Side 1/8

Quick Guide

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on

www.hotpoint.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

WASH CYCLE TABLE

For all testing institutes:

2) Long cotton cycle: set wash cycle with a temperature of 40°C. 3

3) Long synthetics cycle: set wash cycle with a temperature of 40°C.4

* By selecting the cycle and excluding the spin cycle, the washing machine will drain only. 14

** The duration of the wash cycles can be checked on the display.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as

the temperature and pressure of the incoming water, ambient temperature, amount of

detergent, load quantity and type, load balancing and any additional options selected.

1) Test wash cycle in compliance with regulation 1061/2010:

This cycle is designed for normally soiled cotton loads and is the most ecient in terms of

both electricity and water consumption; it should be used for garments washable at 60°C or

at 40°C. The actual washing temperature may dier from the indicated value.

1. REMOTE CONTROL button

2. UP / DOWN buttons

3. ON/OFF button

4. ACTIVE CARE button and indicator light

5. START/PAUSE button

6. CONFIRM / KEY LOCK button

7. START DELAY button

8. SPIN button

9. TEMPERATURE button

10. OPTIONS / SETTINGS button

11. STEAM HYGIENE/FAVOURITES button

12. WASH CYCLE SELECTOR KNOB

13. Programme Key

Maximum load 11 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Active

Care

Add

Gar-

ments

( )

Detergents and

Additives

Recommended

detergent

Residual damp-

ness %

Energy consump-

tion kWh

Total water l

Wash cycle Temperature Max.

spin speed

(rpm)

Max.

load

(kg)

Duration

(min-

utes)

Pre-

wash Wash Fabric

softener Powder Liquid

Default Range 1 2 3

1 Mixed 40°C - 40°C 1600 11 **      ––––

2 Eco Cotton (1) 60°C 60°C 1600 11 360 ––    43 1,13 62,5

40°C 1600 11 350 ––    43 1,13 62,5

3 Cotton (2) 40°C - 60°C 1600 11 250 ––    43 1,13 102

4 Synthetics (3) 40°C - 60°C 1200 5,5 175 –      53 0,83 56

5 Delicates 40°C - 40°C 1000 5,5 **   –  ––––

6 Wool 40°C - 40°C 800 2,5 ** – –  ––––

7 Anti Allergy 60°C 40°C - 60°C 1600 5,5 ** – –    –––

8 Anti Stain 40° 40°C - 40°C 1000 5,5 **   –    –––

9 White 40°C - 90°C 1600 11 **        –––

10 Steam Refresh – – – 2 ** – – – – – – – – – –

11 Rapid 30 min 30°C - 30°C 800 5,5 **   –  –– – –

12 Specials

• Bed & Bath 60°C - 60°C 1600 11 **   –    – – –

• Shirts 40°C - 40°C 600 2 ** – –  –– – –

• Business 30°C - 30°C 400 2 ** ––  –– – –

• Baby 40°C - 40°C 800 4 ** – –  –– – –

• Duvet 30°C - 30°C 1000 3,5 ** ––  –– – –

• Silk & Curtains 30°C - 30°C – 1 ** – –  –– – –

• Jeans 40°C - 40°C 800 4 ** ––  –– – –

• Rapid 15 min 30°C - 30°C 800 4,5 ** – –  –– – –

• Fitness 30°C - 30°C 600 4 ** ––  –– – –

• Cuddly toys 30°C - 30°C – 1 ** ––– – – – –

13 Favourites: allows for any wash cycle to be stored.

14 Spin & Drain * – – 1600 11 ** – – – – – – – – – –

15 Rinse & Spin – – 1600 11 ** – – – – – – – – –

  Required dosage Optional dosage

! Turning the knob to position allows for accessing the menu from which to set additional 12

washing programmes.

1 2 3

5678911 10

1213

DISPLAY

! The “Programme key” situated inside the detergent dispenser shows all the

available wash cycles together with a graphic guide on how to use the

individual dispenser compartments.

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

Eco Cotton 60°/40°

Suitable for washing moderately soiled cotton garments. At 40°C and

60°C it is the standard cycle for washing cotton garments, and is the most

ecient in terms of combined water and electricity consumption.

Cotton

Normally to heavily soiled and robust cottons .

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Delicates

For washing very delicate garments. It is advisable to turn the garments

inside out before washing them. For best results, use liquid detergent on

delicate garments.

Wool - Woolmark Apparel Care - Green:

The “Wool” wash cycle is approved by the Woolmark Company for

washing wool garments classied as “hand-washable”, provided that the

wash complies with the instructions appearing on the garment’s label

and with those provided by the manufacturer of this washing machine.

(M )1135

Anti Allergy

Suitable for removing major allergens such as pollen, mites and cat or dog hair.

Anti Stain 40°

The programme is suitable to heavily-soiled garments with resistant

colours. It ensures a washing class that is higher than the standard class (A

class). When running the programme, do not mix garments of dierent

colours. We recommend the use of powder detergent. Pre-treatment with

special additives is recommended if there are obstinate stains.

White

For washing normally to heavily soiled towels, underwear, table and bed

linen, etc in resilient cotton and linen. Only when the temperature is

selected at 90°C the cycle is provided with a prewash phase before main

washing phase. In this case it is recommended to add detergent both, in

the prewash and main wash section.

