Side 1/4

Quick Guide

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on

www.hotpoint.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

WASH CYCLE TABLE

For all testing institutes:

2) Long cotton cycle: set wash cycle Cotton with a temperature of 40°C.

3) Long synthetics cycle: set wash cycle with a temperature of 40°C.Synthetics

* By selecting the cycle and excluding the spin cycle, the washing machine will Spin & Drain

drain only.

** The duration of the wash cycles can be checked on the display.

*** For Prewash press the “Temp.” button until the symbol lights up (only 90°).

****

After programme end and spinning with maximum selectable spin speed, in default

programme setting.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected.The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient

programme in terms of energy and water consumption for washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly differs from the values stated in the table.

PRODUCT DESCRIPTION

3.2.

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

Maximum load 9 kg

Power input in o mode 0.5 W / in left-on mode 8 W Add

Gar-

ments

( )

Detergents and

Additives Recommended

detergent

Residual

dampness % (****)

Energy

consumption kWh

Total water lt

Laundry

temperature °C

Wash cycle

Temperature Max.

spin speed

(rpm)

Max.

load

(kg)

Dura-

tion

(h : m)

Pre-

wash Wash Fabric

softener Pow-

der Liquid

Setting Range 1 2 3

Eco 40-60 (1) 40 °C 40°C

1351 9,0 3:40 – –    53 0,80 58 34

1351 4,5 2:50 – –    53 0,52 51 35

1351 2,25 2:10 – –    53 0,40 41 32

Cotton (2) 40°C - 60°C 1400 9,0 3:55 – –    49 1,10 97 45

Synthetics (3) 40°C - 60°C 1200 4,5 2:55 – –    35 0,80 55 43

Mixed 40°C - 40°C 1400 9,0 **   –  –– – – –

Delicates 40°C - 40°C 1000 4,5 **   –  –– – – –

White 40°C - 90°C 1400 9,0 2:00       (***) 55 0,89 89 42

Anti Stain 40° 40°C - 40°C 1000 4,5 **   –    – – – –

Rapid 30 min 30°C - 30°C 1200 4,5 0:30   –  –71 0,18 37 27

Spin & Drain * – – 1400 9,0 ** – – – – – – – – – – –

Rinse & Spin – – 1400 9,0 ** – – – – – – – – – –

Steam Refresh – – – 2,0 ** – – – – – – – – – – –

20°C 20 °C - 20 °C 1400 9,0 1:50 – –  –55 0,14 78 22

Wool 40°C - 40°C 800 2,0 ** – –  –– – – –

Anti Allergy 60°C 140040°C - 60°C 5,0 ** – –    – – – –

Bed & Bath 60°C - 60°C 1400 9,0 **   –    – – – –

  Dosing required Dosing optional

DETERGENT DISPENSER DRAWER

compartment 1: Pre-wash detergent (powder)

compartment 2: Detergent for the wash cycle

(powder or liquid)

If liquid detergent is used, it is recommended that

the removable plastic partition A (supplied) be

used for proper dosage.

If powder detergent is used, place the partition

into slot B.

compartment 3: Additives (fabric softeners, etc.)

The fabric softener should not overow the grid.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

1. STEAM HYGIENE / MUTE button

2. FINAL CARE / KEY LOCK button

3. ON/OFF button

4. ACTIVE CARE button and indicator light

5. START/PAUSE button

6. RAPID / GREEN button

7. SPIN button

8. START DELAY button

9. TEMPERATURE button

10. WASH CYCLE SELECTOR KNOB

1 2

56789

DISPLAY

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Eco 40-60

For washing normally soiled cotton garments declared to be washable

at 40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

Cotton

Normally to heavily soiled and robust cottons.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

Delicates

For washing very delicate garments. It is advisable to turn the garments

inside out before washing them. For best results, use liquid detergent on

delicate garments.

White

For washing normally to heavily soiled towels, underwear, table and bed

linen, etc in resilient cotton and linen. Only when the temperature is

selected at 90°C the cycle is provided with a prewash phase before main

washing phase. In this case it is recommended to add detergent both, in

the prewash and main wash section.

Anti Stain 40°

The programme is suitable to heavily-soiled garments with resistant

colours. It ensures a washing class that is higher than the standard class (A

class). When running the programme, do not mix garments of dierent

colours. We recommend the use of powder detergent. Pre-treatment with

special additives is recommended if there are obstinate stains.

Rapid 30 min

For washing lightly soiled garments quickly. This cycle lasts only 30

minutes, saving time and energy.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you

exclude the spin cycle, the machine will drain only

Rinse & Spin

Rinses and then spins. For resilient garments.

