Side 1/19

Leadership enterprise server with significantly lower cost of ownership in a highly available and

expandable, rack-dense, 1U dual-socket server

Please see the Legal Information section for important notices and information.

Product Guide

December 2009

IBM System x3550 M2

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options

x3550 M2 Images

x3550 M2 Specifications

The Bottom Line

Server Comparison

For More Information

Legal Information

Outstanding innovation in only 1U

Suggested Uses: All sectors requiring highly available, energy-efficient, rack-optimized solution

for physical and virtual intensive commercial environments like eBusiness/eCommerce,

collaboration, virtualization, database, and enterprise resource planning applications.

Your challenge is to do more with less—serve more Web pages, handle more secure

connections, support more e-mail users. You need to reduce the costs of doing business and

improve the service you deliver to your customers while lowering your overall risk. The dual-

socket IBM

System x3550 M2 can reduce your costs with its new energy smart design. It can

improve service with reduced operational complexity and increased management functionality. It

will lower your IT risk with the resiliency that comes from no single point of failure. And like all

IBM servers, the x3550 M2 offers you the trust that comes from the IBM global reach, service and

support.

The x3550 M2 is not simply an upgrade to a previous server. It is one of our new generation of

X-Architecture servers. It is a game-changing, completely redesigned rack server using

significantly less power with unified systems management tools, leadership reliability, availability,

serviceability features and broad systems flexibility housed in a compact 1U mechanical package.

The x3550 M2 features Intel

Xeon

5500 Series 4-core and 2-core processors and either 8MB

or 4MB of shared cache, to help provide you with the computing power you need to match your

business needs and growth. This new line of Intel processors delivers unprecedented intelligent

performance with features like adaptive performance for applications and environments, turbo

boost and hyper-threading technology, and integrated power gates and automated power

management.

The x3550M2 uses up to 16 DIMMs with 128GB of registered 1333MHz DDR3 memory with

Chipkill

™

ECC (Error Checking and Correcting) protection—for high performance and reliability.

For even higher levels of availability, the x3550M2 also offers online memory mirroring. Up to 4

integrated high-speed Gigabit Ethernet controllers with TOE (TCP Offload Engine) and Jumbo

Frame support are available, as are two high-performance adapter slots (PCIe x16). The

x3550M2 offers an optional embedded hypervisor to manage your virtual workloads.

The x3550 M2 offers a choice of up to six high-performance hot-swap hard disk drives with an

internal storage capacity of 3.0TB (six 2.5-inch hot-swap Serial-Attached SCSI (SAS) or SATA

HDDs) Optional solid-state drives are also available to keep power low and improve resiliency and

offer up to 300GB of storage. The server supports a choice of four IBM ServeRAID

storage

controllers which provide broad levels of hardware-based RAID solutions. The ultradense 1U

form factor allows businesses to increase their computing power and spread their workload

without outgrowing their current data center. Up to 42 of these 1U servers can be installed in a

single 42U rack, for a total of up to 84 processors and 336 processor cores, offering tremendous

deployment flexibility. Optional Advanced Connectivity Technology (ACT) interconnect cabling

reduces cable clutter and cost and minimizes installation time when interconnecting many rack-

mounted servers.

Standard in the x3550 M2 is the Integrated Management Module (IMM) that enables the user to

manage and control the server easily—both locally and remotely. In conjunction with the IMM, the

x3550 M2 comes with an altitude sensor (altimeter) that governs fan rotation based on

altitude, to help lower your energy consumption. The IMM offers a high level of manageability that

is designed to keep costs down and the system up—even when network usage increases. IBM’s

innovative pop-out/drop-down light path diagnostics panel enables quick servicing of the

system if a problem develops. These advanced features help maximize network availability by

increasing uptime, as do hot simple-swap solid-state drives; hot-swap/redundant SAS or

SATA HDDs, redundant ultra-efficient power supplies and fan modules; Active Memory

™

;

integrated RAID; temperature-controlled fans with Calibrated Vectored Cooling

™

; IPMI 2.0

support, including highly secure remote power control and Serial over LAN; as well as text-

console redirect over LAN.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

expandable, rack-dense, 1U dual-socket server

Please see the Legal Information section for important notices and information.

Another improvement with the new generation of X-Architecture is the replacement of legacy

BIOS with a new generation United Extensible Firmware Interface (UEFI). UEFI provides a

more intuitive user interface and understandable event logs and better management.

With the inclusion of unique IBM service and support features such as the IMM, light path

diagnostics, IBM Systems Director 6.1, IBM Systems Director Active Energy Manager

™

, IBM

ServerGuide

™

and

support for the optional Virtual Media Key for remote presence capability, the

x3550 M2 is designed for superior uptime.

If you need highly manageable, dual-socket/multi-core computing power in a rack-dense

package, the x3550 M2 is the ideal system.

Selling Features

Price/Performance

The x3550 M2 offers numerous features to boost performance and reduce costs:

• Up to two 4-core Xeon 5500 Series processors and 8MB or 4MB of shared cache per

processor, offer superior performance capable of tackling the toughest jobs. 64-bit

extensions provide the flexibility to run 32-bit and 64-bit applications concurrently. Xeon 5500

series processors offer up to 225% better performance than the previous-generation 5400

series processors and up to 900% better performance than the single-core processors of a

few years ago that you may still be using.

• Low-voltage processors draw less energy and produce less waste heat than high-voltage

processors, thus helping to reduce data center energy costs. Some 4-core Xeon 5500 Series

processors use only 60W. This is less than half the wattage consumed by older 130W

processors.

