A cost-optimized storage-rich alternative to traditional enterprise 2U dual-socket servers

Please see the Legal Information section for important notices and information.

Product Guide

February 2011

IBM System x3620 M3

Product Overview

CONTENTS

Product Overview

Selling Features

Key Features

Key Options 1

x3620 M3 Images 1

x3620 M3 Specifications 1

The Bottom Line 1

Server Comparison

For More Information

Legal Information

Cost-effective 2U storage server packed with innovation

Suggested Uses: Departmental and file/print servers, online gaming, messaging, video/photo

sharing, email, transaction processing, blog hosting, and search engines; for large enterprise, mid-

market, SMBs, and emerging markets.

In today’s tough economic environment, your challenge is to do more with less—serve more Web

pages, handle more secure connections, support more e-mail users, and do it all on a tight budget.

You need to reduce the costs of doing business and improve the service you deliver to your

customers while lowering your overall risk. The dual-socket IBM

System x3620 M3 can reduce

your costs with its new energy-smart design and budget-conscious features. It can improve service

with reduced operational complexity and increased management functionality. It can lower your IT

risk with the resiliency that comes from hot-swap/redundant features. And like all IBM servers, the

x3620 M3 offers you the trust that comes from the IBM global reach, service and support.

The x3620 M3 is a game-changing rack server that uses significantly less power than previous

generations, with unified systems management tools; high reliability, availability, and serviceability

features; and broad system flexibility, housed in a compact 2U mechanical package.

The x3620 M3 features Intel

Xeon

5600 series 6-core and 4-core, and 5500 series 4-core

processors, with up to 12MB of shared L3 cache, to provide you with the computing power you need

to match your business needs and growth. The new line of Intel processors delivers unprecedented

intelligent performance with features like adaptive performance for applications and environments,

Turbo Boost Technology and Hyper-Threading Technology, and integrated power gates and

automated power management.

The x3620 M3 supports up to 12 DIMMs / 192GB of RDIMM 1333MHz DDR3 memory and provides

Chipkill

™

ECC (Error Checking and Correcting) protection—for high performance and reliability. For

even higher levels of availability, the x3620 M3 also offers memory mirroring. Two integrated high-

speed Gigabit Ethernet ports are included, as are three high-performance PCIe adapter slots. The

x3620 M3 offers an optional embedded hypervisor to manage your virtual workloads.

Some System x3620 M3 models support up to 8 hot-swap 3.5-inch Serial-Attached SCSI (SAS) or

Serial-Attached ATA (SATA) HDDs with an internal storage capacity of 16TB. Other models

support up to 4 simple-swap SATA drives, with a storage capacity of up to 8TB. The server

includes firmware RAID-0/1 standard, and offers a choice of several IBM ServeRAID

storage

controllers that provide broad levels of hardware-based RAID solutions. To meet your backup

needs, the x3620 M3 supports a choice of internal tape drives, as well as the internal RDX

Removable Disk Backup System.

The ultra-dense 2U form factor allows businesses to increase their computing power and spread

their workload without outgrowing their current data center. Up to 21 of these 2U servers can be

installed in a single 42U rack, for a total of up to 42 processors, 252 processor cores (and 504

threads), offering tremendous deployment flexibility.

Standard in the x3620 M3 is the Integrated Management Module (IMM) that enables the user to

manage and control the server easily—both locally and remotely. The IMM offers a high level of

manageability that is designed to keep costs down and the system up—even when network usage

increases. The IMM helps maximize network availability by increasing uptime, as do Active

Memory

™

protection, hot-swap/redundant SAS or SATA HDDs, hot-swap/redundant ultra-efficient

power supplies and redundant fan modules; integrated RAID; temperature-controlled fans; IPMI

2.0 support, including highly secure remote power control and Serial over LAN; as well as text-

console redirect over LAN.

Another improvement with the new generation of X-Architecture is the replacement of old BIOS with

a new generation United Extensible Firmware Interface (UEFI). UEFI provides a more intuitive

user interface and understandable event logs and better management.

