Product Guide

February 2011

IBM System x3400 M3

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options

x3400 M3 Images

x3400 M3 Specifications

The Bottom Line

Server Comparison Table

For More Information 1

Legal Information 1

IBM System x3400 M3 provides flexible capabilities and outstanding

performance that drives affordable business growth

Suggested uses: Small/medium businesses, large multilocation enterprises and bank branch offices

seeking scalability, top performance and availability features at an entry-level price.

The dual-socket IBM

System x3400 M3, incorporating IBM X-Architecture

™

features, provides

outstanding value to workgroups by combining scalable performance and availability features at an

outstanding price. The x3400 M3 supports the latest 4-core Intel

Xeon

™

5600 series (Westmere)

and 2- and 4-core Xeon 5500 (Nehalem) processors, designed with up to 1066MHz memory access

and 12MB or 4MB of L3 cache, Turbo Boost, and Hyper-Threading Technology (processor-

specific), to help provide you with the computing power you need to match your business needs and

growth. For maximum performance, x3400 M3 also supports the latest 6-core Xeon 5600 series

processors with up to 1333Mhz memory access and 12MB L3 cache, by CTO only. In addition, the

x3400 M3 supports industry-standard registered DDR-3 memory with Chipkill

™

ECC (Error

Checking and Correcting) protection—for high performance, energy savings, and reliability. For even

higher levels of availability, the x3400 M3 also offers memory mirroring. A dual-port integrated

high-speed Gigabit Ethernet controller is standard, as are high-performance PCIe adapter slots and

a legacy PCI-32 slot to support legacy expansion cards.

All models offer impressive scalability, including dual-processor support and up to 128GB of

memory. Some models supports up to 8 or 2.5-inch hot-swap Serial-Attach SCSI (SAS) or Serial

ATA II (SATA II) HDDs, with up to 4TB

capacity, or up to 16 or 2.5-inch hot-swap SAS or SATA II

HDDs, with up to 8TB capacity. Other models support up to 4 3.5-inch hot-swap SAS HDDs with up

to 2.4TB capacity, or 4 3.5-inch hot-swap or simple-swap SATA HDDs with up to 8TB capacity.

For additional storage requirements, Configure-to-Order (CTO) models are available with support for

up to 8 3.5-inch hot-swap SATA/SAS HDDs, or up to 16 2.5-inch HDDs. For advanced performance

and high availability, the four-drive hot-swap x3400 M3 models include an IBM ServeRAID

BR10il V2 controller, providing RAID-0/1/1E support. The IBM ServeRAID

-M1015 controller,

providing RAID-0/1/10 with an option to upgrade to RAID 5 is standard on 8-drive 2.5-inch models,

while the ServeRAID-5014 controller, which provides RAID-0/1/10/5/50 support (upgradeable to

RAID-6/60) and includes 256GB of cache memory, is standard on 16-drive 2.5-inch models.

Additional RAID support is optionally available via the IBM ServeRAID family of SAS/SATA

controllers. The x3400 M3 ships as a tower unit; a tower-to-rack option is available, or CTO models

can be ordered as a 5U rack-mounted server to help save precious data center floor space.

Standard in the x3400 M3 is an Integrated Management Module (IMM) that enables users to

manage and control the server easily—both locally and, using an optional Virtual Media Key,

remotely. Unified Extensible Firmware Interface (UEFI) is an evolutionary leap over legacy BIOS.

This high level of manageability is designed to keep costs down and the system up—even when

network usage increases. These advanced features help maximize network availability by increasing

uptime, as do hot-swap/redundant HDDs; Active Memory

™

; temperature-controlled fans with

Calibrated Vectored Cooling

™

; industry-standard IPMI 2.0 support, including highly secure

remote power control and Serial over LAN; as well as text-console redirect over LAN.

With the inclusion of unique IBM service and support features such as IBM Systems Director, IBM

Systems Director Active Energy Manager, ServerGuide

™

, and

the IMM, the x3400 M3 is as

equally well designed for a locally managed data center environment as for a remotely managed or

stand-alone environment, while offering maximum availability.

