An affordable single-socket, quad-core server with high performance

and data protection for small, medium, and large businesses

Please see the Legal Information section for important notices and information.

Product Guide

October 2010

IBM System x3200 M3

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options

x3200 M3 Images 1

x3200 M3 Specifications 1

The Bottom Line 1

Server Comparison Chart

For More Information 1

Legal Information 1

Value-priced performance, capacity and availability

Suggested uses: Small and medium businesses, distributed large enterprises, retail,

banking, and insurance companies seeking scalability, top performance, and enterprise-

class availability features at an entry-level price.

The single-socket IBM

System x3200 M3, incorporating IBM X-Architecture

features, is

an affordable, single-socket tower server that offers more performance, configuration

flexibility and availability features than many other servers in its class. From network

infrastructure to distributed applications to front-end workloads, the x3200 M3 is designed to

meet a wide range of business needs and help you adapt to changing business

requirements.

It supports, at the high end, the latest quad-core Intel

Xeon

3400 Series processors,

designed with speedy 1333MHz memory access (FSB) and 8MB of L3 cache, to help

provide the computing power you need to match your business needs and growth. For

power-constrained environments, a low-voltage, dual-core Xeon processor is also

available, with 4MB of cache. If cost is your primary concern, the x3200 M3 offers a model

using the affordable dual-core Celeron processor with 2MB of L3 cache. In between, there

are models that use the dual-core Pentium processor with 3MB of L3 cache, as well as a

dual-core Core i3 processor with 4MB of L3 cache. All models are designed with an

integrated memory controller for greatly improved memory performance (up to 1333MHz

access, depending on the processor), 64-bit extensions (EM64T), and multithreading, to

provide the computing power you need to match your business needs and growth. In

addition, the x3200 M3 uses industry-standard 1066/1333MHz DDR3 ECC (Error Checking

and Correcting) memory—for high performance and reliability.

All models offer impressive scalability, including up to 32GB

of memory and up to four 3.5-

inch hot-swap enterprise-class Serial ATA II (SATA II) hard disk drives with a total capacity

of up to 8TB

, or up to four 3.5-inch simple-swap enterprise-class SATA II hard disk drives

with a total capacity of up to 8TB, or eight 2.5-inch hot-swap SAS drives with an internal

storage capacity of up to 4.8TB.

For additional performance and high availability, the x3200 M3 offers integrated hardware

RAID-0/1 support standard in the hot-swap SAS/SATA models (optional for simple-swap

SATA models), and optional RAID-10/5/6. To meet your backup requirements, the x3200 M3

supports a choice of half-high tape drives, an optical drive, or an IBM RDX Removable

Hard Disk Storage System. The server ships as a tower unit; an optional rack conversion

kit turns the x3200 M3 hot-swap models into a 5U rack-mounted server to save precious

data center floor space.

Standard in the x3200 M3 is the Integrated Management Module (IMM) that enables the

user to manage and control the server easily—both locally and, using the optional Virtual

Media Key, remotely. The IMM offers a high level of manageability that is designed to keep

costs down and the system up—even when network usage increases. These advanced

features help maximize network availability by increasing uptime, as do hot-swap and

simple-swap SATA HDDs; hot-swap/redundant SAS HDDs, redundant ultra-efficient

power supplies; integrated RAID; redundant power

; IPMI 2.0 support, including highly

secure remote power control and Serial over LAN; as well as text-console redirect over

LAN.

Another improvement with the new generation of X-Architecture is the replacement of legacy

BIOS with next-generation United Extensible Firmware Interface (UEFI). UEFI provides a

more intuitive user interface and understandable event logs and better management.

With the inclusion of unique IBM service and support features such as the IMM, IBM

Using RDIMMS.

GB equals 1,000,000,000 bytes and TB equals 1,000,000,000,000 bytes when referring to hard disk drive capacity. Accessible

capacity may be less.

A second high-efficiency redundant 430W power supply is available for the x3200 M3. (Model dependant or via CTO.)

An affordable single-socket, quad-core server with high performance

and data protection for small, medium, and large businesses

Please see the Legal Information section for important notices and information.

Systems Director, IBM Systems Director Active Energy Manager

™

, and IBM

ServerGuide

™

, the x3200 M3 is designed for superior uptime.

For a balance of high-performance processing, high availability and vast internal storage at a

budget price, the x3200 M3 is the ideal system.

Selling Features

Price/Performance

The x3200 M3 offers numerous features to boost performance and reduce product and

operating costs:

• Models with a quad-core Xeon processor, high-end 1333MHz memory access, and 8MB

of L3 cache, offer peak performance, capable of tackling the toughest jobs.

• Models containing a high-performance dual-core Core i3 processor, with high-end

1333MHz memory access and 4MB of L3 cache, offer superior performance at an

aggressive price.

• Models containing a dual-core Celeron or Pentium processor with speedy 1066MHz

memory access, for those on a budget.

• Ultra-fast 1333MHz or 1066MHz DDR3 ECC memory offers high speed and high

availability.

• High-speed PCIe adapter slots offers investment protection by supporting high-

performance adapters, such as Ethernet, Fibre Channel and InfiniBand cards, none of

which will run in older legacy PCI slots.

• Integrated hardware RAID-0/1 support (standard in hot-swap models; optional in simple-

swap models) doesn’t consume a valuable adapter slot. RAID-0 offers improved disk

performance via data striping and RAID-1 offers disk mirroring for high availability.

