Side 1/18

Versatile, easy-to-use blade optimized for performance, power and cooling

Please see the Legal Information section for important notices and information.

Product Guide

March 2010

IBM BladeCenter HS22

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options

HS22 Images

HS22 Specifications

The Bottom Line

Server Comparison

For More Information

Legal Information

No compromise, truly balanced, 2-socket blade server

for infrastructure, virtualization and enterprise business

applications

Suggested uses: Front-end and mid-tier applications requiring high performance, enterprise-

class availability and extreme flexibility and power efficiency.

Today’s data center environment is tougher than ever. You are looking to reduce IT cost,

complexity, space requirements, power consumption and heat output, while increasing flexibility,

utilization and manageability. Incorporating IBM X-Architecture

™

features, the IBM

BladeCenter

HS22 blade server, combined with the various BladeCenter chassis, can help

you accomplish all of these goals.

Reducing an entire server into as little as .5U of rack space (i.e., up to 14 servers in 7U) does

not mean trading away features and capabilities for smaller size. Each HS22 blade server offers

features comparable to many 1U rack-optimized full-featured servers: The HS22 supports up to

two of the latest high-performance or low-voltage 6-core, 4-core, and 2-core Intel

Xeon

5500

series and 5600 series processors.. The Xeon processors are designed with up to 12MB of

shared cache and leading-edge memory performance (up to 1333MHz, depending on processor

model) to help provide the computing power you require to match your business needs and

growth. The HS22 supports up to 96GB of registered double data rate III (DDR-3) ECC (Error

Checking and Correcting) memory in 12 DIMM slots, with optional Chipkill

™

protection

, for high

performance and reliability. Selected models are planned for NEBS-3/ETSI-compliance.

The HS22 offers an option for VMware ESXi preloaded on a standard USB flash drive. It

operates in a diskless configuration, offers a smaller memory footprint, extremely high

performance, and stronger security, making getting a system up and running in a virtualized

environment faster and easier than ever before.

An integrated dual-port Gigabit Ethernet

controller is standard, providing high-speed data

transfers and offering TOE (TCP Offload Engine) support, load-balancing and failover

capabilities. Via optional expansion cards, each blade can also connect to additional Ethernet,

SAS, Fibre Channel, iSCSI, InfiniBand

™,

and other high-speed communication switches

housed in the chassis. Optional 2-port and 4-port Expansion Cards add additional fabrics to

the HS22 server as needed. This blade is designed with power management capability to

provide the maximum uptime possible for your systems. In extended thermal conditions or

power brownouts, rather than shut down completely, or fail, the HS22 automatically reduces the

processor frequency to maintain acceptable thermal and power levels.

All HS22 models offer impressive features at an equa

lly impressive price, including up to two

hot-swap SAS or SATA hard disk drives or two hot-swap solid-state drives with RAID-

0/1/1E support, and one USB-based internal flash drive (for embedded hypervisor]. Additional

storage is available via the BladeCenter S chassis. Moreover, the HS22 is optimized for

diskless operation, offering each blade server access to essentially unlimited external storage

capacity via Fibre Channel, SAS, or iSCSI.

A single BladeCenter E or BladeCenter H chassis supports up to 14 hot-swappable 30mm-

wide HS22 blades in only 7U (BladeCenter E) or 9U (BladeCenter H) of rack space or up to 12

in the 12U BladeCenter HT high-speed telecommunications chassis. In addition to the blade

servers, these chassis also hold up to 4 switches (BladeCenter E) or up to 10 (BladeCenter H)

or 8 switches/bridges (BladeCenter HT) internally. The BladeCenter S, designed for SMB and

mid-market customers, takes integration and affordability to a new level, combining up to 12 hot-

swap SAS/SATA HDDs (with optional SAS card) and up to 6 blade servers and 4 switches.

Not only can this save significant data center space (and therefore the cost of floor space and

Chipkill protection on the HS22 requires x4 DIMMs; Chipkill protection is not available with x8 DIMMs.

Actual data transfer speed will vary and is often less than the maximum possible. Gigabit Ethernet transfer speed requires support on both

system and server, and appropriate network infrastructure.

Versatile, easy-to-use blade optimized for performance, power and cooling

Please see the Legal Information section for important notices and information.

rack hardware) compared to 1U servers, it also consolidates switches/bridges and cables for

reduced complexity and lower cabling costs, and it allows clients to manage everything in the

solution as one. Using a BladeCenter E chassis, up to 84 HS22 servers (168 processors) can be

installed in one industry-standard 42U rack; but the value of BladeCenter extends far beyond

high density data center environments.

The various BladeCenter chassis are designed to monitor environmental conditions in the

chassis and each blade and send alerts to the administrator. Advanced standard features, such

as Active Memory

™

, Predictive Failure Analysis

™

, light path diagnostics, hot-swap

redundant hard disk drives, power supplies and blower modules with Calibrated Vectored

Cooling

™

; IPMI 2.0 support, including highly secure remote power control; text-console

redirect over LAN, next-generation BIOS (UEFI), an Advanced Management Module

(upgradeable with a redundant AMM), IBM Systems Director management software including

IBM Systems Director Active Energy Manager™ for x86. Remote Deployment Manager,

and IBM ServerGuide

™

help maintain system availability with increased uptime.