For a balance of high-performance two-, four-, or six-core, dual-socket processing, high availability

and vast internal SAS storage at a budget price, the x3400 M3 is the ideal system.

GB equals 1,000,000,000 bytes and TB equals 1,000,000,000,000 bytes when referring to hard disk drive capacity. Accessible

capacity may be less.

The engine of growth for your emerging businesses.

Please see the Legal Information section for important notices and information.

Selling Features

Price/Performance

The x3400 M3 offers numerous features to boost performance and reduce product and operating

costs:

• Up to two 4- or 6-core Xeon 5600 Series processors and 12MB of shared cache per processor,

offer superior performance capable of tackling the toughest jobs. 2- and 4-core Xeon 5500 series

processors are available for lower entry points. Xeon 5600 series processors offer up to 43%

better performance than the previous-generation 5500 series processors and up to 900% better

performance than the single-core processors of a few years ago that you may still be using.

• Sixteen DIMMs of fast registered 1333MHz (or 1066MHz) DDR3 ECC memory with Chipkill

protection (optional) provides speed, high availability, and a memory capacity of up 128GB.

• Four high-speed PCIe Gen 2 adapter slots offer investment protection by supporting high-

performance adapters, such as 10Gb Ethernet, Fibre Channel and InfiniBand

™

cards, none of

which will run in older conventional PCI slots. A legacy PCI/33 adapter slot offers support for older

adapters.

• The integrated ServeRAID-BR10il V2 controller (model-specific) provides RAID-0/1/1E and full-

duplex (bidirectional 3GBps) data transfers for SAS/SATA/SSD drives. Other server models

include the 6Gbps ServeRAID-M1015 controller standard, which provides RAID-0/1/10/5

(optional RAID-50/6/60 with Self-Encrypting Disk, or SED) or the 6Gbps ServeRAID-M5014

controller standard, which provides RAID-0/1/10/5/50 (optional 6/60 with SED).

• Support for up to 4 3.5-inch hot-swap SAS or SATA II hard disk drives or up to 16 2.5-inch hot-

swap SAS/SATA drives offers high-performance with high availability (model-specific). The

integrated SAS controller provides full-duplex 6Gbps data transfers for SAS drives. For lower cost

and high capacity, other models support up to 4 simple-swap SATA II drives. CTO models are

available to support 8 3.5-inch hot-swap SAS or SATA II drives.

• The integrated dual-port Gigabit Ethernet controller with IPMI 2.0 support provides high-speed

network communications.

• A high degree of device integration, including SAS/SATA, Gigabit Ethernet, systems

management and video controllers, lowers costs and frees up valuable adapter slots.

• Energy-efficient components, including low-voltage transistors and voltage regulator modules,

and power supplies that are up to 90% efficient, help keep your energy bills down.

Flexibility

The x3400 M3 has the ability to grow with your application requirements, thanks to:

• A choice of 2-core or 4-core processors starting at 1.6GHz and up to 2.66GHz clock rates, up to

5.86 Gigatransfers per second (GTps), and 80W maximum power draw. For more advanced

processing power, a choice of 6-core processors up to 3.06GHz clock rates and 6.4 GTps with

95W power draw is available via CTO.

• Up to 128GB of high-speed registered DDR-3 system memory.

• Five available high-performance PCIe adapter slots and one legacy PCI slot in all models.

Optionally, a riser card supporting two PCI-X/133 adapters or one additional PCIe can be

selected via Configure-to-Order (CTO) models.

• Upgrading to the ServeRAID-M5014 or ServeRAID-M5015 controller provides 256MB or 512MB

of battery-backed cache (respectively) to enable higher-performance hardware RAID support, and

allows the x3400 M3 to offer five RAID levels standard: RAID-0/1/10/5/50 (and optionally 6/60

with Self-Encrypting Disk).

