VDL45ST 1 VELLEMAN

VDL45ST – MINI STROBE 45W

1. Introduction & Features

To all residents of the European Union

Important environmental information about this product

This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm

the environment.

Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised

company for recycling.

This device should be returned to your distributor or to a local recycling service.

Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for buying the VDL45ST! Please read the manual thoroughly before bringing this device into service.

If the device was damaged in transit, don't install or use it and contact your dealer.

2. Safety Instructions

Be very careful during the installation: touching live wires can cause life-threatening electroshocks.

Keep this device away from rain and moisture.

• DO NOT OPEN THE HOUSING!

• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer

will not accept responsibility for any ensuing defects or problems.

• A qualified technician should install and service this device.

• Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the device

against damage by leaving it switched off until it has reached room temperature.

• This device falls under protection class I. It is therefore essential that the device be earthed. Have a qualified

person carry out the electric connection.

• Make sure that the available voltage does not exceed the voltage stated in the specifications of this manual.

• Do not crimp the power cord and protect it against damage. Have an authorised dealer replace it if necessary.

• Disconnect the device from the mains to clean it or when it is not in use. Handle the power cord by the plug only.

• There may be some smoke or a particular smell when the device is activated for the first time. This is normal and

any smoke or smell will gradually disappear.

• Do not look directly at the light source as sensitive people may go into epileptic seizure if they do.

• Note that damage caused by user modifications to the device is not covered by the warranty.

• Keep the device away from children and unauthorised users.

• Do not operate the without or with a cracked glass pane. Have it replaced when it is damaged. VDL45ST

3. General Guidelines

• The should only be used indoors with an alternating current of max. 230V AC/50Hz. VDL45ST

• Do not shake the device. Avoid brute force when installing or operating the device.

•

Select a location where the device is protected against extreme heat, dust and moisture. Respect a minimum

distance of 0.5m between the device’s light output and any illuminated surface.

• Familiarise yourself with the functions of the device before actually using it. Do not allow operation by unqualified

people. Any damage that may occur will most probably be due to unprofessional use of the device.

• Use the original packaging if the device is to be transported.

• All modifications of the device are forbidden for safety reasons.

• Only use the device for its intended purpose. All other uses may lead to short circuits, burns, electroshocks, lamp

explosion, crash, etc. Using the device in an unauthorised way will void the warranty.

VDL45ST 2 VELLEMAN

4. Installation

• The installation construction should be able to support a minimum point load of 10 times the weight of the device.

• The installation must always be secured with a secondary attachment e.g. a safety cable ( or ). VDLSC7 VDLSC8

• Install the device outside the reach of unqualified individuals.

• Never stand directly below the device when it is being mounted, removed or serviced. Have a qualified technician

check the device once a year and once before you bring it into service.

• Overhead mounting requires extensive experience: calculating workload limits, determining the installation

material to be used… Have the material and the device itself checked regularly. Do not attempt to install the

device yourself if you lack these qualifications as improper installation may result in injuries.

• The installation has to be approved by an expert before the device is taken into service.

• The glass pane has to be replaced when it is damaged.

5. Use

1. Connect the stroboscope to the mains and flick the power switch to the ON position.

2. Turn the knob on the backside of the strobe to control the flash frequency (0-15 flashes/sec).

3. Adjust the desired inclination angle via the mounting bracket and tighten the bracket screws.

6. Cleaning and Maintenance

1. All screws should be tightened and free of corrosion.

2. The housing, the glass pane, the mounting supports and the installation location (e.g. ceiling, suspension,

trussing) should not be deformed, modified or tampered with.

3. The electric power supply cables must not show any damage. Have a qualified technician maintain the device.

4. Disconnect the device from the mains prior to maintenance activities.

5. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.

6. There are no user-serviceable parts. Only authorized dealers may maintain and service this device.

7. Technical Specifications

Power Supply max. 230Vac/50Hz

Power Consumption 45W

Dimensions Ø130 x 150mm

Total Weight 0.5kg

Fuse 2A fast-blow, 250V AC (internal)

The information in this manual is subject to change without prior notice.

VDL45ST – MINI STROBOSCOOP 45W

1. Inleiding en kenmerken

Aan alle ingezetenen van de Europese Unie

Belangrijke milieu-informatie betreffende dit product

Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn levenscyclus wordt weggeworpen,

dit toestel schade kan toebrengen aan het milieu.

Gooi dit toestel (en eventuele batterijen) niet bij het gewone huishoudelijke afval; het moet bij een

gespecialiseerd bedrijf terechtkomen voor recyclage.

U moet dit toestel naar uw verdeler of naar een lokaal recyclagepunt brengen.

Respecteer de plaatselijke milieuwetgeving.

Heeft u vragen, contacteer dan de plaatselijke autoriteiten inzake verwijdering.

Produkt Specifikationer

Mærke:	HQ Power
Kategori:	Effektmaskine
Model:	vdl45st
Vægt:	500 g
Produktfarve:	Black,Transparent
Dimensioner (BxDxH):	130 x 130 x 150 mm
Pæreeffekt:	45 W
Antal lamper:	1 Lampe( r)
Indgangsspænding:	230 V
Indgangsfrekvens:	50 Hz
