Side 1/23

Ultrascalability combined with extreme availability

features and industry-leading performance

Please see the Legal Information section for important notices and information.

Product Guide

April 2011

IBM System x3850 X5 / x3950 X5

Architecture Overview

CONTENTS

Architecture Overview 1

Key Highlights 2

Key Features 3

Key Options 14

x3850/x3950 X5 Images

x3850/x3950 X5 Specs 17

The Bottom Line 21

Server Comparison 22

For More Information 23

Legal Information 23

Outstanding performance, superior mainframe-like reliability, and

fault-tolerant memory characteristics

IBM

has been designing and implementing servers under the X-Architecture

name since

2001. eX5 technology represents the fifth generation of enterprise servers based on the same

design principle IBM began with in 1997: to offer systems that are expandable, offer “big iron”

reliability, availability, and serviceability (RAS) features, with extremely competitive

price/performance on an Intel

Xeon

processor-based system.

The eX5 technology is primarily designed around three major workloads: database servers,

server consolidation using virtualization services, and Enterprise Resource Planning

(application and database) servers.

If you’re using industry-standard Xeon processor-based servers for running business critical

applications, the systems that run these applications need the type of technology designed

into IBM’s eX5 technology systems. eX5 technology represents a $100M+ investment in

designing a flagship offering that can harness the power of 4-socket-and-up 64-bit x86 (x64)

Xeon processors. The eX5 family includes two 4U 4-socket rack-optimized chassis (x3850

X5 and x3950 X5), which are offered in different scaled configurations up to 8 sockets, with

the architectural capability to scale further. In addition, for those workloads that require the

maximum available memory, the x3850 X5 and x3950 X5 support a 1U MAX5 memory

expansion unit, which adds an additional 32 DIMM slots per chassis (up to 96 DIMMs / 3TB

total). Alternatively, if you also need more processor sockets, you can add a second x3850

X5 or x3950 X5 to form one 8U 8-socket server with double the memory (up to 4TB),

HDDs/SSDs, adapter slots, and all the other system resources. For the ultimate in scalability,

you can add two MAX5 memory expansion units to a 2-node/8-socket server, for up to 6TB of

memory, ideal for large virtualization, ERP, and database needs.

IBM FlexNode partitioning allows you to logically divide an 8-socket server into two 4-

socket servers remotely and automatedly, and then revert back to a single 8-socket server,

all without requiring a physical visit to the server. Maybe you’d like to start out with a 4-socket

server and possibly add sockets later, if your needs change. Or perhaps you need more than

a 4-socket server now, but don’t want to get locked into a monolithic 8-socket or larger

server—again, in case your requirements change. With IBM, you can stop at 4 sockets, or

expand memory or CPU sockets further if needed. And if you require a variety of 4- and 8-

socket servers in your data center, you can qualify a single server for all these workloads.

This can save much time and effort and speed up deployment. You can also save money on

software licensing by virtualizing a 4- or 8-processor server into many VMs, rather than using

multiple 2-processor servers. Huge amounts of memory also enable more and larger VMs,

and larger databases.

IBM X-Architecture pioneered XpandOnDemand

™

(“pay as you grow”) scalability, which

allows chassis to be simply cabled together to form larger scale-up systems. This capability

allows IBM to sell a large SMP (symmetric multiprocessing) system at entry price points. With

XpandOnDemand, you can start small and later expand as your needs change, without

requiring you to buy more than you need up-front or throw away parts later as you expand.

IBM’s eX5 technology-based systems are the ideal solution for scale-up database-serving

applications on Microsoft

Windows

with Microsoft SQL Server

or IBM DB2

, as well as

Linux

with Oracle or DB2. Database hosting demands ultimate server reliability features, and

once installed, they tend to grow and grow, requiring ever greater levels of availability. eX5

servers provide exactly that degree to availability.

Another strong application area for the eX5-based systems is enterprise server consolidation

activities workloads, including SAP and Oracle. eX5 systems can offer considerable savings

over UNIX

deployments, using our certified solution stacks on either Windows or Linux..

Larger servers need more processor, memory and I/O resources, which make maximum use

of any applicable virtual machine software licensing fees and deliver superior system

utilization levels. The name of the game in consolidation activities is to deploy the fewest new

servers possible and help IT staff manage more images with the same or fewer overall

people.

