Versatile, easy-to-use blade optimized for performance, power and cooling
Please see the Legal Information section for important notices and information. 1.
Product Guide
March 2010
IBM BladeCenter HS22
Product Overview
CONTENTS
Product Overview 1
Selling Features 2
Key Features 5
Key Options 12
HS22 Images 13
HS22 Specifications 14
The Bottom Line 16
Server Comparison 17
For More Information 18
Legal Information 18
No compromise, truly balanced, 2-socket blade server
for infrastructure, virtualization and enterprise business
applications
Suggested uses: Front-end and mid-tier applications requiring high performance, enterprise-
class availability and extreme flexibility and power efficiency.
Today’s data center environment is tougher than ever. You are looking to reduce IT cost,
complexity, space requirements, power consumption and heat output, while increasing flexibility,
utilization and manageability. Incorporating IBM X-Architecture™ features, the IBM®
BladeCenter® HS22 blade server, combined with the various BladeCenter chassis, can help
you accomplish all of these goals.
Reducing an entire server into as little as .5U of rack space (i.e., up to 14 servers in 7U) does
not mean trading away features and capabilities for smaller size. Each HS22 blade server offers
features comparable to many 1U rack-optimized full-featured servers: The HS22 supports up to
two of the latest high-performance or low-voltage , , and 6-core 4-core 2-core Intel® Xeon® 5500
series and 5600 series processors.. The Xeon processors are designed with up to of 12MB
shared cache and leading-edge memory performance (up to 1333MHz, depending on processor
model) to help provide the computing power you require to match your business needs and
growth The HS22 supports up to .96GB of registered DDR-3 ECC double data rate III ( ) (Error
Checking and Correcting) memory in DIMM slots, with optional 12 Chipkill™ protection1, for high
performance and reliability. Selected models are planned for NEBS-3/ETSI-compliance.
The HS22 offers an option for VMware ESXi preloaded on a standard USB flash drive. It
operates in a diskless configuration, offers a smaller memory footprint, extremely high
performance, and stronger security, making getting a system up and running in a virtualized
environment faster and easier than ever before.
An integrated dual-port Gigabit Ethernet 2 controller is standard, providing high-speed data
transfers and offering (TCP Offload Engine) support, TOE load-balancing failover and
capabilities. Via optional expansion cards, each blade can also connect to additional Ethernet,
SAS Fibre Channel iSCSI, InfiniBand, , ™,
and other high-speed communication switches
housed in the chassis. Optional and2-port 4-port Expansion Cards add additional fabrics to
the HS22 server as needed. This blade is designed with power management capability to
provide the maximum uptime possible for your systems. In extended thermal conditions or
power brownouts, rather than shut down completely, or fail, the HS22 automatically reduces the
processor frequency to maintain acceptable thermal and power levels.
All HS22 models offer impressive features at an equally impressive price, including up to two
hot-swap SAS or SATA hard disk drives two hot-swap solid-state drives or with RAID-
0/1/1E support, and one USB-based internal flash drive (for embedded hypervisor]. Additional
storage is available via the BladeCenter S chassis. Moreover, the HS22 is optimized for
diskless operation, offering each blade server access to essentially unlimited external storage
capacity via Fibre Channel, SAS, or iSCSI.
A single BladeCenter E BladeCenter H or chassis supports up to 30mm-14 hot-swappable
wide HS22 blades in only (BladeCenter E) or (BladeCenter H) of rack space or up to 7U 9U 12
in the 12U BladeCenter HT high-speed telecommunications chassis. In addition to the blade
servers, these chassis also hold up to 4 switches (BladeCenter E) or up to 10 (BladeCenter H)
or 8 switches/bridges (BladeCenter HT) internally. The BladeCenter S, designed for SMB and
mid-market customers, takes integration and affordability to a new level, combining up to hot-12
swap SAS/SATA HDDs (with optional SAS card) and up to 6 blade servers 4 switches and .
Not only can this save significant data center space (and therefore the cost of floor space and
1 Chipkill protection on the HS22 requires x4 DIMMs; Chipkill protection is not available with x8 DIMMs.
2 Actual data transfer speed will vary and is often less than the maximum possible. Gigabit Ethernet transfer speed requires support on both
system and server, and appropriate network infrastructure.
