ENQuick Guide

PROGRAMS TABLE

Program Programs description

Drying

phase

Auto Door

Available

options *)

Duration

of wash

program

(h:min)**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50° - Eco program is suitable to clean normally soiled tableware. that

for this use. it is the most ecient program in terms of its combined ener-

gy and water consumption. and that it is used to assess compliance with

the EU Ecodesign legislation. 3:10 9.5 0.85

2. Intensive 65° - Program recommended for heavily soiled crockery. espe-

cially suitable for pans and saucepans (not to be used for delicate items). 2:50 17.0 1.60

Mixed 55° - Mixed soil. For normally soiled dishes with dried food residues.

3:00 15.0 1.40

4. Fast&Clean 28’ 45° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Does not have drying phase. - 0:28 9.0 0.50

5. Pre-Wash - Use to refresh crockery planned to be washed later. No deter-

gent to be used with this program. - - 0:12 4.5 0.01

6. Push&Go - 50° Everyday wash and dry cycle that ensures great cleaning

performance in a short time without the need to pre-treat dishes. 1:25 11.5 1.10

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

CONTROL PANEL

1. On-O/Reset button with indicator

light

2. Program selection button with

indicator light

3. Half Load button with indicator light

4. Rinse Aid rell indicator light

5. Salt rell indicator light

6. Program indicator lights

7. Delay indicator light

8. Delay button with indicator

light

9. Push&GO button with indi-

cator light

10. Start/Pause button with

indicator light / Drain out

FIRST TIME USE

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into the

container during the wash program (this could damage the water softener be-

yond repair). Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser should be lled when the A RINSE

AID REFILL indicator light in the control pan-

el is lit. NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device . Introduce the C

detergent into the dry dispenser only. Place the amount of detergent for D

pre-washing directly inside the tub.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

1 2 43 5 6 7

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance, please register

your appliance on: www.indesit.com/register

Before using the appliance carefully read Safety Instructions

guide.

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

Quick GuideEN

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website and docs.indesit.eu parts-selfservice.whirlpool.com

• Alternatively, (See phone number in the warranty booklet). When contacting our After-contact our After-sales Service

sales Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model

identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

TROUBLESHOOTING Please scan on your product in order to have more detailed information. the QR code

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher

does not ll the

water.

All LEDs are blink-

ing rapidly

No water in the water supply or the tap is

closed. Make sure there is water in the water supply or the tap running.

The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher

and reboot.

The sieve in the water inlet hose is clogged; it

is necessary to clean it.

After having carried out the verication and cleaning, turn o and turn on the

dishwasher and restart a new program.

Dishwasher

nishes the cycle

prematurely.

Drain hose positioned too low or siphoning

into home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check for

siphoning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

LOADING THE RACKS CAPACITY: 14 standard place-settings

UPPER RACK

(loading example for the upper rack)

Load delicate and light dishes: glass-

es, cups, saucers, low salad bowls.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

(loading example for the upper rack)

For pots, lids, plates, salad bowls, cutlery etc. Large

plates and lids should ideally be placed at the

sides to avoid interferences with the spray arm.

CUTLERY BASKET

It is tted with top grids

for improved cutlery ar-

rangement. It must only

be positioned at the

front of the lower rack.

Knives and other

utensils with sharp

edges must be placed

in the cutlery basket

with the points facing downwards or they

must be positioned horizontally in the tip-

up compartments on the upper rack.

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)

please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may be

removed by pulling it up-

wards.

DELAY - It is possible to delay the start time of the program by 2, 4 or

8 hours:

The DELAY function cannot be set once a wash cycle has been started.

PUSH&GO button is an easily distinguishable button that allows you

direct access to the Push&GO program, a wash and dry cycle that en-

sures great cleaning performance in a short time. You don’t have to worry

which program to choose, Push&GO cycle will do the work for you.

To select Push&GO program, switch on appliance, press only Push&GO

button for 3 seconds.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program

(see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

HALF LOAD - If there are not many dishes to be washed, a half load-

ing may be used in order to save water, electricity and detergent.

Remember to halve the amount of detergent.

Please scan the on your product in order to have more detailed information. QR code

AUTO DOOR is a convection drying system which automatically

opens the door during/after drying phase to ensure exceptional dry-

ing performance every day. Door opens at the temperature that is

safe to your kitchen furniture.

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Opvaskemaskine
Model:	I3B L634 X
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Berøring
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.3 m
Pakkevægt:	34300 g
Pakkedybde:	675 mm
Pakkebredde:	625 mm
Pakkehøjde:	910 mm
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Delvist indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	44 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	6
Forsinket start-timer:	Ja
Dør farve:	Ikke anvendelig
Indikator for LED-programfase:	Ingen
Vandforbrug pr. cyklus:	9.5 L
Bestik rum type:	Kurv
Antal kuverter:	14 kuverter
Cyklustid:	190 min.
Opvaskeprogrammer:	Eco 50°C, Intensive 65°C, Mixed, Quick
Halv belastning:	Ja
Indikator for afspændingsmiddel:	Ja
Energieffektivitetsskala:	A til G
AquaSensor funktion:	Ingen
AquaStop funktion:	Ingen
Indikator for resterende tid:	Ingen
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Støjemissionsklasse:	B
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	85 kWh
Brugerdefineret panel klar:	Ja
Temperatur (maks):	- °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Doseringsassistent:	Ingen
Selvrensende filter:	Ingen
Antal kurve:	2 kurv(e)
Automatisk belastningsgenkendelse:	Ingen
Ready-indikator:	Ja
Gulvindikatorlys:	Ingen
Automatiske programmer:	Ingen
Garantiperiode:	10 År
Startforsinkelse (min):	8 t
