IBM Europe, Middle East, and Africa Hardware Announcement

ZG12-0218, dated July 31, 2012

IBM Europe, Middle East, and Africa Hardware

Announcement ZG12-0218

IBM is a registered trademark of International Business Machines Corporation 1

IBM System x3300 M4 tower servers feature fast 4C

or 6C Intel Xeon processors with one QPI link and 10

MB or 15 MB cache for enhanced performance and

scalability

Table of contents

2 11Overview Publications

3Key prerequisites Technical information 13

3Planned availability date Terms and conditions 22

4 26Description Prices

10 26Product positioning Announcement countries

10 Product number

At a glance

IBM® System x3300 M4 servers feature:

•A 1.8 GHz/6.4 GTS-10 MB 4C IntelTM E5-2403, a 2.2 GHz/6.4 GTS-10 MB 4C

E5-2407, a 1.9 GHz/7.2 GTS-15 MB 6C E5-2420, a 2.2 GHz/7.2 GTS-15 MB 6C

E5-2430, or a 2.4 GHz/7.2 GTS-15 MB 6C E5-2440, Intel XeonTM processor data

bus to the system with one QPI link.

•2 GB or 4 GB of 1333 MHz DDR3 ECC system memory1; 48 GB maximum or 384

GB maximum when 32 GB DIMMs installed; Express® models have 8 GB.

• Eight-port SAS/SATA with RAID controller.

• One fixed 460-watt 80 Plus Bronze certified power supply fitted standard; one

hot-swap 550-watt 80 Plus Platinum certified redundant power supply on Models

D2, D4,and F2.

• Integrated management module (IMM2).

• Five PCI-Express card slots standard, one PCI-Express card slot enabled with

dual processors, and one optional PCI-X card slot when using interposer card.

• Support for up to sixteen 2.5-inch drives plus one standard optical drive and one

optional half-height tape drive, or up to eight 3.5-inch drives plus one standard

optical drive and one optional half-height tape drive.

•Up to 16 TB2

with 1 TB 2.5-inch HS NL SFF SAS/SATA disk drives.

IBM Europe, Middle East, and Africa Hardware

Announcement ZG12-0218

IBM is a registered trademark of International Business Machines Corporation 2

• Intel I350CM2 integrated Quad Gigabit Ethernet controllers, two ports standard

and two more ports using Software license key and SAS or SATA support.

• SVGA video with 16 MB memory shared.

• Support for optional Remote Presence function.

• 4U tower industry-standard models, rack mount through special bid or option.

• Two USB front and four USB rear ports, two USB internal port, one d-sub

connector, four 10/100/1000 RJ45 ports, and one serial port.

Overview

The System x3300 M4 servers include:

• Quickpath Interconnect (QPI) support for 6.4 and 7.2 Gigabit transfers per

second (GTS), supporting one QPI link.

• Two simple-swap fans standard with single processor or three simple-swap fans

standard with dual processors. Optional redundant cooling option and power

supplies are available.

• Five PCI-Express card slots standard; one PCI-Express card slot enabled with

dual processors; and one optional PCI-X card slot when using interposer card.

• Integrated dual Gigabit Ethernet, quad with software upgrade.

• RAID-0, RAID-1, and RAID-10 support standard or optional RAID-1E, RAID-5,

RAID-10, and RAID-50 using a PCI-E adapter.

• DDR3 ECC DIMMs, combined with an integrated ECC memory controller in core

logic that corrects many soft and hard single-bit memory errors and minimizes

disruption of service to LAN clients.

• Integrated management module (IMM2) with optional Remote Presence function.

• Light path diagnostics with a light path panel visible at front of chassis.

Powered and scaled for business growth

• These servers contain one of the following:

– A 1.8 GHz/6.4 GTS-10 MB 4C Intel E5-2403, a 2.2 GHz/6.4 GTS-10 MB 4C

E5-2407, a 1.9 GHz/7.2 GTS-15 MB 6C E5-2420, a 2.2 GHz/7.2 GTS-15 MB 6C

E5-2430, or a 2.4 GHz/7.2 GTS-15 MB 6C E5-2440, Intel Xeon processor data

bus to the system with one QPI link.

• Either a 1066 MHz or 1333 MHz functional speed processor operations to

memory.

•2 GB or 4 GB of high-speed DDR3 - 1333 MHz ECC memory1, 48 GB maximum

using 4 GB memory DIMMs6, or 384 GB maximum using 32 GB memory DIMMs7,

Express models come standard with 8 GB.

• High-speed, wide-bandwidth slots: Five PCI-Express card slots with single

processor, one more PCI-Express card slot with dual processors, and one optional

PCI-X card slot when using interposer card.

• Intel I350CM2 integrated Quad Gigabit Ethernet controllers, two ports standard

and two more ports using Software license key and SAS or SATA support.

• Standard SATA DVD-ROM and tape drive bay.

• Eight standard 2.5-inch hot-swap drive bays and up to sixteen 2.5-inch bays

available when using upgrade options with total HDD storage capacity of 16 TB,

when using 1 TB Near-Line SFF SAS/SATA HDD options.

High availability for around-the-clock business demands

• Integrated management module (IMM2) and support for the optional Remote

Presence function.

• Wake on LAN.

• ECC memory to detect double-bit errors and correct single-bit errors.

• Integrated memory mirroring and sparing.
