Side 1/2

Quick guide

THANK YOU FOR BUYING AN INDESIT PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

FIRST TIME USE

HEAT THE OVEN

A new oven may release odours that have been left behind during

manufacturing: this is completely normal.Before starting to cook food,

we therefore recommend heating the oven with it empty in order

to remove any possible odours. Remove any protective cardboard

or transparent lm from the oven and remove any accessories from

inside it. Heat the oven to 250 °C for about one hour: The oven must be

empty during this time. Follow the instructions for setting the function

correctly.

Please note: It is advisable to air the room after using the appliance for the

first time.

CONTROL PANEL

100

120

140

160

180

200

220

250

1234

1. SELECTION KNOB

For switching the oven on by selecting a function. Turn to the position

to switch the oven o.

2. TIMER KNOB

Useful as a timer. Does not activate or interrupt cooking.

3. THERMOSTAT KNOB

Turn to select a desired temperature, activating the selected function.

4. LED THERMOSTAT / PREHEATING

Switches on during the heating process. Switches o once the desired

temperature is reached.

ACCESSORIES

The number and type of accessories may vary depending on which model

is purchased. Other accessories that are not supplied can be purchased

separately from the After-sales Service.

WIRE SHELF Use to cook food or as asupport for pans,

cake tins and other ovenproof items of cookware.

DRIP TRAY* Use as an oven tray for cooking meat, sh,

vegetables, focaccia, etc. or position underneath the

wire shelf to collect cooking juices.

BAKING TRAY* Use for cooking all bread and pastry

products, but also for roasts, sh en papillotte, etc.

Insert the wire shelf onto the level you require by holding it tilted slightly

upwards and resting the raised rear side (pointing upwards) down first.

Then slide it horizontally along the shelf runners as far as possible. The

other accessories, such as the baking tray, are inserted horizontally by

sliding them along the shelf runners.

* Available only on certain models.

FUNCTIONS & DAILY USE

1. SELECT A FUNCTION

To select a function, turn the to the symbol for the selection knob

function you require.

OFF

For switching o the oven.

LIGHT

For switching on the light in the compartment.

CONVENTIONAL

For cooking any kind of dish on one shelf only.

CONVENCTION BAKE

For baking cakes with juicy llings on a single shelf. This function

can also be used for cooking on two shelves. Switch the position of the

dishes to cook food more evenly.

GRILL

For grilling steaks, kebabs and sausages, cooking vegetables au

gratin or toasting bread. When grilling meat, we recommend using a

tray to collect the cooking juices: Position the tray on any of the levels

below the wire shelf and add 200 ml of drinking water.

GRATIN

For roasting large joints of meat. We recommend using a tray to

collect the cooking juices: Position the tray on any of the levels below

the wire shelf and add 500 ml of drinking water.

DEFROSTING

For defrosting food more quickly.

2. ACTIVATE UNCTION A F

To start the function you have selected, turn the thermostat knob to

set the temperature you require. To interrupt the function at any time,

switch o the oven, turn the nd the selection nob k a thermostat knob to

and .

3. PREHEATING

Once the function has been activated, the LED thermostat will switch

on signalling that the preheating process has begun. At the end of this

process, the LED thermostat switches o indicating that the oven has

reached the set temperature: at this point, place the food inside and

proceed ith ooking. w c

Please note: Placing the food in the oven before preheating has finished

may have an adverse effect on the final cooking result.

4. SETTING THE TIMER

This option does not interrupt or activate cooking but allows you to

use the minute minder both while a function is active and when the

oven is off. To activate the timer, turn the timer knob fully clockwise

and then return it to desired duration, proceeding counterclockwise:

an acoustic signal will warn you when the countdown is finished.

CLEANING AND MAINTENANCE

Make sure that the oven has cooled down before carrying out any maintenance or cleaning. Do not use steam cleaners. Do not

use wire wool, abrasive scourers or abrasive/corrosive cleaning agents, as these could damage the surfaces of the appliance. Wear

protective gloves. The oven must be disconnected from the mains before carrying out any kind of maintenance work.

EXTERIOR SURFACES

Clean surfaces with a damp microbre cloth. If they are very dirty,

add a few drops of pH-neutral detergent. Finish o with a dry cloth.

Do not use corrosive or abrasive detergents. If any of these products

inadvertently comes into contact with the surfaces of the appliance,

clean immediately with a damp microbre cloth.

INTERIOR SURFACES

After every use, leave the oven to cool and then clean it, preferably

while it is still warm, to remove any deposits or stains caused by

food residues. To dry any condensation that has formed as a result

of cooking foods with a high water content, leave the oven to cool

completely and then wipe it with a cloth or sponge. Clean the glass in

the door with a suitable liquid detergent.

ACCESSORIES

Soak the accessories in a washing-up liquid solution after use, handling

them with oven gloves if they are still hot. Food residues can be

removed using a washing-up brush or a sponge.

LOWER THE TOP HEATING ELEMENT (Only in some models)

The top heating element of the grill can be lowered to clean the upper

panel of the oven: Extract the heating element from its seating, then

lower it. To return the heating element to its position, lift it up, pull it

slightly towards you and make sure that the tab support is in its proper

seating.

REMOVING AND REFITTING THE DOOR

To remove the door, open it fully and lower the catches until they are

in the unlock position (1). Close the door as much as you can (2). Take

a rm hold of the door with both hands - do not hold it by the handle.

Simply remove the door (3) by continuing to close it while pulling it

upwards (a) at the same time until it is released from its seating (b).

1 2

~60°

~15°

Put the door to one side, resting it on a soft surface. Ret the door by

moving it towards the oven, aligning the hooks of the hinges with their

seating and securing the upper part onto its seating. Lower the door

and then open it fully. Lower the catches into their original position:

make sure that you lower them down completely. Try closing the door

and check to make sure that it lines up with the control panel. If it does

not, repeat the steps above.

CLICK & CLEAN - CLEANING THE GLASS

After removing the door and resting it on a soft surface with the

handle downwards, simultaneously press the two retaining clips (1) and

remove the upper edge of the door by pulling it towards you (2).

1 2

Lift and rmly hold the inner glass with both hands, remove it and

place it on a soft surface before cleaning it (3).

To correctly reposition the inner glass, make sure that the “R” is visible

in the left-hand corner and the clear surface (not printed) is facing up.

First insert the long side of the glass indicated by “R” into the support

seats, then lower it into position (4). Ret the upper edge (5): a click

will indicate correct positioning. Make sure the seal is secure before

retting the door.

4 5

REPLACING THE LAMP

Disconnect the oven from the power supply, unscrew the cover from

the light, replace the bulb and screw the cover back on the light.

Reconnect the oven to the power supply. Do not use the oven until the

light cover has been retted.

Please note: Only use 25W/230 ~ V, G9 type, T300°C halogen bulbs. The

bulb used in the product is specifically designed for domestic appliances

and is not suitable for general room lighting within the home. Light bulbs

are available from our After-sales Service.

TROUBLESHOOTING

What to do if... Possible reasons Solutions

The oven is not working. Power cut.

Disconnection from the mains.

Check for the presence of mains electrical power and whether the

oven is connected to the electricity supply.

Turn o the oven and restart it to see if the fault persists.

400011097434

You can download the Safety Instructions, User Manual, Product Fiche and Energy data by:

• Visiting our website docs . indesit . eu

• Using QR Code

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When

contacting our After-sales Service, please state the codes provided on your product's identication

plate.

X XXX XXXXX XXXXX

Mode l: xxxXXXXx x
