IBM Systems and Technology Group

Data Sheet

System x®

IBM System x3630 M3

A storage-rich dual-socket server at a value price

Highlights

●

Meet growing performance and storage

demands with a cost-effective, high-

capacity solution

●

Achieve high levels of system availabil-

ity, backed by IBM’s legendary support

●

Design the conﬁguration that meets

your needs today, with the freedom to

upgrade as needs change over time

Outstanding storage value

The IBM System x3630 M3 is a storage-rich dual-socket 2U server

that integrates the leadership features of traditional enterprise server

offerings with affordable components to deliver outstanding value to

cost-conscious buyers. Based on the latest Intel® Xeon® processor

technology, the x3630 M3 offers high performance and maximum stor-

age capacity. It provides up to 28 TB of internal storage capacity for a

much lower cost per terabyte than external storage, making it an ideal

solution for storage-intensive workloads.

Highly reliable performance

The x3630 M3 helps keep your business running smoothly with

availability features that include redundant cooling fan modules and

hot-swap/redundant power supplies, RAID protection, and predictive

failure analysis. The x3630 M3 also offers a comprehensive suite of sys-

tems management tools that help simplify management tasks.

Designed for affordable growth

With the ﬂexible design of the x3630 M3, you can choose the conﬁgu-

ration that meets your needs today, knowing you can easily upgrade to

more robust features as your needs change over time. With energy-

efficient components that help reduce operating costs, the x3630 M3 is

a cost-optimized offering that delivers value over the long term.

Select conﬁgurations of the x3630 M3 are part of the IBM Express

Advantage® Portfolio designed to meet the needs of midsized busi-

nesses. Easy to manage, Express® models and conﬁgurations vary by

country.

For more information

To learn more about the IBM System x3630 M3, contact your

IBM marketing representative or IBM Business Partner, or visit:

ibm.com/systems/x

IBM System x3630 M3 at a glance

Form factor/height

Processor (max)

Number of

processors (std/max)

Cache (max)

Memory (max)

Expansion slots

Disk bays (total/

hot-swap)

Maximum internal

storage

Network interface

Power supply

(std/max)

Hot-swap

components

RAID support

Systems

management

Operating systems

supported

Rack/2U

Up to 2.93 GHz 6-core (2.66 GHz 4-core) Intel Xeon

5600 series processors, or up to 2.26 GHz 4-core

Intel Xeon 5500 series processors, with up to

1333 MHz memory access speed

1/2

Up to 12 MB L3

Up to 96 GB DDR-3 RDIMM memory via

12 DIMM slots

3 PCIe slots

Up to 14 3.5" hot-swap SAS/SATA or

up to 28 2.5" hot-swap SAS/SATA

Up to 28 TB

Dual Gigabit Ethernet

1/2; 675 W each

Power supplies, hard disk drives

6 Gbps RAID -0, -1, -10 standard, upgradeable to

hardware RAID-5 or RAID-6 (model dependent)

IBM Systems Director, IBM Systems Director Active

Energy Manager™, IMM (Integrated Management

Module) with IPMI 2.0 support, UEFI (Uniﬁed

Extensible Firmware Interface), IBM ToolsCenter,

status LEDs

Microsoft® Windows Server, Red Hat Linux®, SUSE

Linux, VMware

Limited warranty 3-year customer replaceable unit and onsite limited

warranty

IBM Systems and Technology Group

Route 100

Somers, New York 10589

Produced in the United States of America

August 2010

IBM, the IBM logo, ibm.com, Active Energy Manager,

Express, Express Advantage, and System x are trademarks or

registered trademarks of International Business Machines

Corporation in the United States, other countries, or both. If

these and other IBM trademarked terms are marked on their

ﬁrst occurrence in this information with a trademark symbol

(® or ™), these symbols indicate U.S. registered or common

law trademarks owned by IBM at the time this information

was published. Such trademarks may also be registered or

common law trademarks in other countries. A current list of

IBM trademarks is available on the web at “Copyright and

trademark information” at

ibm.com/legal/copytrade.shtml

Intel and Intel Xeon are trademarks or registered trademarks

of Intel Corporation or its subsidiaries in the United States

and other countries.

Linux is a registered trademark of Linus Torvalds in the

United States, other countries, or both.

Microsoft and Microsoft Windows Server are trademarks or

registered trademarks of Microsoft Corporation in the

United States, other countries, or both

Other company, product or service names may be trademarks

or service marks of others.

XSD03087-USEN-00

Please Recycle

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	eServer System x3630 M3
Bredde:	482 mm
Dybde:	730.11 mm
Højde:	85 mm
Vægt:	22450 g
Formfaktor:	2U
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	4
Ethernet LAN:	Ja
Processorkerner:	6
Intern hukommelse:	12 GB
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	2.66 GHz
Processorserie:	Intel® Xeon® 5000 Sequence
Processor boost frekvens:	3.06 GHz
Processortråde:	12
Processor-cache:	12 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1333 MHz
Maksimal intern hukommelse:	96 GB
Samlet lagringskapacitet:	0 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	1.0
Hukommelsesstik:	12x DIMM
Processorproducent:	Intel
Processormodel:	X5650
Optisk drevtype:	Ingen
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Netværk klar:	Ja
Grafikadapter:	G200eV
Antal serielle porte:	1
Understøttede dataoverførselshastigheder:	1000Mbps, 100Mbps, 10MBps
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Stativ (2U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	- "
Strømforsyning:	675 W
Processor sokkel:	Socket B (LGA 1366)
Processor litografi:	32 nm
Stepping:	B1
Thermal Design Power (TDP):	95 W
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	6.4 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Westmere EP
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ingen
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	42.5 X 45 mm
Processor kode:	SLBV3
Processor ARK ID:	47922
CPU-multiplikator (bus/kerneforhold):	20
Understøttede instruktionssæt:	SSE4.2
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	24 TB
Hukommelsestype for grafikadapter:	GDDR2
Maksimal grafikadapterhukommelse:	16 MB
Maksimal intern hukommelse understøttet af processor:	288 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800,1066,1333 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	32 GB/sek.
Tcase:	81.3 °C
Maksimalt antal SMP-processorer:	2
Fysisk adresse udvidelse (PAE):	40 Bit
Antal QPI-lins:	2
Sikkerhedsfunktioner:	Power-on password\nPrivileged access password
Antal strømforsyninger:	1
Processor systemtype:	DP
Hukommelseskanaler understøttet af processor:	Tredobbelt
Disk array controller:	ServeRAID
Skærmkort opløsning:	1600 x 1200
Video adapter, bus:	PCIe