These eX5 servers are designed to protect your data with high performance, high reliability,

Ultrascalability combined with extreme availability

features and industry-leading performance

Please see the Legal Information section for important notices and information.

and high availability. They support the latest ten-, eight-, six-, and four-core Intel

Xeon

family and 7500 series processors, up to 1066MHz memory access, and up to 30MB of L3

cache to help provide you with the computing power you need to match your business needs

and growth. The new Xeon E7-8800 and E7-4800 series processors offer up to 40% greater

performance than the previous-generation Intel 7500 series processors.

In addition, the x3850 X5 and x3950 X5 use industry-standard DDR3 memory with Chipkill

™

ECC (Error Checking and Correcting) protection—for high performance and reliability. For

even higher levels of availability, the eX5 servers also offer Memory ProteXion

™

, memory

scrubbing, memory rank sparing, and selectable memory mirroring.

A dual-port integrated high-speed Gigabit Ethernet controller with TOE (TCP Offload

Engine) acceleration is standard. In addition, a dual-port 10bE virtual fabric adapter is

standard in most models. The 10GbE solution provides the benefits and flexibility of I/O

convergence in a single end-to-end solution. The x3850 offers seven high-performance PCIe

adapter slots (six available, if the 10GbE NIC is installed).

The x3850 X5 and x3950 X5 offer industry-leading scalability, including 4-processor support

(upgradeable to 8 processors / 80 cores in two chassis/nodes), up to 2TB of memory per

chassis (upgradeable to 2TB in two nodes, or 3TB with MAX5), and a choice of up to eight

2.5-inch internal Serial-Attach SCSI (SAS) or Serial ATA II (SATA II) hot-swap hard disk

drives with an internal storage capacity of 4TB per chassis (up to 16 drives and 6TB overall,

in a two-chassis configuration), or sixteen 1.8-inch solid-state drives (SSDs) with a

capacity of 3.2TB per chassis (6.4TB in two nodes).

All models include a ServeRAID-BR10i V2 controller, which supports hardware RAID-0/1/1E.

This controller is installed in a dedicated RAID slot, and can be upgraded with optional IBM

ServeRAID SAS/SATA/SSD RAID controllers, which add up to 512MB of battery-backed

cache, RAID-10/5/50 support, and optionally RAID-6/60 and full disk encryption, via SED

(Self-Encrypting Disk). The 4U size of the chassis helps you maximize your rack investments.

Up to 10 of these chassis can be installed in a single 42U rack, for a total of up to 40

processors (400 cores), 70 PCIe slots, and 80 HDDs or 160 SSDs, offering an ideal balance

of performance, storage and I/O slots per rack.

Standard in both the x3850 X5 and the x3950 X5 is the Integrated Management Module

(IMM) that enables the user to manage and control the server easily—both locally and

remotely. The IMM offers a high level of manageability that is designed to keep costs down

and the system up—even when network usage increases. The drop-down light path

diagnostics panel enables quick servicing of the system if a problem develops. These

advanced features help maximize network availability by increasing uptime, as do IBM

OnForever™ features, such as hot-swap/redundant HDDs, power and fans; Active

Memory

™

; temperature-controlled fans with Calibrated Vectored Cooling

™

; IPMI 2.0

support, including highly secure remote power control and Serial over LAN; as well as

text- and graphics-console redirect over LAN.

Another improvement with the new generation of X-Architecture is the replacement of legacy

BIOS with a new generation Unified Extensible Firmware Interface (UEFI). UEFI provides

a more intuitive user interface and understandable event logs and better management.

With the inclusion of unique IBM service and support features such as IBM Systems

Director, IBM Systems Director Active Energy Manager™, and IBM ServerGuide

™

, the

x3850/x3950 X5 is designed for maximum uptime.

If you need a balance of high-performance four-socket processing, scalability up to eight

sockets, enormous memory expansion, and large I/O capacity in a rack-dense environment,

these are the ideal systems.

Key Highlights

eX5 Design Features

eX5 design offers numerous features per chassis to boost performance and reduce product

and operating costs:

• Supports up to four Intel Xeon processors with 12MB to 30MB of L3 cache (processor

dependant), and Intel Virtualization Technology (VT) , Hyper-Threading (HT) technology,

and Turbo Boost technology.

• Supports 10-core, 8-core, or 6-core Xeon E7 family processors or 8-core, 6-core or 4-

core Xeon 7500 series processors, scalable to 8 processors in a two-chassis

configuration.

• Supports up to 2TB of DDR3 memory in a single 4U chassis/node. A two-node (8U)

configuration supports up to 4TB and doubles all other system resources as well

(HDD/SDD capacity, 10Gb/1Gb Ethernet ports, adapter slots, etc.).

