Flush-mounted radio with
display RAD...
Device descripon
The Jung ush-mounted radio RAD… consists
of a display cover and a ush-mounted
power supply unit.
The display cover is used for display and
operaon. All the sengs are made using
the sensor buons. The display shows the 8
staon informaon from RDS, the me and
the current sengs.
The radio power supply unit contains the
connecons for the mains voltage, inputs
and the loudspeaker.
The radio can be operated with one or two
LSM... loudspeaker modules.
The extension input allows the radio to be
switched on or o, e.g. together with the
light.
The radio signal is obtained from the
connecon to the mains voltage. In
situaons where recepon is dicult, the
oponal cord aerial can be used.
Other audio sources can be played back
using an AUX input, e.g. using the music
centre MC..100… .
Safety information
Electrical equipment must only be installed
and assembled by qualied electricians.
Failure to comply with these instrucons
may result in damage to the device, re or
other hazards.
This product is only intended for use in dry
rooms.
These instrucons are a component part of
the product and must remain with the end
customer.
Operaon
The lower half of the cover is used for
operaon. All operaon is carried out using
8 sensor buons.
When idle, the buons and display may be
hidden, depending on the sengs.
They are reacvated when the sensor
buons are touched again.
Switch-on / Switch-o
The radio is switched on and o
here.
If the buon is pressed for 3 seconds when
the system is switched on, then the sleep
mer (fall asleep funcon) can be acvated.
Sengs
Basic conguraon of brightnesses,
alarm me, and much more.
Alarm funcons
The alarm, which has a gradually
increasing volume, is switched on
and o here.
If the buon is pressed for longer than
3 seconds, this opens the menu for seng
the alarm me.
Favourites
Preferred staons can be saved to
the Favourites or the AUX input
selected.
Operang buons
Staon search, volume seng and the
navigaon/
seng in the menu.
Brightness of display during standby
adjusts the brightness for the
standby state.
The lowest level is Night mode.
Night mode
In Night mode, the display is switched o
completely as standby.
Pressing any buon brings the display back
from Night mode.
Main menu
Aer switch-on, the staon informaon and
status line are shown in the display.
The status line provides informaon on the
selected favourites, me and alarm
operaon.
When idle, this informaon is reduced to the
me and date.
Staon selecon
The next staon is selected using the
buons.
RDS (Radio Data System)
During operaon, the display shows the
staon name and, in some cases, addional
informaon, e.g. on the current song.
If this informaon is not available, then
frequency informaon on the selected radio
staon is displayed.
Adjusng the volume
The volume is adjusted using .
Favourites
Briey pressing the buon selects the
saved favourites or the AUX input.
Cancel Select -/+ Conrm
In radio operaon, a long press of the
buon (> 3 s) adds the current staon to the
Favourites list.
Up to 8 favourites are possible.
Sengs
The submenus can be found using the
buon. The menu is operated with the
sensor buons below.
Cancel Select -/+ Conrm
Here you can select one of the following 8
submenus with the +/- buons.
With the buon you get into the
selected submenu to change required
sengs.
AUX input
When the AUX input is acvated, radio
recepon is terminated and playback comes
from the external source. If the input is
deacvated again, radio operaon will
recommence.
Alarm me
The set alarm me starts the radio with an
increasing volume.
The display and buons are previously
illuminated at full brightness.
The buons terminate any further
increase in volume.
The buon switches the alarm o.
The buon switches the funcon on and
o.
Sleepmer (Fall asleep funcon)
The Sleepmer (fall asleep funcon)
switches the radio o automacally aer
the selected period of me.
The countdown is displayed in the status
line.
Buon brightness
The brightness and switch-o behaviour of
the buons can be varied.
On switching-o, the informaon in the
display is reduced to the display of staon
name and the me.
If the system is operated again, the buons
become brighter again.
Brightness of operaonal display
The display brightness can be reduced.
Loudspeaker
During operaon, the radio switches
between stereo and mono operaon
automacally. If recepon condions are
variable, it may be wise to select connuous
mono operaon. This allows two dierent
areas to be lled with sound.
Time
Normally, the recepon of an RDS staon is
sucient to perform this seng
automacally. However, the current me
can also be set manually.
Default seng
The state as delivered is restored. In so
doing, the 8 strongest staons are saved
automacally.
Flush-mounted radio with
display RAD...
Operang instrucons
Albrecht Jung GmbH & Co. KG
Volmestrasse 1
58579 Schalksmühle
Germany
www.jung.de
We reserve the right to make technical
changes.
en_RAD_V3.docx
02/2014
0024073100
The symbol is a free trade symbol,
intended solely for the authories and does
not carry any guarantee of properes.
Guarantee
Our products are under guarantee within
the scope of the statutory provisions.
Please send the device, postage paid, to our
central Customer Service Centre, with a
descripon of the error.
ALBRECHT JUNG GMBH & CO. KG
Volmestrasse 1
58579 Schalksmühle
Germany
Telephone: +49 2355 806-0
Fax: +49 2355 806-204
kundencenter@jung.de
www.jung.de
Service Centre
Kupferstr. -17 19
44532 Lünen
Germany
Correct use
• Installaon in a ush-mounted device box
according to DIN EN 49073
(Recommendaon: Deep sockets)
• VHF recepon in the frequency range
87.5 MHz to 108 MHz
Product properes
• VHF radio with display and sensor buons
• Real glass front panel
• Stereo recepon
• Connecon terminals for two loudspeakers
• Stereo/mono switch-over
• Simple operaon
• Integrated VHF aerial
• High level of recepon quality
• Automac and manual staon search
• Storage of 8 favourites
• Switch-on with most recent staon
• Switch-on with most recent volume
• Alarm funcon
• Sleep mode
• Switch-on/switch- f using extension of
• Oponal external cord aerial
Art. no. RAD-ANT available as accessory
Mounng
The radio RAD… is designed for mounng in
ush-mounted DIN EN 49073 sockets.
The ush-mounted power supply unit
contains the connecons for the mains
voltage, loudspeaker and possibly the
extension.
The display cover is aached to the power
supply unit together with the frame.
DANGER!
Touching live parts can result in an
electric shock.
An electric shock can be fatal.
Before working, disconnect all the
appropriate cable protecon
switches. Cover live parts in the
vicinity.
Mains connecon
The radio requires a permanent mains
power connecon.
It is not allowed to use the terminals to loop
through wires.
Connecng the extension
The extension connecon is used to switch
the radio o and on using switches,
e.g. together with the light.
The extension input may only be operated
with the same phase as the radio.
Connecng an external cord aerial
The rear-side connecon for the external
aerial may only be used to connect the cord
aerial, art. no. RAD-ANT. Connecon to roof
aerials of shared aerial systems is not
permied.
To connect the cord aerial, remove the
jumper. Make sure to store the jumper for
later use of the radio without cord aerial.
Insert the aerial in the lower connecon.
Using the AUX input
The AUX input is used to connect external
sources, e.g. the music centre MC..100… .
Within the device box, all the cables carrying
low voltages (including the oponal cord
aerial) must have an insulang hose, in
order to guarantee secure isolaon.
The AUX input is selected using the
Favourites buon or in the menu.
Connecng a loudspeaker
The radio is designed for operaon with one
or two LSM... loudspeaker modules. The
connecon cable can be up to 5 m long.
Within the device box, all the cables carrying
low voltages must have an insulang hose,
in order to guarantee secure isolaon.
In normal stereo operaon, both outputs
(L+R) are used. If necessary, the receiver
switches to mono operaon automacally.
In the case of manual switch-over to mono
operaon (2 x mono), the radio can also be
used with just one loudspeaker.
The connecon of mulple loudspeakers to
each output is not permied.
Third-party loudspeakers may only be used
if their technical data is idencal to the Jung
LSM... .
Please observe the polarity.
Mounng of the power supply unit
Aer connecon of all the cables, mount the
power supply unit in the device box in the
right posion.
Mounng of the display unit
Aer the power supply unit has been
mounted in the device box, aach the
display cover, including the frame, to the
power supply unit in the right posion.
First commissioning
Switch the device on using the buon.
During rst commissioning, the 8 strongest
staons are saved automacally.
If necessary, adjust the sengs for the
loudspeakers and brightnesses.
Normally the brief recepon of an RDS
staon is sucient to set the me and date
automacally. Otherwise, the me can also
be set manually.
Technical data
Radio RAD…
Rated voltage: AC 230 V ~
Frequency: 50/60 Hz
Ambient temperature: 0 …+ 50 °C
Humidity: 15 % … 90 %
No dew formaon
Frequency range: 87.50 MHz … 108.00 MHz
Protecon rang: IP 20
Connecon: Screw terminals
1 x 2.5 mm² or 1 x 1.5 mm²
Loudspeaker connecon cable:
Twin-core cable H03VH-H, 2 x 0.75
alternavely:
-(St)- Y 2x2x0.6 mm JY
Length: max: 5 m
Loudspeaker LSM…
Rated power: 2.5 W
Impedance: 4 Ω
Frequency range: 120 ... 15000 Hz (-10 dB)
AUX input:
Impedance: 470 Ω
Input level: 1 V