• Gen 2 HDD cage support for up to four hot-swap 3.5-inch SAS or SATA hard disk

drives or up to eight hot-swap 2.5-inch SAS HDDs (CTO/special bid), offers high-

performance and large capacity with high availability. The SAS/SATA controller provides

full-duplex (2 x 300MBps) data transfers for SAS drives. For lower cost with high

capacity, other models support up to four simple-swap SATA drives.

• The two integrated single-port Gigabit Ethernet controllers with IPMI 2.0 support provide

high-speed network communications.

• A high degree of device integration, including SAS/SATA, RAID-0/1/1E, Gigabit

Ethernet, IMM systems management, and video controllers, lowers costs and frees up

valuable adapter slots.

Flexibility

The x3200 M3 has the ability to grow with your application requirements, thanks to:

• A choice of one quad-core Xeon processor with 2.4 to 3.06GHz clock rate, 8MB of L3

cache, and up to 1333MHz memory access, or a dual-core Celeron, Pentium or Core i3

processor with a 2.26 to 3.20GHz clock rate, 2MB to 4MB of L3 cache, and 1066MHz or

1333MHz memory access.

• A choice of 73W dual-core or 95W quad-core processors.

• Up to 32GB of high-speed DDR3 system memory.

• Five available adapter slots: two PCIe x8, two PCIe x4 (one PCIe slot is reserved for a

ServeRAID controller) and two legacy PCI (32-bit, 33MHz) slots in all models.

• The seven USB 2.0 ports (two front, four rear, one internal) are up to 40X faster

than

older USB 1.1 ports. This provides speedy access to external HDDs (non-arrayed),

optical drives, tape drives, and other USB devices. The internal port can be used for an

optional tape drive, disk cartridge backup device or USB key with embedded hypervisor.

• Up to four internal 3.5-inch simple-swap SATA or hot-swap SAS or SATA HDDs or

eight 2.5-inch hot-swap SAS HDDs (by special bid only), can be installed. This provides

tremendous internal storage capability, along with full data backup.

• Alternatively, iSCSI or Fibre Channel-attached storage can be attached using IBM

System Storage

servers.

Manageability

Powerful systems management features simplify local and remote management of the x3200

M3:

• The x3200 M3 includes an Integrated Management Module (IMM) to monitor server

availability, perform Predictive Failure Analysis, etc., and trigger IBM Systems Director

alerts. The IMM performs the functions of both the mini Baseboard Management

Data transfer rates may be less than the maximum possible.

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	eServer x3200 M3
Bredde:	- mm
Dybde:	- mm
Højde:	- mm
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	7
Ethernet LAN:	Ja
Processorkerner:	2
Intern hukommelse:	2 GB
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	3.2 GHz
Processorserie:	Intel® Core™ i3
Processortråde:	4
Processor-cache:	4 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1333 MHz
Maksimal intern hukommelse:	32 GB
Samlet lagringskapacitet:	250 GB
On-board grafikkort, model:	Intel® HD Graphics
On-board grafikkort:	Ja
Indbygget grafikadapterfamilie:	Intel® HD Graphics
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	Ingen
Kompatible operativsystemer:	Windows Server 2008 STD, EE, R2, Small BusinessServer 2008\nRed Hat Linux, SUSE Linux
Processorproducent:	Intel
Processormodel:	i3-550
Antal VGA-porte (D-sub):	1
Optisk drevtype:	DVD Super Multi
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	1
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ingen
Intel® Virtualization Technology (VT-x):	Ja
HDD-grænseflade:	Serial ATA, Serial Attached SCSI (SAS)
Netværksfunktioner:	Gigabit Ethernet
Antal serielle porte:	1
Antal installerede processorer:	1
Bus type:	DMI
Processorgeneration:	Intel® Core™ i3
Kabinettype:	Tower
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ingen
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	3.5 "
Strømforsyning:	400 W
Processor sokkel:	LGA 1156 (Socket H)
Processor litografi:	32 nm
Stepping:	K0
Thermal Design Power (TDP):	73 W
Maksimalt antal PCI Express-kanaler:	16
PCI Express slots version:	2.0
PCI Express-konfigurationer:	1x16, 2x8
Fejlkorrigerende kode understøttet af processor:	Ingen
Processor front side bus:	- MHz
Systembus-hastighed:	2.5 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Clarkdale
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ja
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ingen
Intel® Demand Based Switching:	Ingen
Termiske overvågningsteknologier:	Ingen
Fysisk adresseudvidelse (PAE):	Ja
Intel® Dual Display Capable Teknologi:	Ja
Intel® FDI Teknologi:	Ja
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	37.5 x 37.5 mm
Processor kode:	SLBUD
Grafisk og IMC litografi:	45 nm
Processor ARK ID:	48505
Antal installerede HDD'er:	1
Indbygget grafikadapter basefrekvens:	733 MHz
CPU-multiplikator (bus/kerneforhold):	24
Understøttede instruktionssæt:	SSE4.2
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	8 TB
Fejlkorrigerende kode:	Ja
PCI Ekspres x8 slots:	2
Redundant strømforsyning:	Ja
Hot-swap:	Ja
RAID-niveauer:	0, 1
Antal behandling Die transistorer:	382 M
Behandling Die størrelse:	81 mm²
PCI-slots:	2
Maksimal intern hukommelse understøttet af processor:	16 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	1066,1333 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	21 GB/sek.
Tcase:	72.6 °C
Antal understøttede skærme (indbygget grafik):	2
PCI Ekspres x4 slots:	2
Fysisk adresse udvidelse (PAE):	36 Bit
Antal strømforsyninger:	1
Hukommelseskanaler understøttet af processor:	Dobbelt
