Side 1/21

Leadership enterprise server with significantly lower cost of ownership in a highly available and

expandable, rack-dense, 1U dual-socket server

Please see the Legal Information section for important notices and information.

Product Guide

February 2011

IBM System x3550 M3

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options 1

x3550 M3 Images 1

x3550 M3 Specifications 1

The Bottom Line 1

Server Comparison

For More Information 2

Legal Information 2

Outstanding innovation in only 1U

Suggested Uses: All sectors requiring highly available, energy-efficient, rack-optimized solution

for physical and virtual intensive commercial environments like eBusiness/eCommerce,

collaboration, virtualization, database, and enterprise resource planning applications.

Your challenge is to do more with less—serve more Web pages, handle more secure

connections, support more e-mail users. You need to reduce the costs of doing business and

improve the service you deliver to your customers while lowering your overall risk. The dual-

socket IBM

System x3550 M3 can reduce your costs with its new energy smart design. It can

improve service with reduced operational complexity and increased management functionality. It

will lower your IT risk with the resiliency that comes from no single point of failure. And like all

IBM servers, the x3550 M3 offers you the trust that comes from the IBM global reach, service and

support.

The x3550 M3 is a game-changing rack server that uses significantly less power than previous

generations, with unified systems management tools, leadership reliability, availability, and

serviceability features and broad systems flexibility, housed in a compact 1U mechanical

package.

The x3550 M3 features Intel

Xeon

5600 series 6-core and 4-core processors, with up to

12MB of shared L3 cache, to provide you with the computing power you need to match your

business needs and growth. The new line of Intel processors delivers unprecedented intelligent

performance with features like adaptive performance for applications and environments, Turbo

Boost Technology and Hyper-Threading Technology, and integrated power gates and automated

power management.

The x3550 M3 supports up to 18 DIMMs / 192GB of registered (RDIMM) 1333MHz DDR3

memory (or up to 12 DIMMs / 48GB of unbuffered UDIMM memory) and provides Chipkill

™

ECC

(Error Checking and Correcting) protection—for high performance and reliability. For even higher

levels of availability, the x3550 M3 also offers memory mirroring. Up to 4 integrated high-speed

Gigabit Ethernet ports are available (offering TOE (TCP Offload Engine) support on Microsoft

Windows

), as are two high-performance adapter slots (PCIe x16). The x3650 M3 offers an

optional embedded hypervisor to manage your virtual workloads.

The x3550 M3 offers a choice of up to supports up to 8 high-performance hot-swap HDDs with an

internal storage capacity of 8TB

(2.5-inch hot-swap Serial-Attached SCSI (SAS) or Serial-

Attached ATA (SATA) drives). Alternatively, up to 8 solid-state drives (SSDs) are also

available to keep power low, improve resiliency, and offer up to 400GB of storage. The server

includes a choice of several IBM ServeRAID

storage controllers that provide broad levels of

hardware-based RAID solutions. The ultradense 1U form factor allows businesses to increase

their computing power and spread their workload without outgrowing their current data center. Up

to 42 of these 1U servers can be installed in a single 42U rack, for a total of up to 84 processors

and 504 processor cores, offering tremendous deployment flexibility.

Standard in the x3550 M3 is the Integrated Management Module (IMM) that enables the user to

manage and control the server easily—both locally and remotely. In conjunction with the IMM, the

x3550 M3 comes with an altitude sensor (altimeter) that governs fan rotation based on

altitude, to help lower your energy consumption. The IMM offers a high level of manageability that

is designed to keep costs down and the system up—even when network usage increases. IBM’s

innovative pop-out/drop-down light path diagnostics panel enables quick servicing of the

system if a problem develops. These advanced features help maximize network availability by

increasing uptime, as do hot simple-swap solid-state drives; hot-swap/redundant SAS or

SATA HDDs, redundant ultra-efficient power supplies and fan modules; Active Memory

™

;

integrated RAID; temperature-controlled fans with Calibrated Vectored Cooling

™

; IPMI 2.0

support, including highly secure remote power control and Serial over LAN; as well as text-

console redirect over LAN.

