1
English 1 ..............
Português 10 .......
繁体中文 ......... 13
.............. 16
Español 7 .............
Français 4 ............
Windows
1. For Windows 7 or earlier, do not connect the USB cable before installing
the software. The installation process prompts to connect the cable at
the appropriate time. If the cable is already connected, restart the printer
when installation prompts to connect the cable.
2. Continue to “6. Locate or download the software installation les.”
NOTE: During software installation, select the option to Directly connect
this computer using a USB cable.
Mac
1. Connect the USB cable between the computer and the printer before
installing the software.
2. Continue to “6. Locate or download the software installation les.”
Perform a wireless installation
(M12w wireless models only)
Before starting the installation, verify that the wireless access point is working
correctly. Make sure that the printer, router, and computer are all turned on
and that the computer is connected to the same wireless network that the
printer will be connected to.
If there is not a solid blue light on the top of the printer, go to Process A.
If there is a solid blue light on the top of the printer, go to Process B.
Process A
1. Place the CD in the CD-ROM drive, and then click Install. When the
Printer connections dialog appears, choose Congure to print over
the Wireless Network.
2. Follow the on-screen instructions.
Process B
1. Place the CD in the CD-ROM drive, and then click Install. When the
Printer connections dialog appears, choose Connect to a congured
Wireless Network printer.
2. Follow the on-screen instructions.
3. Select the printer detected by the software. If the printer cannot be
detected by the installer, manually input the printer’s IP address to
continue the installation.
NOTE: Print a conguration page to nd the printer’s IP address. At the
printer control panel, press and hold the Cancel button for 5 seconds,
and then release the Cancel button to print the conguration page. The
IP address is listed on the conguration page in the Network Information
section.
Manually congure the IP address
See the printer user guide for information on how to manually congure the IP
address www.hp.com/support/ljm11-m13.
IMPORTANT:
First, follow Steps 1 - 3
on the printer hardware
setup poster, then continue
with Step 4.
www.hp.com/support/ljm11-m13 www.register.hp.com
LaserJet Pro M11-M13 series
Getting Started Guide
USB connection directly between the
printer and the computer
Use an A-to-B type USB cable.
4.
Set up the Control Panel
At the printer control panel, check the LED status before beginning software installation.
5. Select a connection method