Steam Refresh

The garments will be damp once the cycle is completed, so we recommend

hanging them to dry (2 kg, roughly 3 items). This programme refreshes

garments by removing bad odours and relaxing the bres. Insert dry items

only (that are not dirty) and select programme “Steam Refresh”. Garments

will be a little damp at the end of the cycle and can be worn after a few

minutes. The “Steam Refresh” programme makes ironing easier.

! Do not add softeners or detergents.

! Not recommended for wool or silk garments.

20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Wool - Woolmark Apparel Care - Green:

The “Wool” wash cycle is approved by the Woolmark Company for

washing wool garments classied as “hand-washable”, provided that the

wash complies with the instructions appearing on the garment’s label

and with those provided by the manufacturer of this washing machine.

(M1127)

In UK, Eire, Hong Kong and India the Woolmark trade mark is a Certication

trade mark.

Anti Allergy

Suitable for removing major allergens such as pollen, mites and cat or dog hair.

Bed & Bath

For washing home linen in a single cycle. It optimises the use of fabric

softener and allows for saving time and electricity. We recommend the

use of powder detergent.

DISPLAY

The display is useful when programming the washing machine and

provides plenty of information.

The duration of the available wash cycles and the remaining time of a

running cycle appear in section (the display will show the maximum A

duration of the cycle chosen, which may decrease after several minutes,

since the eective duration of the programme varies depending on the

wash load and the settings chosen); if the DELAYED START option has been

set, the countdown to the start of the selected wash cycle will appear.

Pressing the corresponding button allows you to view the maximum spin

speed and temperature values attained by the machine during the set

wash cycle, or the values selected most recently, if these are compatible

with the set wash cycle.

The “wash cycle phases” corresponding to the selected wash cycle and the

“wash cycle phase” of the running wash cycle appear in section :B

Main wash

Rinse

Spin + Pump out

References indicate the wash options available (See “Options” section). C

The “Start Delay” symbol , when lit, indicates that the set “delayed start”

value has appeared on the display.

The symbol indicates the possibility of inserting an additional garments

load with the washing program started (See “Adding Garments” section).

The symbol indicates the possibility to silence the key tones

While the mute is active, almost all sounds will be turned o. Only the sound

signals and the alarms remain active, as well as the sound of the end of cycle.

For activate/deactivate the mute press and hold button.

DISPLAY INDICATORS

Failure: Call Service

Refer to Troubleshooting section

Failure: Water lter clogged

Water cannot be drained; water lter might be blocked

Failure: No water

No or not sucient inlet water.

In the event of any failure, refer to the “Troubleshooting” section.

Key Lock

To lock the control panel, press and hold the “Key lock” button for

approximately 3 seconds. The symbol will light up on the display to

indicate that the control panel has been locked (with the exception of the

“ON/OFF“ button). This prevents unintentional changes to programmes,

especially with children near the machine. To unlock the control panel,

press and hold the “Key lock” button for approximately 3 seconds .

Locked door indicator

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before you use it for the rst

time, run a wash cycle with detergent and no laundry, using the wash

cycle .White (60°)

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button .

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the wash cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments, as described in the “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- The machine automatically displays the default temperature and spin

speed values for the selected cycle, or the most recently used settings if

they are compatible with the selected cycle.

- Select the desired wash cycle.

- Select the desired options.

STARTING CYCLE

- Press the start/pause button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol OFF) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again. To start

the wash cycle from the point at which it was interrupted, press the

START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns on to signal that the door cannot

be opened. While a wash cycle is running, the door remains locked. To

open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle. If the

symbol is not lit, the door may be opened. Press the START/PAUSE

button again to continue the cycle.

END

E M

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	NM11 945 GC A UK N
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	600 mm
Dybde:	610 mm
Højde:	850 mm
Produktfarve:	Grafit
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	9 kg
Maksimal centrifugeringshastighed:	1400 rpm
Støjniveau (centrifugering):	78 dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ja
Børnesikring:	Ja
Dør farve:	Sort, sølv
Spin-tørre klasse:	B
Cyklustid (maks.):	220 min.
Restfugtighed:	53 %
Vandforbrug pr. cyklus:	50 L
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Vandpåfyldning:	Kold
Dispenser skuffetype:	3-vejs
Støjemissionsklasse:	C
Energieffektivitetsklasse:	B
Energiforbrug pr. 100 cyklusser:	57 kWh
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Visningsvindue:	Ja
Lydalarm:	Ja
Tænd/sluk-knap:	Ja
Dørgrebets farve:	Grafit
