Congratulations and thank you for choosing our Inverter
air conditioner. We are sure you will find your new air
conditioner a pleasure to use. Before you use the air
conditioner, we recommend that you read through
the entire user manual, which provides the description
of the air conditioner and its functions.
To avoid the risks that are always present when you use an
electrical appliance, it is important that the air conditioner
is installed correctly and that you read the safety instructions
carefully to avoid misuse and hazards.
We recommend that you keep this instruction booklet
for future reference and pass it on to any future owners.
After unpacking the air conditioner please check it is not
damaged. If in doubt, do not use the air conditioner but
contact your local Electrolux Customer Care Centre.
Meanings of symbols used in this manual are shown below:
warning
This symbol indicates information concerning your
personal safety
caution
This symbol indicates information on how to avoid
damaging the appliance
tips and information
This symbol indicates tips and information about
use of the appliance
This symbol indicates tips and information about
economical and ecological use of the appliance
This symbol indicates never to do this
This symbol indicates always do this
Important safety instructions ........................................... 3
Notice for installation ....................................................... 3
Minimum floor areas ......................................................... 4
Components ...................................................................... 4
Product description .......................................................... 5
Installation checklist .......................................................... 6
Installation site instructions .............................................. 7
Rooftop installation .......................................................... 8
Outdoor unit installation................................................... 9
Indoor unit installation .................................................... 10
Installation ....................................................................... 20
Testing the air conditioner .............................................. 24
Post installation checks ................................................... 25
Warranty .......................................................................... 27
Congratulations Contents
2 Contents Kelvinator Air Conditioning