Produkt Specifikationer

Mærke: JUNG
Kategori: Radio
Model: RADLS908

Har du brug for hjælp?

Hvis du har brug for hjælp til JUNG RADLS908 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Radio JUNG Manualer

JUNG

JUNG RANCDM514 Manual

15 August 2024
JUNG

JUNG DAB A WW Manual

9 August 2024
JUNG

JUNG DAB A2 WW Manual

4 August 2024
JUNG

JUNG R AN AC M 514 SW Manual

3 August 2024
JUNG

JUNG DABA2BTWW Manual

2 August 2024
JUNG

JUNG DAB LS2 Manual

1 August 2024
JUNG

JUNG RADA528 Manual

31 Juli 2024
JUNG

JUNG DAB A1 WW Manual

30 Juli 2024
JUNG

JUNG DAB AL1 Manual

28 Juli 2024
JUNG

JUNG DABLS2BT Manual

24 Juli 2024

Radio Manualer

Nyeste Radio Manualer

OXX Digital

OXX Digital Tube Internet Radio Manual

13 September 2025
Sangean

Sangean SG-100 Manual

12 September 2025
Hama

Hama 00054254 Manual

12 September 2025
Flex

Flex RD 10.8/18.0/230 Manual

12 September 2025
Makita

Makita DMR057 Manual

11 September 2025
Blow

Blow RA8 Manual

10 September 2025
Blow

Blow RA3 Manual

9 September 2025
Blow

Blow RK5 Manual

9 September 2025
Blow

Blow RA10 Manual

9 September 2025
Blow

Blow RK3 Manual

9 September 2025