With the inclusion of unique IBM service and support features such as the IMM, IBM Systems

Director 6.1, IBM Systems Director Active Energy Manager

™

, IBM ToolsCenter, IBM

ServerGuide

™

, and

support for the optional Virtual Media Key for remote presence capability, the

A cost-optimized storage-rich alternative to traditional enterprise 2U dual-socket servers

Please see the Legal Information section for important notices and information.

x3620 M3 is designed for superior uptime.

If you need highly manageable, dual-socket/multi-core computing power in a budget rack-dense

package, the x3620 M3 is the ideal system.

Selling Features

Price/Performance

The x3620 M3 offers numerous features to boost performance and reduce costs:

• Up to two 2.26 to 3.06GHz 6-core or 1.6GHz to 3.2GHz 4-core Xeon 5600 series processors; or

two 2.13GHz to 2.26GHz 4-core or 2.0GHz 2-core Xeon 5500 series processors, standard or via

CTO. withd 12MB, 8MB, or 4MB of cache per processor, offer superior performance capable of

tackling the toughest jobs. Xeon 5600 series processors offer up to 54% better performance than

the previous-generation 5500 series processors (depending on workload).

• Low-voltage processors (available via the Configure To Order process) draw less energy and

produce less waste heat than high-voltage processors, thus helping to reduce data center energy

costs. Selected 4-core Xeon 5600 series processors use only 40W and selected 6-core

processors consume only 60W. This is less than half the wattage consumed by 130W processors.

• Twelve DIMMs of registered 1333MHz DDR3 ECC memory with Chipkill

protection (optional)

provide speed, high availability, and a memory capacity of up 192GB.

• x3620 M3 servers using the 1333MHz 5600 series processors support 2 DIMMs per channel

(2DPC) at 1333MHz (using 1.5V DIMMs or 1.35V-capable DIMMs running at 1.5V).

• Two p2-x8 (“by 8”) PCIe Gen 2 and one x4 PCIe Gen 2 adapter slot offer investment protection by

supporting high-performance adapters, such as 10Gb Ethernet, Fibre Channel and InfiniBand

™

cards, none of which will run in older legacy PCI slots.

• The optional integrated 3Gbps ServeRAID-BR10il v2 controller, or the 6Gbps ServeRAID-

M1015, ServeRAID-M5014, or ServeRAID-M5015 controller, provide high-performance RAID

support for SAS/SATA drives.

• Up to 8 3.5-inch hot-swap SAS/SATA hard disk drives offer high-performance and high capacity,

with high availability. Up to 4 3.5-inch simple-swap SATA drives offer high capacity and quick

servicing

• The integrated dual-port Gigabit Ethernet controller with IPMI 2.0 provide high-speed network

communications.

• A high degree of device integration—including hot swap SAS/SATA HDDs, multiple hardware-

based ServeRAID options, Gigabit Ethernet ports, systems management and video controllers—

lowers costs and frees up valuable adapter slots.

Flexibility

The x3620 M3 has the ability to grow with your application requirements, thanks to

• A choice of 4-core or 6-core processors with 1.6 to 3.2GHz clock rates, up to 6.4 gigatransfers

per second, and 40W to 95W maximum power draw.

• A choice of either 1.5V DIMMs, or 1.35V DIMMs that consume 20% less energy.

• Up to 192GB of high-speed registered DDR3 system memory.

• Three available high-performance PCIe adapter slots in all models.

• Upgrading to one of several ServeRAID controllers provides up to 512MB of battery-backed

cache to enable higher-performance hardware RAID support, and allows the x3620 M3 to offer

five RAID levels standard: RAID-0/1/10/5/50 (and optionally 6/60 with Self-Encrypting Disk).

• The five USB 2.0 ports (two front, two rear, one internal) are up to 40X faster

than older USB 1.1

ports. This provides speedy access to external HDDs (non-arrayed), optical drives, tape drives,

and other USB devices. Two ports are on the front of the unit and two are on the back. The

internal port supports an internal tape or IBM RDX Removable Disk Backup System, and a flash

drive with embedded hypervisor can be support via another internal USB port.

• A choice of up to eight 3.5-inch hot-swap SAS/SATA HDDs or four 3.5-inch simple-swap

SATA drives and one internal tape drive or RDX Removable Disk Backup System, offer a variety

of storage options. The SATA models provide a maximum of 16.0TB of internal storage, while the

SAS models support up to 4.8TB.