Steam Refresh

The garments will be damp once the cycle is completed, so we recommend

hanging them to dry (2 kg, roughly 3 items). This programme refreshes

garments by removing bad odours and relaxing the bres. Insert dry items

only (that are not dirty) and select programme “ ”. Garments Steam Refresh

will be a little damp at the end of the cycle and can be worn after a few

minutes. The “Steam Refresh” programme makes ironing easier.

! Do not add softeners or detergents.

! Not recommended for wool or silk garments.

Rapid 30 min

For washing lightly soiled garments quickly. This cycle lasts only 30

minutes, saving time and energy.

Specials

• Bed & Bath

For washing home linen in a single cycle. It optimises the use of fabric

softener and allows for saving time and electricity. We recommend the

use of powder detergent.

• Shirts

Use the special wash cycle to wash shirts in dierent fabrics and

colours to guarantee they receive the best possible care.

• Business

Program for clothes used infrequently or only slightly dirty (do not use

for dry clean garment).

Follow the instructions of the garment’s wash care label.

• Baby

Use the special wash cycle to remove the remove the soiling typically

caused by babies, while removing all traces of detergent from nappies

in order to prevent the delicate skin of babies from suering allergic

reactions. The cycle has been designed to reduce the amount of

bacteria by using a greater quantity of water and optimising the eect

of special disinfecting additives added to the detergent.

• Duvet

Designed for washing eiderdown padded items such as double or

single duvets, cushions and anoraks. It is recommended to load such

padded items in the drum with the edges folded inwards and not to

exceed ¾ of the drum’s volume. For optimal washing, we recommend

using a liquid detergent.

• Silk & Curtains

use special wash cycle to wash all silk garments or curtains. We

recommend the use of special detergent which has been designed to

wash delicate clothes.

For washing curtains, fold and place them in a pillow case or mesh bag.

• Jeans

Turn garments inside-out before washing and use a liquid detergent.

• Rapid 15 min

for washing lightly soiled garments in a short time. Not suitable for

wool, silk and garments to be washed by hand.

• Fitness

Sportswear in knitwear or microbers with a normal degree of dirt and

sweat.

• Cuddly toys

With this program it is possible to remove dust more easily and wash

better cuddle toys.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you

exclude the spin cycle, the machine will drain only

Rinse & Spin

Rinses and then spins. For resilient garments.

DISPLAY

The display is useful when programming the washing machine and

provides plenty of information.

COTTON

--:--

1:40

140040°

By pressing the and buttons, it is possible to select the desired

option and conrm it with the button.

The rst time the machine is switched on, you will be asked to select the

language and the display will automatically display the language selection

menu.

To select the desired language, press the and buttons; to conrm

the selection, press the button.

Area A will display the following: the icon and selected washing programme,

the washing phases and the time remaining to the end of the wash cycle.

Area B will display: the selected options, the energy and water consumption

for the chosen cycle and the button lock symbol.

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

DETERGENT DISPENSER DRAWER

compartment 1: Pre-wash detergent

(powder)

compartment 2: Detergent for the wash cycle

(powder or liquid)

If liquid detergent is used, it is recommended

that the removable plastic partition A (supplied)

be used for proper dosage.

If powder detergent is used, place the partition

into slot B.

compartment 3: Additives (fabric softeners, etc.)

The fabric softener should not overow the grid.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

PRODUCT DESCRIPTION

C D

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	NLLCD 1165 WD ADW UK
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	605 mm
Højde:	850 mm
Vægt:	75900 g
Produktfarve:	Hvid
Kontroltype:	Rotary, Touch
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	13 A
Ledningslængde:	1.2 m
Energieffektivitetsklasse (gammel):	A+++
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	11 kg
Maksimal centrifugeringshastighed:	1600 rpm
Antal vaskeprogrammer:	15
Støjniveau (centrifugering):	79 dB
Støjniveau (vask):	52 dB
Near Field Communication (NFC):	Ingen
Vaskeprogrammer:	Bedding, Hygiene/anti-allergy, Baby care, Blouse/shirt, Cotton, Eco, Wool, Mix, Quick, Steam, Synthetics, White, Delicate/silk
Børnesikring:	Ja
Justerbare fødder:	Ja
Energiforbrug ved vask:	1.102 kWh
Årligt energiforbrug vask:	205 kWh
Tromle volumen:	71 L
Dør farve:	Sølv
Balje materiale:	Plast
Balance system:	Ja
Spin-tørre klasse:	A
Cyklustid (maks.):	310 min.
Skum kontrol system:	Ja
Restfugtighed:	44 %
Vaskeklasse:	A
Årligt vandforbrug vask:	12850 L
Indikator for LED-programfase:	Ja
Halv belastning:	Ja
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Indikator for resterende tid:	Ja
Wi-Fi kontrolleret:	Ingen
Rense plus funktion:	Ja
Brugerdefineret panel klar:	Ingen
Cyklustid (hurtigt vaskeprogram):	30 min.
Strømforbrug (fortsat-tændt):	8 W
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Skærmlys:	Ja
Tilføj tøj (pause) -funktion:	Ja
Belysningsfarve:	Gul
Varighed af tilstanden fortsat-tændt:	30 min.
Nem strygning funktion:	Ja
Tænd/sluk-knap:	Ja
