Side 1/4

Quick Guide

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on

www.hotpoint.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

WASH CYCLE TABLE

* By selecting the cycle and excluding the spin cycle, the washing machine will Spin & Drain

drain only.

** The duration of the wash cycles can be checked on the display.

****

After programme end and spinning with maximum selectable spin speed, in default

programme setting.

4) Eco Cotton - Test wash cycles in compliance with regulations 1061/2010. Set

“Cotton”

wash cycle at a temperature of 40°C or 60°C to access this cycles.

Note: If “Steam Hygiene” option is set, the duration of the wash cycles will increase.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected.The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient

programme in terms of energy and water consumption for washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly differs from the values stated in the table.

For all testing institutes:

2) Long cotton cycle: set programme at temperature 40°C. Cotton

3) Long synthetics cycle: set cycle at a temperature of 40°C.Synthetics

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

1. ON/OFF button

2. KEY LOCK button

3. EXTRA TOUCH button

4. EXTRA TOUCH indicator lights

5. START/PAUSE button and indicator light

6. OPTION button and indicator light

7. DELAY START button

8. SPIN button

9. TEMPERATURE button

10. WASH CYCLE SELECTOR KNOB

Maximum load

9 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(****)

Energy

consumption

kWh

Total water lt

Laundry

temperature

°C

Wash cycle Temperature Maximum

spin

(r.p.m.)

Max.

load

(kg)

Duration

(h : m)

Wash Fabric

softener Powder Liquid

Setting Range 2 3

Mixed 40°C - 40°C 1600 9,0 **   –––––

Eco 40-60 (1) 40 °C 40°C

1551 9,0 3:40     44 0,95 57 33

1551 4,5 2:50     44 0,76 47 35

1551 2,5 2:10     44 0,58 40 33

Cotton (2) 40°C - 60°C 1600 9,0 3:55     49 1,10 97 45

Synthetics (3) 40°C - 60°C 1200 4,5 2:55     35 0,8 55 43

Delicates 40°C - 40°C 1000 4,5 **   –––––

Wool 40°C - 40°C 800 2 **   –––––

Anti Allergy 60°C 40°C - 60°C 1600 5 **     ––––

Spin & Drain * – – 1600 9,0 ** – – – – – – – –

Rinse & Spin – – 1600 9,0 ** – ––––––

Baby 40°C - 40°C 800 4,0 **   –––––

20°C 20 °C - 20 °C 1600 9,0 1:50   –54,5 0,14 78 22

Duvet 30°C - 30°C 1000 3,5 **   –––––

White 40°C - 90°C 1600 9,0 2:00    – 54,6 0,89 89 42

30 min 30°C - 30°C 800 4,5 0:30   –71 0,18 37 27

Full Load 45 min 40°C - 40°C 1200 9,0 **   –––––

Anti Stain 40° 40°C - 40°C 1600 9,0 **   –––––



Required dosage Optional dosage

Eco Cotton (4) 60 °C 60 °C 1600 9,0 4:25     44 1,1 53 –

40 °C 40 °C 1600 9,0 3:55     49 1,10 97 –

DETERGENT DISPENSER DRAWER

Compartment *:

Do not insert detergent in this compartment.

Compartment 1: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition (supplied) should be used for proper A

dosage.

If powder detergent is used, place the partition

into slot .B

Compartment 2: Additives (fabric softeners, etc.)

The fabric softener must not exceed the “MAX” level.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

DISPLAY

567

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resistant garments in cotton, linen,

synthetic bres and mixed bres.

Eco 40-60

For washing normally soiled cotton garments declared to be washable

at 40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Delicates

Suitable for washing lightly soiled garments made of synthetic bres (e.g.

polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Wool - Woolmark Apparel Care - Green:

The “Wool” wash cycle is approved by the Woolmark Company

for washing wool garments classied as “hand-washable”,

provided that the wash complies with the instructions

appearing on the garment’s label and with those provided by

the manufacturer of this washing machine (M1127)

Anti Allergy

Suitable for removing major allergens such as pollen, mites and cat or

dog hair.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you

exclude the spin cycle, the machine will drain only.

Rinse & Spin

Rinses and then spins. For resilient garments.

Baby

Use the special wash cycle to remove the soiling typically caused by

babies, while removing all traces of detergent from nappies in order to

prevent the delicate skin of babies from suering allergic reactions. The

cycle has been designed to reduce the amount of bacteria by using a

greater quantity of water and optimising the eect of special disinfecting

additives added to the detergent.

