Side 1/4

Quick Guide

THANK YOU FOR PURCHASING A PRODUCTHOTPOINT .

To receive more comprehensive assistance, register the

appliance on www.hotpoint.eu/register

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more

detailed instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

1. ON/OFF button

2. DRY ONLY button and indicator light

3. KEY LOCK button and indicator light

4. CLEANING ACTION button

5. CLEANING ACTION indicator lights

6. START/PAUSE button and indicator light

7. DELAY button and indicator light

8. buttonDRYING

9. SPIN button

10. TEMPERATURE button

11. WASH CYCLE SELECTOR KNOB

DETERGENT DISPENSER DRAWER

Compartment *:

Do not insert detergent in this compartment.

Compartment 1: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition (supplied) should be used for proper A

dosage.

If powder detergent is used, place the partition

into slot .B

Compartment 2: Additives (fabric softeners, etc.)

The fabric softener must not exceed the “MAX” level.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

For all testing institutes:

2) Long cotton cycle: set programme 3 at temperature 40°C.

3) Long synthetics cycle: set cycle 4 at a temperature of 40°C.

* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

**** If a drying cycle is also programmed, the machine will run a “wash+dry” programme

lasting 45’ and a 1kg laundry load.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected.The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40- 60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation

2019/2014. The most ecient programme in terms of energy and water consumption for

washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the table.

4) Eco 40-60 (Wash & Drying)-

Test wash and drying cycle in compliance with EU

Ecodesign regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash

programme and set “Drying” option level to

“A3”.

The most ecient programme in terms of

energy and water consumption for washing and drying normally soiled cotton laundry. At the

end of cycle the garments can be immediately stored to the cupboard.

Maximum load 8 kg

Power input in o mode 0.5 W / in left-on mode 8 W Detergents and

Additives Recommended

detergent

Residual

dampness %

(****)

Energy

consumption

kWh

Total water lt

Laundry

temperature °C

Wash cycle Temperature Max.

spin speed

(rpm)

Max.

load for

washing

(kg)

Duration

(h : m)

Drying

Max.

load for

drying

(kg)

Wash Fabric

softener

Powder

Liquid

Setting Range 2 3

1 Anti-Stain Turbo 40 °C - 40 °C 1200 4.5 ** 4.5   –– – – –

2 Anti-Stain 40° 40 °C - 40 °C 1400 8.0 ** 6.0   –– – – –

3 Cotton (2) 40 °C - 60 °C 1400 8.0 3:55 6.0     49 1.40 105 45

4 Synthetics (3) 40 °C - 60 °C 1200 4.0 2:55 4.0     35 0.80 55 43

5 Rapid 30’ 30 °C - 30 °C 800 4.5 0:30 4.5****   –71 0.20 45 27

6 Mix Wash & Dry 40 °C 800 3.5 **40 °C 3.5   –– – – –

7 Shirts Wash & Dry 40 °C 1000 2.0 **40 °C 2.0   –– – – –

8 Wool 40 °C - 40 °C 800 2.0 ** 2.0   –– – – –

9Eco 40-60 (1)

(Wash) 40 °C 40°C

1351 8.0 3:30 

6.0

    53 0.77 54 33

1351 4 2:45      53 0.65 52 36

1351 2 2:10      53 0.45 37 33

10 20°C 20 °C - 20 °C 1400 8.0 1:50 6.0   –49 0.16 90 22

11 White 60 °C - 90 °C 1400 8.0 2:45 6.0     49 0.90 90 55

12 Anti Allergy 60°C 1400 5.0 **40 °C - 60 °C 5.0     – – – –

13 Steam Refresh – – – 2.0 ** – – – – – – – – – –

14 Ultradelicates 30 °C - 30 °C 0 1.0 ** 1.0   –– – – –

Rinse&Spin – – 1400 8.0 ** 6.0 – – – – – – –

Spin&Drain * – – 1400 8.0 ** 6.0 – – – – – – – –

  Required dosage Optional dosage

9Eco 40-60 (4)

(Wash & Drying) 40 °C 40 °C 1351 6.0 9:20 6.0     0 3.80 75 33

1351 3.0 5:10 3.0     0 1.98 47 32

DISPLAY

678

910

Produkt Specifikationer

Mærke:	Hotpoint
Kategori:	Vaskemaskine
Model:	RDG 8643 WW UK N
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	540 mm
Højde:	850 mm
Vægt:	66000 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.2 m
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	14
Støjniveau (centrifugering):	81 dB
Støjniveau (vask):	81 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Cotton, Delicate/silk, Eco, Hygiene/anti-allergy, Steam, Synthetics, Wool
Børnesikring:	Ja
Justerbare fødder:	Ja
Tromle volumen:	58 L
Dør farve:	Black, White
Spin-tørre klasse:	B
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Støjemissionsklasse:	D
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Visningsvindue:	Ja
Tørreprogrammer:	Cotton, Eco, Synthetics, White clothes, Wool
Tørreevne:	8 kg
Vaske kapacitet:	6 kg
Støjniveau (tørring):	81 dB
Cyklustid vask og tørring:	560 min.
Vandforbrug pr. vask:	48 L
Vandforbrug pr. vask og tørring:	65 L
Anti-krølle funktion:	Ingen
Tilføj tøj (pause) -funktion:	Ja
Lydalarm:	Ja
Energieffektivitetsklasse (vask):	C
Energieffektivitetsklasse (vask og tørring):	D
Energiforbrug pr. 100 cyklusser (vask):	63 kWh
Energiforbrug pr. 100 cyklusser (vask og tørring):	307 kWh
Cyklustid vask:	210 min.
Tænd/sluk-knap:	Ja
Dørgrebets farve:	Hvid
