The engine of growth for your emerging businesses.
Please see the Legal Information section for important notices and information. 1
Product Guide
February 2011
IBM System x3400 M3
Product Overview
CONTENTS
Product Overview
1
Selling Features
1
Key Features
3
Key Options
11
x3400 M3 Images
13
x3400 M3 Specifications
14
The Bottom Line
17
Server Comparison Table
1
8
For More Information 1
9
Legal Information 1
9
IBM System x3400 M3 provides flexible capabilities and outstanding
performance that drives affordable business growth
Suggested uses: Small/medium businesses, large multilocation enterprises and bank branch offices
seeking scalability, top performance and availability features at an entry-level price.
The IBMdual-socket ® System , incorporating IBM x3400 M3 X-Architecture
™ features, provides
outstanding value to workgroups by combining scalable performance and availability features at an
outstanding price. The x3400 M3 supports the latest Intel4-core ® Xeon™ 5600 series (Westmere)
and - and -core Xeon 5500 (Nehalem) processors, designed with up to memory access 2 4 1066MHz
and or of L3 cache, , and (processor-12MB 4MB Turbo Boost Hyper-Threading Technology
specific), to help provide you with the computing power you need to match your business needs and
growth. For maximum performance, x3400 M3 also supports the latest 5600 series 6-core Xeon
processors with up to memory access and L3 cache, by CTO only. In addition, the 1333Mhz 12MB
x3400 M3 supports industry-standard memory with registered DDR-3 Chipkill
™ (Error ECC
Checking and Correcting) protection—for high performance, energy savings, and reliability. For even
higher levels of availability, the x3400 M3 also offers . A integrated memory mirroring dual-port
high-speed controller is standard, as are high-performance PCIe adapter slots and Gigabit Ethernet
a legacy PCI-32 slot to support legacy expansion cards.
All models offer impressive scalability, including dual-processor support and up to of 128GB
memory. Some models supports up to or -inch ( ) or 8 2.5 hot-swap Serial-Attach SCSI SAS Serial
ATA II 4TB (SATA II) HDDs, with up to 1 capacity, or up to or -inch or 16 2.5 hot-swap SAS SATA II
HDDs, with up to capacity. Other models support up to -inch HDDs with up 8TB 4 3.5 hot-swap SAS
to capacity, -inch HDDs with up to capacity. 2.4TB or 4 3.5 hot-swap or simple-swap SATA 8TB
For additional storage requirements, Configure-to-Order (CTO) models are available with support for
up to -inch SATA/SAS HDDs, or up to HDDs. For advanced performance 8 3.5 hot-swap 16 2.5-inch
and high availability, the x3400 M3 models include an IBM four-drive hot-swap ServeRAID
®-
BR10il V2 RAID-0/1/1E controller, providing support. The IBM ServeRAID®-M1015 controller,
providing with an option to upgrade to is standard on 2.5-inch models, RAID-0/1/10 RAID 5 8-drive
while the controller, which provides support (upgradeable to ServeRAID-5014 RAID-0/1/10/5/50
RAID-6/60) and includes of cache memory, is standard on 2.5-inch models. 256GB 16-drive
Additional RAID support is optionally available via the IBM ServeRAID family of SAS/SATA
controllers. The x3400 M3 ships as a tower unit; a tower-to-rack option is available, or CTO models
can be ordered as a rack-mounted server to help save precious data center floor space. 5U
Standard in the x3400 M3 is an that enables users to Integrated Management Module (IMM)
manage and control the server easily—both locally and, using an optional Virtual Media Key,
remotely. Unified Extensible Firmware Interface ( ) is an evolutionary leap over legacy BIOS. UEFI
This high level of manageability is designed to keep costs down and the system up—even when
network usage increases. These advanced features help maximize network availability by increasing
uptime, as do ; hot-swap/redundant HDDs Active Memory
™; withtemperature-controlled fans
Calibrated Vectored Cooling™; industry-standard support, includingIPMI 2.0 highly secure
remote power control Serial over LAN text-console redirect over LAN and ; as well as .
With the inclusion of unique IBM service and support features such as IBM Systems Director IBM ,
Systems Director Active Energy Manager ServerGuide, ™, and the IMM, the x3400 M3 is as
equally well designed for a locally managed data center environment as for a remotely managed or
stand-alone environment, while offering maximum availability.
For a balance of high-performance two-, four-, or six-core, dual-socket processing, high availability
and vast internal SAS storage at a budget price, the x3400 M3 is the ideal system.
1 GB equals 1,000,000,000 bytes and TB equals 1,000,000,000,000 bytes when referring to hard disk drive capacity. Accessible
capacity may be less.
The engine of growth for your emerging businesses.
