Side 1/4

CONTROL PANEL

FIRST TIME USE

Remove all the tapes used to hold items on the machine.

Before you use it, clean the inside of the drum to remove any dust

that could have accumulated during transport.

Slight odour or vapour may be found if you open the door during

its ﬁrst use, this is normal and should only last a few minutes.

Make sure that the ventilation hose is properly inserted (refer to the

Safety Instructions).

DESCRIPTION OF CONTROL PANEL

"High Heat" button

To be used to increase the heat on drying cycles. When the button is out

low heat is selected and when it is pushed in high heat is selected.

"Start" button

Press to begin drying.

"Drying light"

is on when a drying programme is running, it goes out

at the end of the drying programme or if you open the door.

"Timer" selection knob

This is used to set the drying time: turn the knob in a clockwise

direction until the indicator is set to the desired drying time.

The 0 position switches oﬀ the dryer.

OPENING THE DOOR DURING THE CYCLE

Laundry can be checked while the drying cycle runs and any

garments already dry can be removed, while drying continues for

the remaining items. After closing the door, press the "Start" button

to resume machine operation.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to clean your lter after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door, ensure that the ﬁlter is clean and securely

placed, check to see if the drum is empty before loading it.

3. Load garments; always refer to instructions on clothing labels and

the max loads indicated in the drying time table. Empty pockets.

Make sure garments do not get caught between the door and/or

the door filter.

Do not load items that are dripping wet. Do not

tumble dry large, very bulky items.

4. Close the door.

5. Turn the “Timer" selection knob until the indicator is pointing

towards the most suitable drying time for the type of fabric in

that load.

Note: do not attempt to turn the knob anticlockwise.

6. If necessary, set the temperature using the "High Heat" button.

7. Press the "Start" button to begin drying and the drying light

comes on.

8. A ﬁnal COOL TUMBLE phase (i.e. the fabrics are cooled)

activates during the last few minutes of the drying cycle;

always allow this phase to ﬁnish.

9. The cycle ends when the selection knob reaches the "0" zero

position and the drum stops.

10. Open the door, remove the laundry.

11. Disconnect the dryer from the power supply.

12. Clean the ﬁlter and replace it.

Synthetics - High (full) Heat Acrylics - Low (gentle) Heat

Drying times on reduced spin in washing machine

1kg 2kg 1kg 2kg

20-30mins 30-45mins 30-50mins 50-70mins

DRYING TIMES

Refresh

A short cycle suitable for refreshing ﬁbres and garments through the

emission of fresh air. It lasts about 10 minutes. As this is not a drying cycle,

it is not to be used for garments that are still wet. It can be used on any load

size but is more eﬀective on smaller loads.

Drying Times

The drying time depends on the size of the load and on the type of fabric

it contains (see the table below).

A cool tumble cycle runs during the ﬁnal 10 minutes of the cycle.

High Heat Cotton is the most eﬃcient setting in terms of energy

consumption (EU 392/2012). To reach maximum eﬃciency, select the

highest temperature option.

Drying Times table

The tables below show approximate drying times in minutes.

Weights refer to dry garment weights.

Drying times are approximate and may vary depending on the following:

• Amount of water retained after the spin cycle: towels and delicate items

can retain a lot of water (if laundry retains a large amount of water,

use a longer cycle than the one recommended).

• Fabrics: items of the same fabric, but with diﬀerent texture and

thickness may have diﬀerent drying times.

• Amount of laundry: single items and small loads take less time to dry.

• Ironing: if you will be ironing laundry, remove while slightly damp for

better results. Items not being ironed can be left longer.

• Temperature of the room: the lower the temperature of the room, the

longer it will take for the dryer to dry clothing.

• Bulky items: bulky items require special care. We recommend removing

several times the items during the drying cycle to shake them out.

Warning: do not over-dry items.

All fabrics contain natural dampness which helps to keep them soft and ﬂuﬀy.

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the ﬁ rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

Standard Cotton - High (full) Heat

Drying times 800-1000rpm spin in washing machine

1kg 2kg 3kg 4kg

30-40mins 40-55mins 60-70mins 85-120mins

MAX COTTON LOAD 4 Kg (Dry load)

MAX SYNTHETIC LOAD 2 Kg (Dry load)

DRYING

OFF

120’

110’

100’

90’

80’

70’

60’

50’

40’

30’

20’

10’

HIGH HEAT

LOW HEAT

1 Kg 30’ - 40’

2 Kg 40’ - 55’

3 Kg 60’ - 70’

4 Kg 85’ - 120’

Standard Cotton

HIGH HEAT

1 Kg 20’ - 30’

2 Kg 30’ - 45’

Synthetics

HIGH HEAT

1 Kg 30’ - 50’

2 Kg 50’ - 70’

Acrylics

LOW HEAT

4Kg

Reverse Action

MADE IN GREAT BRITAIN

First Edition

START

Heat Button

Start Button

Drying Light

Indicator

Timer Knob

THANK YOU FOR BUYING A HOTPOINT PRODUCT.