If you need highly manageable, high-performance computing power in a space- or power-

constrained environment, the HS22 is the ideal system.

Selling Features

Price/Performance

• There is an HS22 model to fit all budgets. The HS22 offers a choice of high-performance 6-core/4-

core/2-core Xeon processors with integrated memory controllers, clock rates from 2.00GHz to

3.06GHz, and up to 12MB of shared cache (processor-specific) of integrated L3 cache. Xeon 5600

Series processors offer up to 60% better performance

than the previous-generation 5500 Series

processors and up to 1500% better performance than the single-core processors of a few years ago

that you may still be using.

• Low-voltage processors draw less energy and produce less waste heat than higher-voltage

processors, thus helping to reduce data center energy costs. On a per-core basis, the standard

80W processors are extremely economical, consuming as little as 20W per core. Some low-voltage

Xeon processors consume only 60W (15W per core).

• Up to 96GB of registered DDR-3 ECC memory operates at 800MHz to 1333MHz (depending on

the system configuration), for high performance and wide memory bandwidth.

• Run two DIMMs per memory channel at 1333MHz in 5600 Series processor configurations

• Embedded virtualization (optional on all models) offers extremely high performance, enhanced

security, and a zero-gigabyte HDD footprint. (In other words, no mechanical HDD to fail.)

• Optional solid-state drives (SDDs) use only 2W of energy per drive, vs. 9-10W for 2.5-inch HDDs.

This is as much as 80% less energy than a HDD would use (with a corresponding reduction in heat

output).

• Low power 1.35V memory draws up to 15% less power than current shipping memory DIMMs.

• Selected HS22 blade servers are planned for NEBS3/ETSI-compliance and feature long-life

availability. These blades are ideal for telecom or Next Generation Network (NGN) applications

such as IPTV, IP Multimedia Subsystem (IMS) and security.

• The extremely high degree of integration in the various BladeCenter chassis reduces the need

for server components, replacing numerous fans, KVM and Ethernet cables, power supplies,

external switches and other components with fewer shared hot-swap/redundant components in the

BladeCenter chassis itself. This integration also can greatly reduce the amount of power

consumed and heat produced, relative to an equivalent number of 1U servers. This can

significantly reduce a data center power bill. The reduced datacenter footprint can also save on

infrastructure cost.

• The midplanes used in all chassis provide high-speed blade-to-blade, blade-to-switch-module

and module-to-module communications internally as well as externally. The midplanes used in

the BladeCenter H and BladeCenter HT chassis provide four 10Gb data channels to each blade,

and supports high-speed switch modules, including 4X InfiniBand and 10Gb Ethernet.

• The various BladeCenter chassis use ultrahigh efficiency power supplies. Most industry-

standard servers use power supplies that are between 70-75% efficient at converting power from

AC wall current to the DC power used inside servers. BladeCenter power modules are up to 92%

efficient. This helps save even more money, as more of the power input you are paying for is used

for processing, rather than released into the data center as waste heat that requires even more

energy to cool.

• BladeCenter also reduces the number of parts required to run the system. Sharing fans, systems

management, floppy devices and media means fewer parts to buy and maintain, and fewer items

that can fail and bring the overall solution down.

Based on Intel measurements.

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	BladeCenter HS22 7870GCY
Bredde:	29 mm
Dybde:	446 mm
Højde:	245 mm
Vægt:	5400 g
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	1
Processorkerner:	4
Intern hukommelse:	6 GB
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	2.66 GHz
Processorserie:	Intel® Xeon® 5000 Sequence
Processor boost frekvens:	2.93 GHz
Processortråde:	8
Processor-cache:	12 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1333 MHz
Maksimal intern hukommelse:	96 GB
Samlet lagringskapacitet:	0 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	1.0
Kompatible operativsystemer:	Microsoft Windows, Linux, Sun Solaris & VMware
Hukommelsesstik:	12x DIMM
Processorproducent:	Intel
Processormodel:	E5640
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Grafikadapter:	RN50
HDD-grænseflade:	Serial Attached SCSI (SAS)
Netværksfunktioner:	1000Mbps, 100Mbps, 10MBps
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Blade
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	2.5 "
Processor sokkel:	Socket B (LGA 1366)
Processor litografi:	32 nm
Stepping:	B1
Thermal Design Power (TDP):	80 W
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	5.86 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Westmere EP
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ingen
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	42.5 X 45 mm
Processor ARK ID:	47923
CPU-multiplikator (bus/kerneforhold):	20
Understøttede instruktionssæt:	SSE4.2
Maksimal lagerkapacitet:	0.6 TB
Redundant strømforsyning:	Ingen
Antal understøttede HHD'er:	2
Hukommelsestype for grafikadapter:	GDDR
Bundkort chipsæt:	Intel® 5520
Maksimal grafikadapterhukommelse:	16 MB
Hot-swap:	Ja
Maksimal intern hukommelse understøttet af processor:	288 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800,1066 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	25.6 GB/sek.
Tcase:	77.6 °C
Maksimalt antal SMP-processorer:	2
Fysisk adresse udvidelse (PAE):	40 Bit
Antal QPI-lins:	2
Hukommelseskanaler understøttet af processor:	Tredobbelt
Skærmkort opløsning:	1024 x 768
