Safety Precaution Information1
CAUTION
WARNING
1. This appliances is not intended for use by person (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
2.
3. It is recommended to examine the fan suspension system for at least once in every years.
4. Do not attempt to repair fan. Always return fan to our authorised service agent for repair.
5. Safety wire & mounting hook must be able to withstand 10 times the weight of ceiling fan.
(Product net weight: 5.2kg)
6. That the mounting of the suspension system shall be performed by the manufacturer, its
service agent or suitably qualified person.
7. To reduce the risk of injury to person, install fan at least 2.5m(8.3ft) above the ground and
1 meter from the nearest wall.
8. This appliance must be earthed.
9. Do not use any other down rod expect provided by KHIND. This is to ensure good
performance and extra protection.
1. Ceiling Fan must be mounted above 2.5m from the floor and 1m from the wall to the Blade.
Avoid fixing inside the dome ceiling.
2. Ensure Downrod has been fully tigthen to Motor Shaft.
(Bold tightening torque is 800~1000 N.cm)
Can cause injury if ceiling fan drops.
3. R Cotter Pin must fix into Bolt as shown. Can cause injury if
Ceiling Fan drops.
10. The double poles single throw switch must have a contact separation of at least 3mm must
be incorporated in the fixed wiring.
11. Disconnect power supply before dismantling any part for cleaning.
12. For household use only, not intended for any business purposes.
13. Do not use in hot or wet environment or near to flammable materials.
14. The wires in these power supply leads are coloured in accordance with the following
codes. (Green/Yellow-Earth(E), Blue-Neutral(N), Brown-Live(L).
15. If the power supply lead is damaged, it must be replaced by an authorized service agent
or the manufacturer to avoid any hazard.
R Cotter Pin
Ceiling
More than 2.5m More than 1m
WARNING
If unusual oscillating movement is observed, immediately stop using
the fan and contact the manufacturer, its service agent or suitably
qualified persons.
