2COMPVT SUBWOOFER
The Kicker CompVT subwoofers were specially designed for “Livin’ Loud” out in the harsh automotive
environment. CompVT subwoofers are versatile and surpass the competition in a sealed or vented box.
The ultra-thin mounting depth makes the CompVT subwoofers ideal for custom installations and space-
limited applications. They are made using advanced materials and construction techniques to maintain
optimal performance for years to come.
WIRING
S
The
whe
resp
amo
not
To m
sub
sub
dep
to c
of a
a 5
the
cou
fi t tig
insid
COMPVT SUBWOOFER Owner’s Manual
Authorized KICKER Dealer:
Purchase Date:
Speaker Model Number:
Speaker Serial Number:
Model CompVT CompVT8 10 CompVT12
Nominal Impedance [Zn], ohm [per coil] 2 or 4 2 or 4 2 or 4
Resonance Frequency [fs], Hz 49.2 32.7 32.7
Power Handling Watts, Peak (RMS) 400 (200) 800 (400) 800 (400)
Sensitivity [SPLo], dB @ 1W, 1m 84.8 87.2 87.1
Total Q-Factor [Qts] .565 .440 .518
Mechanical Q-Factor [Qms] 10.641 9.56 10.16
Electrical Q-Factor [Qes] .597 .461 .546
Effective Excursion [EXmax™] in (mm) .28 (7.1) .36 (9.2) .39 (9.8)
DC Resistance [Re], ohm 2.15 2.13 2.16
Equivalent Volume [Vas], ft3 (L) .364 (10.32) 1.3 (37.14) 2.15 (61)
Net Displacement, in3 (cc) 30.4 (497) 48.2 (790) 52.4 (860)
Outer Frame Dimension, in (cm) 8 1/2 (21.6) 10-11/16 (27.1) 12-5/8 (32)
Mounting Depth, in (cm) 3-7/16 (8.73) 4-1/4 (10.8) 4-3/8 (11.1))
Hole Cut-Out Diameter, in (cm) 7-1/16 (17.8) 9-3/16 (23.3) 11 (28.1)
Co
Co
Co
M
Co
Co
Co
CompVT CompVT CompVT8 / 10 / 12
Models:
SPECIFICATIONS
Se
Note: All specifi cations and performance fi gures are subject to change. Please visit www.kicker.com for the most
current information. To get the best performance from your new KICKER Subwoofer, we recommend using genuine
KICKER Accessories and Wiring. Please allow two weeks of break-in time for the subwoofer to reach optimum
performance.
Figure 1
Series Wiring
Parallel Wiring
Two 2 Woofers = 4 Load
Two 4 Woofers = 8 Load
Two 2 Woofers = 1 Load
Two 4 Woofers = 2 Load