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instructions.

Instruction for use

SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

This symbol reminds you to read this instruction

manual.

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all

times. The manufacturer declines any liability for

failure to observe these safety instructions, for

inappropriate use of the appliance or incorrect

setting of controls.

Very young children (0-3 years) should be kept

away from the appliance. Young children (3-8 years)

should be kept away from the appliance unless

continuously supervised. Children from 8 years old

and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge can use this appliance only if they

are supervised or have been given instructions on

safe use and understand the hazards involved.

Children must not play with the appliance. Cleaning

and user maintenance must not be carried out by

children without supervision.

WARNING: Never stop a tumble dryer before the

end of the drying cycle unless all items are quickly

removed and spread out so that the heat is

dissipated.

Items that have been soiled with substances such

as cooking oil, acetone, alcohol, petrol, kerosene,

spot removers, turpentine, waxes and wax removers

and items such as foam rubber (latex foam), shower

caps, waterproof textiles, rubber-backed articles

and clothes or pillows fitted with foam rubber pads

should not be dried in the tumble dryer. Remove all

objects from pockets, such as lighters and matches.

Do not use the tumble dryer if industrial chemicals

have been used to clean it.

Oil-soaked items should not be dried in the

tumble dryer due to their high flammability.

Never open the door forcibly or use it as a step.

PERMITTED USE

CAUTION: The appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: staﬀ kitchen areas

in shops, oﬃ ces and other working environments;

farm houses; by clients in hotels, motels, bed &

breakfast and other residential environments.

This appliance is not for professional use. Do not

use the appliance outdoors.

Do not store explosive or flammable substances

(e.g. gasoline or aerosol cans) inside or near the

appliance - risk of fire.

Do not load the machine above the maximum

capacity (kg of dry cloth) indicated in the programme

table.

Do not dry unwashed items in the tumble dryer.

Take care that no lint or dust has accumulated

around the dryer.

Fabric softeners, or similar products, should be

used as specified by the fabric softener instructions.

Do not overdry the laundry.

INSTALLATION

The appliance must be handled and installed by

two or more persons - risk of injury. Use protective

gloves to unpack and install - risk of cuts.

Installation, including water supply (if any),

electrical connections and repairs must be carried

out by a qualiﬁ ed technician. Do not repair or replace

any part of the appliance unless speciﬁ cally stated in

the user manual. Keep children away from the

installation site. After unpacking the appliance, make

sure that it has not been damaged during transport.

In the event of problems, contact the dealer or your

nearest After-sales Service. Once installed, packaging

waste (plastic, styrofoam parts etc.) must be stored

out of reach of children - risk of suﬀ ocation. The

appliance must be disconnected from the power

supply before any installation operation - risk of

electric shock. During installation, make sure the

appliance does not damage the power cable - risk of

ﬁ re or electric shock. Only activate the appliance

when the installation has been completed.

Install the dryer in rooms with adequate

ventilation (open door, ventilation grid or slot larger

than 500 cm

) in order to avoid the backflow of

gases into the room from appliances burning other

fuels, including open fires. If the dryer is installed

under a worktop, provide a distance of 50 mm

between the upper panel of the dryer and any

objects above it, and 25 mm between the sides of

the appliance and the walls or furniture units

adjacent to it.

If the dryer is installed near to a gas or coal stove,

provide a heat insulating plate (85 cm x 57 cm) in

between, as the side facing the stove is covered with

aluminium foil.

Exhaust air must not be discharged into a flue

which is used for discharging fumes from appliances

burning gas or other fuels.

The appliance must not be installed behind a

lockable door, a sliding door or a door with a hinge

on the opposite side to that of the tumble dryer, in

such a way that a full opening of the tumble dryer

door is restricted.

The appliance shall be placed against the wall to

limit access to its rear side.

Take care not to use a carpet which obstructs

ventilation openings in the base of the dryer.

ELECTRICAL WARNINGS

It must be possible to disconnect the appliance

from the power supply by unplugging it if plug is

accessible, or by a multi-pole switch installed

upstream of the socket in accordance with the

wiring rules and the appliance must be earthed in

conformity with national electrical safety standards.

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Tørretumbler
Model:	NV4D 01 P (UK)
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	490 mm
Dybde:	480 mm
Højde:	670 mm
Vægt:	19700 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ingen
Strøm:	13 A
Årligt energiforbrug:	330 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Tilsluttet belastning:	2200 W
Støjniveau:	66 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	4 kg
Forsinket start-timer:	Ingen
Tromle volumen:	58 L
Dør farve:	Hvid
Cyklustid:	101 min.
Energieffektivitetsskala:	A+++ til D
Tørreprogrammer:	Cotton, Synthetics
Tørresystem:	Ventileret
Energiforbrug:	- kWh
Varmekilde:	Elektrisk
Dørstil:	Plastik vinduesdør