20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Duvet

Suitable for washing clothing padded with goose down, such as single

duvets (weighing under 3,5 kg), cushions or down jackets. Duvets should

be loaded into the drum with their edges folded inwards and no more

than ¾ of the total drum volume should be used up. For best results, it is

advisable to use liquid detergent to be poured into the detergent drawer.

White

For heavily soiled whites and resistant colours.

30 min

For washing lightly soiled garments in a short time. Not suitable for wool,

silk and garments to be washed by hand.

Full Load 45 min

Suitable for washing a full load of cotton clothes moderately soiled in 45

minutes.

Anti Stain 40°

the programme is suitable to heavily-soiled garments with resistant

colours. It ensures a washing class that is higher than the standard class (A

class). When running the programme, do not mix garments of dierent

colours. We recommend the use of powder detergent. Pre-treatment with

special additives is recommended if there are particularly obstinate stains.

Eco Cotton

For washing normally soiled cotton garments. At 40°C and 60°C.

DISPLAY

The display is useful when programming the washing machine and

provides plenty of information.

The duration of the available wash cycles and the remaining time of a running

cycle appear (the display will show the maximum duration of the cycle chosen,

which may decrease after several minutes, since the eective duration of the

programme varies depending on the wash load and the settings chosen); if the

DELAY START option has been set, the countdown to the start of the selected

wash cycle will appear.

Pressing the corresponding button allows you to view the maximum spin speed

and temperature values attained by the machine during the set wash cycle, or

the values selected most recently, if these are compatible with the set wash cycle.

Locked door indicator

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with a very little detergent and no laundry, by

setting the “Auto-Clean” cycle. (see “CARE AND MAINTENANCE”)

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button ; the indicator light relative to START/PAUSE

will ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the wash cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments, as described in the “DETERGENT DISPENSER

DRAWER” section.

- Close the door.

- The machine automatically displays the maximum temperature and spin

speed values for the selected cycle, or the most recently used settings if

they are compatible with the selected cycle. Pressing the button

gradually reduces the temperature down to the cold wash “OFF” setting.

Pressing the button gradually reduces the spin speed until it is

completely excluded (“OFF” setting). Pressing the buttons further restores

the maximum allowed values for the selected cycle.

- Select the desired wash cycle.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative

indicator light will light up steady green and the door will lock ( symbol on).

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash amber. To start the wash cycle from the point at

which it was interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns on to signal that the door cannot

be opened. While a wash cycle is running, the door remains locked. To

open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened. Press the START/PAUSE button again to continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash amber),

then select the desired cycle and press the START/PAUSE button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

AT THE END OF THE WASH CYCLE

This will be indicated by the word “END” on the display; when the symbol

switches o, the door may be opened. Open the door, unload the laundry and

switch o the machine. If you do not press “ON/OFF” button, the washing

machine will switch o automatically after about a 10 minutes.

OPTIONS

- If the selected option is not compatible with the set wash cycle, the

indicator light will ash and the option will not be activated.

Extra Rinse

Selecting this option allows for enhancing rinsing eciency and fully

removing the detergent. It is particularly useful for sensitive skin.

OUC

Extra Touch

After pushing the button for the 1st time, option “Rapid Option” is

selected and the cycle duration will be reduced.

After pushing the button for the 2nd time, option “Steam Hygiene”

enhances washing performance by generating steam during the wash cycle

to remove any bacteria from the bres, which are treated at the same time.

! The steam generated during the operation of the washing machine may

cause the porthole door to become hazy.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	NSWM 963C W UK N
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	600 mm
Dybde:	610 mm
Højde:	850 mm
Produktfarve:	Hvid
Kontroltype:	Rotary, Touch
Indbygget skærm:	Ja
Strømforbrug (standby):	0.5 W
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Støjniveau:	85 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	9 kg
Maksimal centrifugeringshastighed:	1600 rpm
Støjniveau (centrifugering):	- dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ja
Børnesikring:	Ja
Dør farve:	Hvid
Spin-tørre klasse:	A
Cyklustid (maks.):	220 min.
Vandforbrug pr. cyklus:	48 L
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Vandpåfyldning:	Kold
Dispenser skuffetype:	3-vejs
Støjemissionsklasse:	D
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	75 kWh
Justerbar centrifugeringshastighed:	Ja
Visningsvindue:	Ja
Lydalarm:	Ja
Døråbning:	Sideåbning
Tænd/sluk-knap:	Ja
Dørgrebets farve:	Hvid