Please see the Legal Information section for important notices and information. 2
Selling Features Price/Performance
The x3400 M3 offers numerous features to boost performance and reduce product and operating
costs:
• Up to or Xeon 5600 Series processors and of shared cache per processor, two 4- 6-core 12MB
offer superior performance capable of tackling the toughest jobs. 2- and Xeon 5500 series 4-core
processors are available for lower entry points. Xeon 5600 series processors offer up to 43%
better performance than the previous-generation 5500 series processors and up to 900% better
performance than the single-core processors of a few years ago that you may still be using.
• DIMMs of fast registered (or ) ECC memory with Sixteen 1333MHz 1066MHz DDR3 Chipkill2
protection (optional) provides speed, high availability, and a memory capacity of up . 128GB
• offer investment protection by supporting high-Four high-speed PCIe Gen 2 adapter slots
performance adapters, such as 10Gb Ethernet, Fibre Channel and InfiniBand
™ cards, none of
which will run in older conventional PCI slots. A legacy PCI/33 adapter slot offers support for older
adapters.
• The integrated controller (model-specific) provides and full-ServeRAID-BR10il V2 RAID-0/1/1E
duplex ( ) data transfers for SAS/SATA/SSD drives. Other server models bidirectional 3GBps
include the controller standard, which provides /6Gbps ServeRAID-M1015 RAID-0 1/10/5
(optional with , or ) or the RAID-50/6/60 Self-Encrypting Disk SED 6Gbps ServeRAID-M5014
controller standard, which provides / (optional with ). RAID-0 1/10/5/50 6/60 SED
• Support for up to or hard disk drives or up to 4 3.5-inch hot-swap SAS SATA II 16 2.5-inch hot-
swap SAS/SATA drives offers high-performance with high availability (model-specific). The
integrated SAS controller provides full-duplex data transfers for SAS drives. For lower cost 6Gbps
and high capacity, other models support up to drives. CTO models are 4 simple-swap SATA II
available to support or drives. 8 3.5-inch hot-swap SAS SATA II
• The integrated controller with support provides high-speed dual-port Gigabit Ethernet IPMI 2.0
network communications.
• A , including SAS/SATA, Gigabit Ethernet, systems high degree of device integration
management and video controllers, lowers costs and frees up valuable adapter slots.
• Energy-efficient components, including low-voltage transistors and voltage regulator modules,
and power supplies that are up to 90% efficient, help keep your energy bills down.
Flexibility
The x3400 M3 has the ability to grow with your application requirements, thanks to:
• A choice of or processors starting at and up to clock rates, up to 2-core 4-core 1.6GHz 2.66GHz
5.86 Gigatransfers per second 80W (GTps), and maximum power draw. For more advanced
processing power, a choice of processors up to clock rates and with 6-core 3.06GHz 6.4 GTps
95W power draw is available via CTO .
• Up to of high-speed registered system memory. 128GB DDR-3
• adapter slots and one Five available high-performance PCIe legacy PCI slot in all models.
Optionally, a riser card supporting or can be two PCI-X/133 adapters one additional PCIe
selected via Configure-to-Order (CTO) models.
• Upgrading to the or controller provides or ServeRAID-M5014 ServeRAID-M5015 256MB 512MB
of battery-backed cache (respectively) to enable higher-performance hardware RAID support, and
allows the x3400 M3 to offer five RAID-0/1/10/5 50 6/60 RAID levels standard: / (and optionally
with . Self-Encrypting Disk)
• The ports (six external, two internal) are up to fastereight USB 2.0 40X 3 than older USB 1.1
ports. This provides speedy access to external HDDs (non-arrayed), floppy drives, flash drives,
optical drives, tape drives, and other USB devices. Two ports are on the front of the unit and four
are on the back.
• internal or , , or up to Up to 4 3.5-inch simple- hot-swap SATA or hot-swap SAS HDDs 16 2.5-
inch hot-swap SAS SATA drives half- full-high tape driveor , plus 5.25-inch bays for a or are
standard. CTO models are available to increase 3.5-inch storage support to a maximum of 8 3.5-
inch hot-swap SAS/SATA drives (with no tape drive support and slim optical device only). This
translates into as much as of internal -inch or , of -inch16TB 3.5 hot-swap SAS SATA 8GB 3.5
simple-swap SATA 9.6TB, of -inch or of -inch 2.5 hot-swap SAS, 8TB 2.5 hot-swap SATA
storage, providing tremendous internal storage capability, along with full data backup.
Manageability / Security
Powerful systems management features simplify local and remote management of the x3400 M3:
• The x3400 M3 includes an to monitor server availability, Integrated Management Module (IMM)
2 All models require Chipkill-enabled DIMMs for Chipkill protection.
3 Data transfer rates may be less than the maximum possible.