1TB drives available in 2Q/2011.

Leadership enterprise server with significantly lower cost of ownership in a highly available and

expandable, rack-dense, 1U dual-socket server

Please see the Legal Information section for important notices and information.

Another improvement with the new generation of X-Architecture is the replacement of legacy

BIOS with a new generation United Extensible Firmware Interface (UEFI). UEFI provides a

more intuitive user interface and understandable event logs and better management.

With the inclusion of unique IBM service and support features such as the IMM, light path

diagnostics, IBM Systems Director, IBM Systems Director Active Energy Manager

™

, IBM

ServerGuide

™

and

support for the optional Virtual Media Key for remote presence capability, the

x3550 M3 is designed for superior uptime.

The x3550 M3 passed the NEBS 1/ETSI equivalent compliance for both AC and DC power

supplies and compliance with 80 PLUS

and ENERGY STAR

standards (model dependent),

demonstrating exceptional energy efficiency. For more information about IBM’s ENERGY STAR

compliance, visit http://ibm.com/systems/greendc/green_technology/energy_star/index.html.

If you need highly manageable, dual-socket/multi-core computing power in a rack-dense, energy-

efficient package, the x3550 M3 is the ideal system.

Selling Features

Price/Performance

The x3550 M3 offers numerous features to boost performance and reduce costs:

• Up to two 6-core or 4-core Xeon 5600 series processors and up to 12MB of cache per

processor, offer superior performance capable of tackling the toughest jobs. Xeon 5600 series

processors offer up to 54% better performance than the previous-generation 5500 series

processors (depending on workload).

• Low-voltage processors draw less energy and produce less waste heat than high-voltage

processors, thus helping to reduce data center energy costs. Selected 4-core Xeon 5600

series processors (available via CTO) use only 40W, and selected 6-core processors

consume only 60W. This is less than half the wattage consumed by 130W processors.

• Eighteen DIMMs of ultra-fast registered 1333MHz DDR3 ECC memory with Chipkill

protection (optional) provide speed, high availability, and a memory capacity of up 192GB.

• x3550 M3 servers using the L5640, E5645, E5649 and 1333MHz X56xx processors support 2

DIMMs per channel (2DPC) at 1333MHz (running at 1.5V).

• Optional 50GB solid-state drives (SSD) use only 2W of power per drive, vs. 9-10W for 2.5-

inch HDDs. This is as much as 80% less power than a 2.5-inch HDD would use (with a

corresponding reduction in heat output).

• The altimeter works in conjunction with IMM to govern fan rotation. which can help save

money at lower altitudes because the fans do not have to spin at high speed.

• Two high-speed PCIe x16 adapters (Gen 2) slots offer investment protection by supporting

high-performance adapters, such as 10Gb Ethernet, Fibre Channel and InfiniBand™ cards,

none of which will run in older 33MHz and 66MHz conventional PCI slots.

• The integrated ServeRAID-BR10il v2 controller (model-specific) provides RAID-0/1/1E and

full-duplex (bidirectional 3Gbps) data transfers for SAS/SATA/SSD drives without consuming

a valuable adapter slot. Other server models include the 6Gbps ServeRAID-M1015 (RAID-

0/1/10, optional 5/50 with Self-Encrypting Disk, or SED), the 6Gbps ServeRAID-M5014

controller, which provides RAID-0/1/10/5/50 with 256MB cache and optionally 6/60 with SED

and optional battery backup, or the 6Gbps ServeRAID-M5015 controller, which provides

RAID-0/1/10/5/50 with 512MB of battery-backed cache (except CTO models) and optionally

6/60 with SED.

• Up to 8 2.5-inch hot-swap SAS/SATA hard disk drives offer high-performance with high

availability. SSDs offer even higher availability, with extremely high IOPS rates.