• Alternatively, direct-attach, network-attached storage (NAS), or iSCSI or Fibre Channel-attached

storage can be attached using IBM System Storage

servers.

All models require Chipkill-enabled DIMMs (provided standard) for Chipkill protection.

Data transfer rates may be less than the maximum possible.

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	System x x3620 M3
Bredde:	487.6 mm
Dybde:	749.3 mm
Højde:	86.3 mm
Vægt:	22450 g
Wi-Fi:	Ingen
Ethernet LAN-porte (RJ-45):	2
Antal USB 2.0-porte:	4
Ethernet LAN:	Ja
Processorkerner:	6
Driftstemperatur (T-T):	10 - 32 °C
Intern hukommelse:	12 GB
Dimensioner (BxDxH):	487.6 x 749.3 x 86.3 mm
Kabelteknologi:	10/100/1000Base-T(X)
Understøttede netværksprotokoller:	TCP/IP, IPv4/IPv6, UDP
Intel® Wireless Display (Intel® WiDi):	Ingen
Mac kompabilitet:	Ingen
Processorfrekvens:	2.66 GHz
Processorserie:	Intel® Xeon® 5000 Sequence
Processor boost frekvens:	3.06 GHz
Processortråde:	12
Processor-cache:	12 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1333 MHz
Maksimal intern hukommelse:	196608 MB
Samlet lagringskapacitet:	0 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	1.0
Driftshøjde:	0 - 2133 m
Kompatible operativsystemer:	Windows Server 2008\nWindows Server 2008 R2\nWindows Server 2003 R2\nWindows SBS 2003 R2\nRHEL 5 U4\nSLES 11\nSLES 10 SP3\nVMware ESX Server 4.0\nESXi 4.0, 4.0 U1
Hukommelsesstik:	12x DIMM
Processorproducent:	Intel
Processormodel:	X5650
Antal VGA-porte (D-sub):	1
Optisk drevtype:	Ingen
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
Idle status:	Ja
CPU-konfiguration (maks.):	2
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Netværk klar:	Ja
Grafikadapter:	G200eV
HDD-grænseflade:	Serial ATA II, Serial Attached SCSI (SAS)
Overholdelse af branchestandarder:	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Netværksfunktioner:	Gigabit Ethernet
Antal serielle porte:	1
Antal installerede processorer:	1
Bus type:	QPI
Kabinettype:	Stativ (2U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ja
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	3.5 "
Strømforsyning:	675 W
Processor sokkel:	Socket B (LGA 1366)
Processor litografi:	32 nm
Stepping:	B1
Thermal Design Power (TDP):	95 W
PCI Express slots version:	2.0
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	6.4 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Westmere EP
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ja
Termiske overvågningsteknologier:	Ingen
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	42.5 X 45 mm
Processor kode:	SLBV3
Processor ARK ID:	47922
Hukommelseslayout (slots x størrelse):	3 x 4 GB
CPU-multiplikator (bus/kerneforhold):	20
Understøttede instruktionssæt:	SSE4.2
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	16 TB
Fejlkorrigerende kode:	Ja
PCI Ekspres x8 slots:	1
PCI Express x16 slots:	2
Redundant strømforsyning:	Ja
Antal understøttede HHD'er:	8
Hukommelsestype for grafikadapter:	GDDR3
Kompatibel processor serie:	Intel® Xeon®
Bundkort chipsæt:	Intel® 5520
LAN Kontroller:	Broadcom BCM5709S
Maksimal grafikadapterhukommelse:	16 MB
Wake-on-LAN klar:	Ja
Hot-swap:	Ja
RAID-niveauer:	0, 1,5, 10, 50
Udluftningsventilator (er):	4
Maksimal intern hukommelse understøttet af processor:	288 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800,1066,1333 MHz
Hukommelsesbåndbredde understøttet af processor (maks.):	32 GB/sek.
Tcase:	81.3 °C
Maksimalt antal SMP-processorer:	2
Grafikadapter familie:	Matrox
Fysisk adresse udvidelse (PAE):	40 Bit
Antal QPI-lins:	2
Antal strømforsyninger:	2
Processor systemtype:	DP
Hukommelseskanaler understøttet af processor:	Tredobbelt
Disk array controller:	M5015
