THANK YOU

for purchasing a JBL

Grand Touring

Series automotive

speakers. We’ve organized this manual to make your

installation as simple and trouble-free as possible.

Please read it thoroughly before proceeding. Remember

to keep your sales receipt and this manual in a safe

place so both are available for future reference.

GRAND

TOURING

SERIES

GTO327

GTO427

GTO527

GTO627

GTO637

GTO6427

GTO6527

GTO6527S

GTO6537

GTO837

GTO8627

GTO927

GTO937

multielements

owner’s manual

INSTALLATION WARNINGS AND TIPS

ABOUT THESE

INSTRUCTIONS

Installation of automotive stereo components

can require extensive experience with a

variety of mechanical and electrical

procedures. Although these instructions

explain how to install Grand Touring Series

multielement speakers in a general sense,

they do not show the exact installation

methods for your particular vehicle. If

you do not feel you have the necessary

experience, do not attempt the installation

yourself – instead, ask your authorized

JBL car audio dealer about professional

installation options.

LOUD MUSIC AND HEARING

Playing loud music in an automobile can

hinder your ability to hear trafﬁc as well as

permanently damage your hearing. The

maximum volume levels achievable with

JBL speakers, combined with high power

ampliﬁcation, may exceed safe levels for

extended listening. We recommend using

low volume levels when driving. JBL

accepts no liability for hearing loss, bodily

injury or property damage as a result of use

or misuse of this product.

REAR DECK PRECAUTION

In some cars, the fuel tank may be located

directly beneath the rear deck. Before

installation, make sure there is adequate

speaker basket clearance before

considering this location.

INSTALLATION TIPS

• Always wear protective eyewear when

using any tools.

• Turn off all audio components and other

electrical devices before you start.

Disconnect the (–) negative lead from your

vehicle’s battery.

• Keep speakers in their package until ﬁnal

installation. When moving a speaker,

always rest it with the cone or dome

facing up. Never use force to install

any speaker.

• Check clearances on both sides of a

planned mounting surface before drilling

any holes or installing any screws.

Remember that the screws can extend

behind the surface.

• At the installation sites, locate and make a

note of all fuel lines, hydraulic brake lines,

vacuum lines and electrical wiring. Use

extreme caution when cutting or drilling in

and around these areas.

• Before drilling or cutting holes, use a utility

knife to remove unwanted fabric or vinyl

to keep material from snagging in a drill bit

or saw.

• For door installations, check the clearance

with the windows throughout the range of

the window’s travel, and verify that a

mounted speaker will not interfere with

the window crank or power window

mechanism.

• If mounting speakers elsewhere, check for

clearance around rear deck torsion bars,

glove box or other structural elements.

• Do not mount speakers where they will

get wet.

UNIPOINT

™

ROTATING

TWEETER

Figure 1. Turn the angled tweeter on the

GTO527, GTO627, GTO6527, GTO8627 and

GTO927 to aim the sound at the listener.

TWEETER LEVEL CONTROL

Figure 2. Move the tweeter level control

switch on the GTO527, GTO627, GTO637,

GTO6527, GTO6527S, GTO6537, GTO837,

GTO8627, GTO927 and GTO937 to select

0dB (reference) or +3dB.

INSTALLATION
