D E C A D E

™

D S 3 5 , D S 4 5 , D S 5 5 , D S 6 4 5 , D S 6 5 , D S 7 5 5 , D S 9 6 5

G E N U I N E J B L

Thank you for purchasing a JBL

Decade™ Series multielement speaker

system. We’ve organized this manual to

make your installation as simple and

trouble-free as possible. Please read it

thoroughly before proceeding.

Remember to keep your sales receipt

with this manual in a safe place so both

are available for future reference.

Important

Installation of automotive stereo compo-

nents can require extensive experience

with a variety of mechanical and electri-

cal procedures. Although these instruc-

tions explain how to install a JBL

Decade Series multielement speaker

system in a general sense, they do not

show the exact installation methods for

your particular vehicle. In many cases,

removing door or rear-deck panels

is necessary to gain access to the

mounting location. This procedure may

require specialized tools and a skilled

installer. If you do not feel you have the

tools or experience necessary, do not

attempt the installation yourself, but

instead ask your authorized JBL dealer

about professional installation options.

Warning

Playing loud music in an automobile

can permanently damage your hearing,

as well as hinder your ability to hear

trac. The maximum volume levels

achievable with JBL speakers, combined

with high power amplication, may

exceed safe levels for extended listen-

ing. We recommend using low volume

levels when in your car. JBL accepts no

liability for hearing loss, bodily injury or

property damage as a result of use or

misuse of this product.

Installation Warnings and Tips

•Always wear protective eyewear when

using any tools.

•Turn off all audio systems and other

electrical devices before you start.

Disconnect the negative (–) lead from

your vehicle’s battery.

•Keep speakers in their package until

nal installation. When moving a

speaker, always rest it with the cone or

dome facing up. Never use force to

install any speaker.

•Check clearances on both sides of a

planned mounting surface before

drilling any holes or installing any

screws. Remember that the screws can

extend behind the surface.

•At the installation sites, locate and

make a note of all fuel lines, hydraulic

brake lines, vacuum lines and electrical

wiring. Use extreme caution when cut-

ting or drilling in and around these

areas.

Caution: In some cars, fuel tanks may be

located directly beneath the rear deck.

Check for adequate speaker-basket clear-

ance before considering this location!

•Before drilling or cutting holes, use a

utility knife to remove unwanted fabric

or vinyl in order to keep material from

snagging in a drill bit or saw.

•For door installations, check the clear-

ance with the windows throughout the

range of the window’s travel, and verify

that a mounted speaker will not inter-

fere with the window crank or power-

window mechanism.

•If mounting speakers elsewhere, check

for clearance around rear-deck torsion

bars, glove box or other structural

elements.

•Do not mount speakers where they will

get wet.

Grille

Screen

Trim Ring

Car Door

Installation

Note: The DS35, DS645 and DS75 speak-

ers are designed for direct replacement

of factory speakers. Therefore, they do

not contain the grilles and trim ring

shown in Fig 1. Installation of these mod-

els simply entails reversing the steps

taken to remove the original speakers.

Figure 1

Typical installation of the DS45, DS55,

DS65, DS965.