Versatile, easy-to-use blade optimized for performance, power and cooling
Please see the Legal Information section for important notices and information. 2.
rack hardware) compared to 1U servers, it also consolidates switches/bridges and cables for
reduced complexity and lower cabling costs, and it allows clients to manage everything in the
solution as one. Using a BladeCenter E chassis, up to HS22 servers ( processors) can be 84 168
installed in one industry-standard 42U rack; but the value of BladeCenter extends far beyond
high density data center environments.
The various BladeCenter chassis are designed to monitor environmental conditions in the
chassis and each blade and send alerts to the administrator Advanced standard features, such .
as Active Memory™, Predictive Failure Analysis™, light path diagnostics hot-swap ,
redundant hard disk drives power supplies and blower modules Calibrated Vectored , with
Cooling™; support, includingIPMI 2.0 highly secure remote power control text-console ;
redirect over LAN, next-generation BIOS ( ), an UEFI Advanced Management Module
(upgradeable with a redundant AMM), IBM Systems Director management software including
IBM Systems Director Active Energy Manager™ for x86 Remote Deployment Manager. ,
and IBM ServerGuide™ help maintain system availability with increased uptime.
If you need highly manageable, high-performance computing power in a space- or power-
constrained environment, the HS22 is the ideal system.
Selling Features Price/Performance
• There is an HS22 model to fit all budgets. The HS22 offers a choice of high-performance 6-core/4-
core/2-core Xeon processors with integrated memory controllers, clock rates from 2.00GHz to
3.06GHz, and up to 12MB of shared cache (processor-specific) of integrated L3 cache. Xeon 5600
Series processors offer up to 60% better performance3 than the previous-generation 5500 Series
processors and up to 1500% better performance than the single-core processors of a few years ago
that you may still be using.
• Low-voltage processors draw less energy and produce less waste heat than higher-voltage
processors, thus helping to reduce data center energy costs. On a per-core basis, the standard
80W processors are extremely economical, consuming as little as 20W per core. Some low-voltage
Xeon processors consume only 60W (15W per core).
• Up to 96GB of registered DDR-3 ECC memory operates at 800MHz to 1333MHz (depending on
the system configuration), for high performance and wide memory bandwidth.
• Run two DIMMs per memory channel at 1333MHz in 5600 Series processor configurations
• Embedded virtualization (optional on all models) offers extremely high performance, enhanced
security, and a zero-gigabyte HDD footprint. (In other words, no mechanical HDD to fail.)
• Optional solid-state drives (SDDs) use only 2W of energy per drive, vs. 9-10W for 2.5-inch HDDs.
This is as much as 80% less energy than a HDD would use (with a corresponding reduction in heat
output).
• Low power 1.35V memory draws up to 15% less power than current shipping memory DIMMs.
• Selected HS22 blade servers are planned for NEBS3/ETSI-compliance and feature long-life
availability. These blades are ideal for telecom or Next Generation Network (NGN) applications
such as IPTV, IP Multimedia Subsystem (IMS) and security.
• The extremely high degree of integration in the various BladeCenter chassis reduces the need
for server components, replacing numerous fans, KVM and Ethernet cables, power supplies,
external switches and other components with fewer shared hot-swap/redundant components in the
BladeCenter chassis itself. This integration also can greatly reduce the amount of power
consumed and heat produced, relative to an equivalent number of 1U servers. This can
significantly reduce a data center power bill. The reduced datacenter footprint can also save on
infrastructure cost.
• The midplanes used in all chassis provide high-speed blade-to-blade, blade-to-switch-module
and module-to-module communications internally as well as externally. The midplanes used in
the BladeCenter H and BladeCenter HT chassis provide four 10Gb data channels to each blade,
and supports high-speed switch modules, including 4X InfiniBand and 10Gb Ethernet.
• The various BladeCenter chassis use ultrahigh efficiency power supplies. Most industry-
standard servers use power supplies that are between 70-75% efficient at converting power from
AC wall current to the DC power used inside servers. BladeCenter power modules are up to 92%
efficient. This helps save even more money, as more of the power input you are paying for is used
for processing, rather than released into the data center as waste heat that requires even more
energy to cool.
• BladeCenter also reduces the number of parts required to run the system. Sharing fans, systems
management, floppy devices and media means fewer parts to buy and maintain, and fewer items
that can fail and bring the overall solution down.
3 Based on Intel measurements.