• Sixteen DIMMs of ultra-fast registered 1333MHz DDR3 ECC memory with Chipkill

error

protection (using p2-x8 DIMMS) provides speed, high availability, and a memory capacity of up

128GB.

• Optional 50GB solid-state drives (SSD) use only 2W of power per drive, vs. 9-10W for 2.5-

inch HDDs. This is as much as 80% less power than a 2.5-inch HDD would use (with a

corresponding reduction in heat output).

• The x3550 M2 is a leader in server resiliency. With hot-swap power supplies, fan modules,

and storage, the x3550 M2 has no single point of failure.

• The altimeter works in conjunction with IMM to govern fan rotation. which can help save

money at lower altitudes because the fans do not have to spin at high speed.

• Two high-speed PCIe x16 adapters (Gen 2) slots offer investment protection by supporting

high-performance adapters, such as 10Gb Ethernet, Fibre Channel and InfiniBand™ cards,

none of which will run in older 33MHz and 66MHz conventional PCI slots.

• Integrated ServeRAID-M5015 (on selected models) provides RAID-0/1/10/5/50 (optional 6/60

with Self-Encrypting Disk (SED)) without consuming a valuable adapter slot. It also offers

higher performance 512MB battery-backed cache.

• Up to six 2.5-inch hot-swap SAS hard disk drives offer high-performance with high

availability. The SAS controller provides full-duplex (bi-directional 300MBps) data transfers

for SAS drives.

• The integrated dual Gigabit Ethernet controllers with IPMI 2.0 provide high-speed network

communications. Jumbo Frames offer higher efficiency transfers for large data packets. Two

more NICS can be supported on the planar with an additional Dual Port Gb Ethernet

daughtercard.

• The TCP Offload Engine (TOE) feature offers higher performance for TCP/IP traffic, with less

overhead on the system processor.

• A high degree of device integration—including SAS/SATA or SSD, multiple ServeRAID

options, Gigabit Ethernet ports, systems management and video controllers—lowers costs

and frees up valuable adapter slots.

Flexibility

The x3550 M2 has the ability to grow with your application requirements, thanks to

• A choice of four-core or two-core processors with 1.86 to 2.93GHz clock rates, up to 6.4

gigatransfers per second, Turbo Boost and Hyper-threading technology, and 60W to 95W

maximum power draw.

• Up to 128GB of high-speed fully-buffered DDR3 system memory.

• Two available high-performance PCIe x16 adapter slots in all models. Optionally, if desired,

All models require Chipkill-enabled DIMMs (provided standard) for Chipkill protection.

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	eServer System x3550 M2
Bredde:	440 mm
Dybde:	711 mm
Højde:	43 mm
Vægt:	15600 g
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	4
Processorkerner:	4
Intern hukommelse:	6 GB
HDD kapacitet:	146 GB
Intel® Wireless Display (Intel® WiDi):	Ingen
Mac kompabilitet:	Ingen
Processorfrekvens:	2 GHz
Processorserie:	Intel® Xeon® 5000 Sequence
Processortråde:	4
Processor-cache:	4 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1333 MHz
Maksimal intern hukommelse:	128 GB
Samlet lagringskapacitet:	292 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ingen
Intel® Turbo Boost Teknologi:	Ingen
Kompatible operativsystemer:	Microsoft Windows Server 2003, \nRed Hat Enterprise Linux, SUSE Linux Enterprise Server, TurboLinux Enterprise Server, Novell NetWare, VMware ESX Server
Hukommelsesstik:	16x DIMM
Processorproducent:	Intel
Processormodel:	E5504
Antal VGA-porte (D-sub):	2
Optisk drevtype:	DVD Super Multi
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ja
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Netværk klar:	Ja
Grafikadapter:	G200eV
HDD-grænseflade:	Serial Attached SCSI (SAS)
Netværksfunktioner:	Gigabit Ethernet
Antal serielle porte:	1
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Stativ (1U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ingen
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	2.5 "
Strømforsyning:	675 W
Processor sokkel:	Socket B (LGA 1366)
Processor litografi:	45 nm
Stepping:	D0
Thermal Design Power (TDP):	80 W
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	4.8 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Nehalem EP
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ingen
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ingen
Fysisk adresseudvidelse (PAE):	Ja
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	42.5 x 45 mm
Processor kode:	SLBF9
Processor ARK ID:	40711
Hukommelseslayout (slots x størrelse):	3 x 2 GB
Antal installerede HDD'er:	2
CPU-multiplikator (bus/kerneforhold):	15
Intel® Smart Cache:	Ja
Maksimal lagerkapacitet:	1.8 TB
Fejlkorrigerende kode:	Ja
PCI Express x16 slots:	2
Redundant strømforsyning:	Ja
Maksimal grafikadapterhukommelse:	16 MB
Båndbredde:	19.2 Gbit/sek.
Hot-swap:	Ja
RAID-niveauer:	1
Billedtypekort:	<div><img src="https://ark.intel.com/inc/images/diagrams/diagram-17.gif" title="Block Diagram" /><img src="https://ark.intel.com/inc/images/diagrams/diagram-16.gif" title="Block Diagram" /><img src="https://ark.intel.com/inc/images/diagrams/diagram-19.gif" title="Block Diagram" /></div>
Maksimal intern hukommelse understøttet af processor:	144 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	19.2 GB/sek.
Tcase:	76 °C
Maksimalt antal SMP-processorer:	2
Fysisk adresse udvidelse (PAE):	40 Bit
Antal QPI-lins:	2
Processor systemtype:	DP
Hukommelseskanaler understøttet af processor:	Tredobbelt
Disk array controller:	M1015