• The eight USB 2.0 ports (six external, two internal) are up to 40X faster

than older USB 1.1

ports. This provides speedy access to external HDDs (non-arrayed), floppy drives, flash drives,

optical drives, tape drives, and other USB devices. Two ports are on the front of the unit and four

are on the back.

• Up to 4 internal 3.5-inch simple- or hot-swap SATA, or hot-swap SAS HDDs, or up to 16 2.5-

inch hot-swap SAS or SATA drives, plus 5.25-inch bays for a half- or full-high tape drive are

standard. CTO models are available to increase 3.5-inch storage support to a maximum of 8 3.5-

inch hot-swap SAS/SATA drives (with no tape drive support and slim optical device only). This

translates into as much as 16TB of internal 3.5-inch hot-swap SAS or SATA, 8GB of 3.5-inch

simple-swap SATA, 9.6TB of 2.5-inch hot-swap SAS, or 8TB of 2.5-inch hot-swap SATA

storage, providing tremendous internal storage capability, along with full data backup.

Manageability / Security

Powerful systems management features simplify local and remote management of the x3400 M3:

• The x3400 M3 includes an Integrated Management Module (IMM) to monitor server availability,

All models require Chipkill-enabled DIMMs for Chipkill protection.

Data transfer rates may be less than the maximum possible.

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	eServer 7379K4G
Bredde:	218 mm
Dybde:	767 mm
Højde:	440 mm
Vægt:	27100 g
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	6
Ethernet LAN:	Ja
Processorkerner:	4
Intern hukommelse:	4 GB
Dimensioner (BxDxH):	440 x 218 x 767 mm
Effektkrav:	230V 50Hz
Intel® Wireless Display (Intel® WiDi):	Ingen
Mac kompabilitet:	Ingen
Processorfrekvens:	2.4 GHz
Processorserie:	Intel® Xeon® 5000 Sequence
Processor boost frekvens:	2.66 GHz
Processortråde:	8
Processor-cache:	12 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1333 MHz
Maksimal intern hukommelse:	128 GB
Samlet lagringskapacitet:	0 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	1.0
Kompatible operativsystemer:	Windows Server 2008 R2, Red Hat Linux, SUSE Linux, VMware ESX Server
Hukommelsesstik:	16
Processorproducent:	Intel
Processormodel:	E5620
Antal VGA-porte (D-sub):	1
Optisk drevtype:	DVD-RW
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ja
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Grafikadapter:	G200e
Netværksfunktioner:	10/100/1000
Antal serielle porte:	1
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Tower (5U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	2.5 "
Strømforsyning:	920 W
Anbefalet driftstemperaturområde (T-T):	10 - 30 °C
Processor sokkel:	Socket B (LGA 1366)
Processor litografi:	32 nm
Stepping:	B1
Thermal Design Power (TDP):	80 W
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	5.86 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Westmere EP
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ingen
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	42.5 X 45 mm
Processor kode:	SLBV4
Processor ARK ID:	47925
CPU-multiplikator (bus/kerneforhold):	18
Understøttede instruktionssæt:	SSE4.2
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	8 TB
Redundant strømforsyning:	Ingen
Hukommelsestype for grafikadapter:	GDDR2
Bundkort chipsæt:	Intel® 5500
Maksimal grafikadapterhukommelse:	16 MB
Hot-swap:	Ja
Billedtypekort:	<div><img src="https://ark.intel.com/inc/images/diagrams/diagram-19.gif" title="Block Diagram" /></div>
Maksimal intern hukommelse understøttet af processor:	288 GB
Hukommelsestyper understøttet af processor:	DDR3 800/1066
Hukommelsesurhastigheder understøttet af processor:	800,1066 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	25.6 GB/sek.
Tcase:	77.6 °C
Fysisk adresse udvidelse (PAE):	40 Bit
Antal QPI-lins:	2
Antal strømforsyninger:	1
Anbefalet luftfugtighed ved drift:	10 - 75 %
Hukommelseskanaler understøttet af processor:	Tredobbelt