• The 7143 machine type supports low-voltage 1.35V DIMMs.

• Support for a MAX5 memory expansion unit, increasing memory capacity by 50% for

memory-intensive workloads. One chassis with one MAX5 supports up to 3TB of

Produkt Specifikationer

Mærke:	Ibm
Kategori:	Server
Model:	System x x3950 X5
Bredde:	440 mm
Dybde:	712.1 mm
Højde:	172.8 mm
Vægt:	49900 g
Relativ luftfugtighed ved drift (H-H):	8 - 80 %
Ethernet LAN-porte (RJ-45):	2
Ethernet LAN:	Ja
Processorkerner:	10
Driftstemperatur (T-T):	10 - 35 °C
Intern hukommelse:	512 GB
Operativsystem installeret:	Ingen
Kabelteknologi:	10/100/1000Base-T(X)
HDD kapacitet:	600 GB
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	2.4 GHz
Processorserie:	Intel® Xeon® E7 Family
Processor boost frekvens:	2.8 GHz
Processortråde:	20
Processor-cache:	30 MB
Processor cache type:	Smart cache
Intern hukommelsestype:	DDR3-SDRAM
Hukommelsesur hastighed:	1066 MHz
Maksimal intern hukommelse:	- GB
Samlet lagringskapacitet:	4800 GB
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ja
Intel® Turbo Boost Teknologi:	1.0
Kompatible operativsystemer:	Windows Server 2008\nRed Hat Enterprise Linux\nSUSE Enterprise Linux\nVMware vSphere Hypervisor
Hukommelsesstik:	32
Processorproducent:	Intel
Processormodel:	E7-8870
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
CPU-konfiguration (maks.):	8
Intel® VT-x with Extended Page Tables (EPT):	Ja
Indlejret tilgængelige muligheder:	Ingen
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Virtualization Technology (VT-x):	Ja
Netværk klar:	Ja
HDD-grænseflade:	Serial Attached SCSI (SAS)
Netværksfunktioner:	Gigabit Ethernet
Antal installerede processorer:	4
Bus type:	QPI
Kabinettype:	Stativ (4U)
Intel® Flex Memory Access:	Ingen
Intel® Trusted Execution Teknologi:	Ja
Intel® Enhanced Halt State:	Ingen
Intel® klar video teknologi:	Ingen
Konfliktfri processor:	Ingen
HDD-størrelse:	2.5 "
Strømforsyning:	1975 W
Processor sokkel:	LGA 1567 (Socket LS)
Processor litografi:	32 nm
Stepping:	A2
Thermal Design Power (TDP):	130 W
Fejlkorrigerende kode understøttet af processor:	Ja
Processor front side bus:	- MHz
Systembus-hastighed:	6.4 GT/s
Processor driftstilstande:	64-bit
Processor kodenavn:	Westmere EX
FSB Paritet:	Ingen
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Clear Video HD Teknologi (Intel® CVT HD):	Ingen
Intel® Insider™:	Ingen
Intel® My WiFi Teknologi (Intel® MWT):	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Quick Sync Video Teknologi:	Ingen
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ja
Intel® Demand Based Switching:	Ingen
Termiske overvågningsteknologier:	Ja
Intel® Dual Display Capable Teknologi:	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Intel® Fast Memory Access:	Ingen
Intel® Clear Video Teknologi til MID (Intel® CVT for MID):	Ingen
Processor-pakke størrelse:	49.17 x 56.47 mm
Processor kode:	SLC3E
Processor ARK ID:	53580
Antal installerede HDD'er:	8
CPU-multiplikator (bus/kerneforhold):	18
Understøttede instruktionssæt:	SSE4.1, SSE4.2
Understøtter RAID:	Ja
Maksimal lagerkapacitet:	- TB
Redundant strømforsyning:	Ja
Maksimal grafikadapterhukommelse:	16 MB
Hot-swap:	Ja
RAID-niveauer:	0, 1
Billedtypekort:	<div><img src="https://ark.intel.com/inc/images/diagrams/diagram-17.gif" title="Block Diagram" /></div>
Maksimal intern hukommelse understøttet af processor:	4096 GB
Hukommelsestyper understøttet af processor:	DDR3-SDRAM
Hukommelsesurhastigheder understøttet af processor:	800,978,1066,1333 MHz
Tcase:	69 °C
Skalerbarhed:	S8S
Maksimalt antal SMP-processorer:	4
Antal strømforsyninger:	2
Hukommelseskanaler understøttet af processor:	Quad
Reboot beskyttelse:	Ja
