Side 1/2

User Manual

Slot PC

OPC51204

(OPC51204xx series)

M239B21

Function Frequency Maximum Output

Power (EIRP)

WiFi

2412-2472 MHz 19.32 dBm

5150-5250 MHz 20.72 dBm

5250-5350 MHz 20.81 dBm

5470-5725 MHz 21.00 dBm

5725-5850MHz 13.96 dBm

Bluetooth 2402-2480 MHz 8.96 dBm

RF&POWER

 Before using and operating this device, please read

thoroughly and comply with the following precautions in

order to prevent accidents or mal-operations.

 Do not charge or use the device in dusty or wet conditions,

to prevent internal circuit failure.

 Keep the device away from heat sources such as an

electric heater.

 This device and its parts may contain some small

components, so keep the product out of reach of children to

prevent accidents.

 This device is not water-resistant, please keep it dry.

 The normal working temperature for the product is

0°C~45°C, and the normal working humidity is 10%~95%.

 Please contact professional service personnel for

maintenance services.

 Do not insert any sharp or pointed object into the device.

 Prevent the device from falls and collisions with other

objects, which may cause damages.

 There are heating hole on back cover, do not spray water

to it or use damp cloth for cleaning;

 Please call professional personnel for maintenance service.

STATEMENT

The image shown in this manual is indicative only. If there is

inconsistency between the image and the actual product, the

actual product shall govern.

SAFETY WARNING

xx: RAM and SSD size control code

Here, IIYAMA Corporation declares that the Slot PC

complies with Directive 2014/53/EU Radio Equipment

Directive, 2011/65/EU RoHS Directive, Radio Equipment

Regulation 2017 and The Restriction of the Use of Certain

Hazardous Substances in Electrical and Electronic Equipment

Regulations 2012.

The full text of the EU and UK declaration of the conformity is

available at the following internet address: https://iiyama.com

Please refer to https://iiyama.com to download the

User manual and driver.

We recommend recycling of used product.

Please contact your dealer or iiyama service

center. Recycle information is obtained via

the Internet, using the address:

https://iiyama.com

You can access the Web page of diﬀ erent

countries from there.

CHECKING THE CONTENTS OF THE PACKAGE

 Slot PC x 1

 Installation manual x 1 (this document)

OPS PC MODULE SPECIFICATION

INSTALLATION PROCEDURE

NOTE Before mounting and using the Monitor, please follow the steps below to install the Slot PC. The

installation should be performed by at least two adult persons to avoid danger and injuries.

Please make sure the power cable of the Monitor is disconnected before installation.

Do not plug or unplug the Slot PC while the monitor is powered on. Slot PC may be broken.

When using for the ﬁ rst time, if the screen is blurred, ﬂ ickering, no signal, etc. after booting, Slot PC

may not be installed correctly; please check the installation status or reinstall it.

1. Insert Slot PC into the panel slot 2. Press the power button to turn it on and operate like a

regular computer

Product Speciﬁ cation

Type Slot PC

CPU

12th Generation Intel

Core

i5-12450H

RAM DDR4 3200MHz 8GB, Max. 32GB

SSD PCIe 256GB, Max. 1T

Graphics Integrated Intel® UHD Graphics for

12th Gen

Sound Card Integrated HS-100B

Ethernet Card Integrated 10M/100M/1000M

Adaption RTL8111H

Wi-Fi

Intel AX200 + BT5.2

Support 802.11a/b/g/n/ac/ax (Wiﬁ 6)

Speed: 2.4Gbps

Bluetooth 5.2

Operating system Windows 11 IoT Enterprise 64Bit

Security Device

Support TPM2.0

I/O Port

Antenna 2

USB3.2 Gen 1 (5Gbps, DC5V, 900mA) 4

USB3.2 Gen2 10Gbps Type-C(DC5V,

900mA) (Not Support DP ALT mode) 1

HDMI2.0 OUT

(Max resolution 3840 x 2160 60Hz) 1

DP1.4 OUT

(Max resolution 3840 x 2160 60Hz) 1

MIC IN 1

Audio OUT 1

RJ45 1

SSD LED (Running : Green LED blinking)

I/O Port

POWER LED (Power on : Red LED) 1

80 PIN Support

Kensington Lock 1

Power Button 1

System recovery Button 1

Power

Power Requirements 12-19Vdc, 8A

Max Power 80.7W

Standby Power 2.9W

Physical Speciﬁ cation

Dimension 180.0 x 119.0 x 30.0 mm (L x W x H)

Dimension(package) 267.0 x 192.0 x 72.0 mm (L x W x H)

Net Weight 0.60kg

Gross Weight 0.97kg

Environmental Condition

Operation Temperature

0 to 45

Operation Humidity 10% to 95% RH (non condensing)

Storage Temperature

-10 to 50

Storage Humidity 10% to 95% RH (non condensing)

Please ensure the Slot PC is inserted

correctly by making sure the Caution-

Label(yellow) and the fan are facing

outwards.
