels, with the possibility to fully load

the machine; we recommend using liquid detergent.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Specic for synthetic items (e.g. polyester, polyacrylic, viscose, etc.). If the

dirt is dicult to remove, the temperature can be increased up to 60° and

powder detergent can be used too.

Wool - Wool Care

The wool wash cycle of this machine has been approved by

The Woolmark Company for the washing of machine

washable wool products provided that the products are

washed according to the instructions on the garment label

and those issued by the manufacturer of this washing

machine. The Woolmark symbol is a Certication mark in

many countries. (M2222)

Delicates

For washing very delicate garments. For best results, turn the garments

inside out and use liquid detergent. If a time-based drying option is

added, a particularly delicate drying cycle is performed at the end of the

wash cycle, thanks to light handling and appropriate temperature control

of the water jet. The recommended durations are:

1 kg of synthetic garments --> 165 min

1 kg of synthetic and cotton garments --> 180 min

1 kg of cotton garments --> 180 min

The degree of dryness depends on the load and fabric composition.

Anti Allergy

Suitable for removing major allergens such as pollen, mites and cat or

dog hair.

Anti Stain

This program ensures stain removal at low temperatures, preserving

fabrics and colours. It is suitable to heavily-soiled garments with resistant

colours. When running the program, do not mix garments of dierent

colours. We recommend the use of powder detergent.

Steam Refresh

This programme refreshes garments by removing bad odours and relaxing

the bres and it is meant for dry, unsoiled items.

Insert dry items only (that are not dirty) and select programme “Steam

Refresh”. The garments will be damp once the cycle is completed, so we

recommend hanging them to dry (2 kg, roughly 3 items).

The “Steam Refresh” programme makes ironing easier.

! Do not add softeners or detergents.

! Not recommended for wool or silk garments.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you

exclude the spin cycle, the machine will drain only.

Rinse & Spin

Rinses and then spins. For resilient garments.

Wash 20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at 40 °C

or 60 °C, together in the same cycle. This is the standard cotton programme

and the most ecient in terms of water and energy consumption.

! The cycle runs only at 40°C as per regulation.

Intense 60-90°C

For heavily soiled whites and resistant colours.

Rapid Wash

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Wash & Dry XS Rapid

This cycle is to wash and dry without interruption small garments or

T-shirts in dierent fabrics and colours up to 1kg in 45’. To achieve

optimum results, use liquid detergent.

DISPLAY

The display is useful when programming the machine and provides a

great deal of information.

Area : here will appear the icon and programme selected, the washing A

and drying phases and time remaining to the end of the cycle. Area : B

shows the the two modes relative to the ACTIVE CARE option. Area : C

shows the indicator lights relative to the available functions. Area : D

displays the time remaining to the start of the selected cycle if the Delay

Timer option was set.

Area : will display the maximum available spin speed on the basis of the E

set cycle; if the cycle does not include the spin cycle setting, the dimly lit

“ ” symbol will appear in the area.--

Area : will show the temperature value that can be selected on the basis F

of the set cycle; if the cycle does not include setting of the temperature,

the dimly lit “ ” symbol will appear in the area.--

SELECT LANGUAGE: the rst time the machine is switched on, you will be

asked to select the language and the display will automatically show the

language selection menu.

To select the desired language press the and buttons; to conrm the X Y

selection press the button.Z

To change the language switch o the machine and press buttons , , G H I

simultaneously until an alarm is heard: the language-selection menu will

be displayed again.

DISPLAY BRIGHTNESS: to change the display luminosity, which by

default is set to the highest value, switch the machine o then

simultaneously press buttons , and until the buzzer sounds.G L M

Press buttons and to choose the desired level of luminosity then X Y

conrm by pressing button .Z

! During the wash cycle or when the Delay Timer option has been enabled,

if the user does not interact with the display for 1 minute the SCREEN SAVER

activates. To return to the previous window, simply press any button.

LOCKED DOOR INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before attempting to open the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the “Auto

Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button ; “HOTPOINT” will appear on the display; the

indicator light relative to the START/PAUSE button will ash slowly.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the wash cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments, as described in the “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- Use the WASH CYCLE selector knob to select the desired wash cycle: the

cycle’s name will appear on the display; the cycle will be associated with a

specic temperature and spin speed which can be modied. The duration

of the cycle will appear on the display.

- Modify the temperature and/or spin speed: the machine automatically

selects the maximum temperature and spin speed set for the selected

wash cycle; these values cannot therefore be increased. Pressing the

button gradually reduces the temperature down to the cold wash setting

(the “--” symbol will appear on the display). Pressing the button

gradually reduces the spin speed until it is completely excluded (the “--”

symbol will appear on the display). Pressing the buttons further restores

the maximum allowed values for the selected cycle.

- Select the desired options.

STARTING CYCLE

Press the START/PAUSE button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol o) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash. To start the wash cycle from the point at which it

was interrupted, press the START/PAUSE button again.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash),

then select the desired cycle and press the START/PAUSE button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

AT THE END OF THE WASH CYCLE

This will be indicated by the word “CYCLE END” on the display; when the

symbol switches o, the door may be opened. Open the door and

switch o the machine. If you do not press ON/OFF button, the

washing machine will switch o automatically after about a 10 minutes.

Close the water tap and unload the washing machine. Leave the door ajar

to allow the drum to dry.

OPTIONS

- If the selected function is incompatible with the set wash cycle, the

relevant indicator light will appear dimly lit; the incompatibility will also

be signalled by a buzzer (3 beeps) and the wording “This action is not

allowed” will appear on the display.

- If the selected function is incompatible with another previously set

function, the wording “ ” will appear on the This action is not allowed

display and the function will not be enabled.

2:55

90° 1200 --

WASH & DRY

MIXED

X Z

L M

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	NDD 9725 BDA UK
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	605 mm
Højde:	850 mm
Vægt:	73400 g
Produktfarve:	Sort
Kontroltype:	Buttons, Rotary, Touch
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	13 A
Ledningslængde:	1.2 m
Strømforbrug (standby):	0.5 W
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Inverter-teknologi:	Ja
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1600 rpm
Støjniveau (centrifugering):	- dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Cotton, Cottons 40°C, Cottons 60°C, Delicate/silk, Down wear/duvet, Hygiene air refresh, Hygiene/anti-allergy, Rinse & spin, Spin/drain, Steam, Synthetics, Wool
Justerbare fødder:	Ja
Energiforbrug ved vask:	0.569 kWh
Understøttede scanningstilstande:	1045 mm
Tromle volumen:	71 L
Dør farve:	Sort
Spin-tørre klasse:	A
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Støjemissionsklasse:	C
Tørreprogrammer:	Cotton, Delicate/silk, Down wear/duvet, Hygiene/anti-allergy, Hygienic freshen-up, Steam, Synthetics, Wool
Tørreevne:	7 kg
Vaske kapacitet:	9 kg
Støjniveau (tørring):	- dB
Cyklustid vask og tørring:	590 min.
Vandforbrug pr. vask:	50 L
Energiforbrug pr. vask og tørring:	0.414 kWh
Vandforbrug pr. vask og tørring:	66 L
Anti-krølle funktion:	Ingen
Tilføj tøj (pause) -funktion:	Ja
Energieffektivitetsklasse (vask):	B
Energieffektivitetsklasse (vask og tørring):	E
Energiforbrug pr. 100 cyklusser (vask):	57 kWh
Energiforbrug pr. 100 cyklusser (vask og tørring):	414 kWh
Cyklustid vask:	228 min.
Tænd/sluk-knap:	Ja
Dybde med lukket låge:	624 mm