• The integrated dual-port Gigabit Ethernet controller with IPMI 2.0 provide high-speed

network communications. Two more NICs can be added to the planar with an additional dual-

port Gb Ethernet daughtercard. The TCP Offload Engine (TOE) feature offers higher

performance for TCP/IP traffic, with less overhead on the system processor.

• A high degree of device integration—including SAS/SATA HDDs or SSDs, multiple

ServeRAID options, Gigabit Ethernet ports, systems management and video controllers—

lowers costs and frees up valuable adapter slots.

• Energy-efficient components, including DDR3 memory, low-voltage transistors and voltage

regulator modules, and power supplies that are up to 90% efficient (model-specific), help keep

your energy bills down.

All models require Chipkill-enabled DIMMs (provided standard) for Chipkill protection.

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	eServer x3550 M3
Bredde:	440 mm
Dybde:	711 mm
Højde:	43 mm
Vægt:	15600 g
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	4
Ethernet LAN:	Ja
Processorkerner:	4
Driftstemperatur (T-T):	10 - 32 °C
Intern hukommelse:	4 GB
Strømforsyningstype:	Vekselstrøm/jævnstrøm
Operativsystem installeret:	Ingen
Intel® Wireless Display (Intel® WiDi):	Ingen
Mac kompabilitet:	Ingen
Bæredygtighedscertifikater:	ENERGY STAR
Processorfrekvens:	1.6 GHz
Processorserie:	Intel® Xeon® 5000 Sequence
Processortråde:	4
Processor-cache:	4 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1066 MHz
Maksimal intern hukommelse:	192 GB
Samlet lagringskapacitet:	0 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ingen
Intel® Turbo Boost Teknologi:	Ingen
Driftshøjde:	914.4 - 2133 m
Kompatible operativsystemer:	Windows Server 2008, 2008 R2 (32/64-bit)\nMicrosoft Windows Server 2003, 2003 R2 (32/64-bit)\nRHEL 5 (32/64-bit)\nRHEL 6 (32/64-bit)\nSLES 10/11 (32/64-bit)\nVMware vSphere Hypervisor 4.1\nSun Solaris 10
Hukommelsesstik:	18x DIMM
Processorproducent:	Intel
Processormodel:	E5603
Antal VGA-porte (D-sub):	1
Optisk drevtype:	Ingen
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Grafikadapter:	G200eV
HDD-grænseflade:	Serial ATA, Serial Attached SCSI (SAS)
Overholdelse af branchestandarder:	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Netværksfunktioner:	Gigabit Ethernet
Antal serielle porte:	1
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Stativ (1U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	2.5 "
Strømforsyning:	460 W
Processor sokkel:	Socket B (LGA 1366)
Processor litografi:	32 nm
Stepping:	B1
Thermal Design Power (TDP):	80 W
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	4.8 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Westmere EP
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ingen
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	42.5 X 45 mm
Processor kode:	SLC2F
Processor ARK ID:	52584
Hukommelseslayout (slots x størrelse):	1 x 4 GB
CPU-multiplikator (bus/kerneforhold):	12
Understøttede instruktionssæt:	SSE4.2
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	4 TB
Fejlkorrigerende kode:	Ja
PCI Express x16 slots:	2
Redundant strømforsyning:	Ingen
Antal understøttede HHD'er:	4
Hukommelsestype for grafikadapter:	GDDR2
Kompatibel processor serie:	Intel® Xeon®
Bundkort chipsæt:	Intel® 5520
LAN Kontroller:	Broadcom BCM5709S
Maksimal grafikadapterhukommelse:	16 MB
Wake-on-LAN klar:	Ja
Hot-swap:	Ja
RAID-niveauer:	10
Maksimal intern hukommelse understøttet af processor:	288 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800,1066 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	25.6 GB/sek.
Maksimalt antal SMP-processorer:	2
Grafikadapter familie:	Matrox
Fysisk adresse udvidelse (PAE):	40 Bit
Antal QPI-lins:	2
Antal strømforsyninger:	1
Hukommelseskanaler understøttet af processor:	Tredobbelt
Disk array controller:	LSI 1068
