Kidde CV3106 Manual

Kidde Røgalarm CV3106

Læs gratis den danske manual til Kidde CV3106 (2 sider) i kategorien Røgalarm. Denne vejledning er vurderet som hjælpsom af 2 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 1.5 anmeldelser. Har du et spørgsmål om Kidde CV3106, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

2. THE BEST AREAS TO INSTALL THE HEAT

ALARM:

• Kitchen area

• Garage or workshop

Additional alarms increase the security.

3. NOT AREAS WHERE TO INSTALL HEAT-

ALARMS:

• In rooms where the temperature goes outside

-10ºC to +50ºC.

• Bedrooms

• Lounge

• Dining room

• Hallway

• Family room

NOTE: In areas where smoldering res occur

over aming res, photoelectric smoke alarms

are still the best to be installed.

4. PLACEMENT:

The heat alarm is design to be installed on a ceiling

or wall. Do not install to close to the oven/hob/

stove (see drawing).

For wall installation:

For celling installation:

5. INSTALLING THE HEAT ALARM:

Detach the alarm from the mounting base by

twisting counter clockwise.

MARK UP

SCREW HOLES

WITH A PEN

All alarms that need to be connected in the

house should be put into ‘Learn Mode’ by sliding

the switch on the back of the alarm to the ‘Learn

Mode’ position.

The red LED will light up to indicate that ‘Learn

Mode’ has been selected.

Please note that when the alarms are placed

in ‘Learn Mode’ they can’t be inserted into the

mounting base.

Press and hold the test button at one alarm only,

until it beeps and the LED ashes. This alarm will

become the master and will start sending out a

specic house code to the other alarms.

As the other alarms receive the specic house

code, they will also ash the LED light.

When the red LED light flashes on all alarms,

they are connected and MUST BE SWITCHED

OUT OF ‘LEARN MODE’and installed.

Label the original “Learn” alarm in order to easily

add new CAVIUS Wireless Family alarms to the

system.

Thermal heat alarm device

Model no.: 3106

This Thermal Heat Alarm is designed for areas not

suitable for smoke alarms due to high risk of false

alarms such as; kitchens, garages or workshops.

PLEASE READ THE INSTALLATION GUIDE

CAREFULLY BEFORE INSTALLATION AND

RETAIN FOR FUTURE USE.

SAFETY INSTRUCTIONS:

The device comes with a 3V lithium battery. Bat-

teries are to be handled with care and battery pow-

ered devices should be kept out of reach of chil-

dren. Do not try to recharge or burn the batteries.

TECHNICAL INFORMATION:

Cavius heat alarm detects:

1) rapidly increased temperature level

2) absolute heat level of 58 degrees C.

The maximum number of alarms that can be inter-

linked within a house group are 32.

Please note: These must be alarms from the CAVIUS

The distance between interlinked alarms depends

on the house layout and they should always be

tested after installation. It is not advised to get

more than 10m distance between two alarms.

Diameter: 78mm. Height: 42mm.

The alarm is powered by a non-replaceable 3v

CR123A lithium battery.

1. HOW TO SET UP AND CONNECT ALARMS:

Please note: The product label must not be

removed as it contains important information

regarding the product.

MOUNTING

BASE

TEST BUTTON

RED LED

THERMISTOR

Peak ceiling

Minimum 15cm

from peak

Minimum 15cm and

maximum 30cm from

ceiling

Wall

Ceiling

Minimum 30cm

and maximum 50cm

from stove

Ceiling

Minimum 30cm

from wall

Wall

Ceiling

LEARN MODE

NORMAL MODE

Heat

Siting of Heat alarms

Use the mounting base ring to mark the screw

holes on the ceiling or the wall.

Once the mounting base is installed, attach the

alarm by twisting clockwise until it clicks. If

the switch is in ‘Learn Mode’, the heat alarm will

not be able to click into the mounting base.

6. SAFETY LOCK:

7. TEST FUNCTION:

After installation, and at least once per quarter,

test all of your alarms to ensure they are operating

correctly and are within range of each other.

It is recommended to check visually every week if

the LED ashes correctly (every 48sec.)

Press the test button on any alarm for 2

sweeps of alarm signal. This will send out a

test signal from the alarm; all other connected

alarms should receive the signal within a short

time. The alarms will emit a short beep and the

LED will ash every 8 seconds for 2 minutes.

NOTE: Test function also allows to send a depleted

RF signal to ensure an optimal operation in normal

conditions.

When the test signal is sent out, the alarms will

respond in two ways:

1. A single beep every 8 seconds indicates that the

alarms are connected and functioning.

2. Three short beeps every 8 seconds indicates a

heat sensor fault.

If required this indication can be stopped early on

each alarm by a short press of the test button.

If the problem continues, please visit www.cavius.

com for any trouble shooting.

8. ADD EXTRA DEVICE:

All CAVIUS interconnected alarms within the

they run on the same frequency and use the same

data protocol.This means that the wireless system

can consist of a combination of smoke, heat etc.

Place all alarms into ‘Learn Mode’ and repeat

section 1.

Always test connection to all devices by repeating

test function section 7 after adding devices.

The alarm effected by the low battery will only

beep, no other connected alarms will sound.

9. OTHER INFORMATION:

Do not paint the alarm.

Disposal: Please dispose properly at the end of

life. This is electronic waste which should be re-

cycled.

The heat alarm is not suitable for use as a re

safety device unless it is part of a planned re

safety system, i.e. when interconnected to one or

more smoke alarm(s).

RF Frequency: 868 MHz.

Maximum radio-frequency power transmitted: 20

WARNING: All alarms should be assumed as due

to actual re and the dwelling should be evacuat-

ed immediately.

WARNING: To prevent injury, this apparatus must

be securely attached to the ceiling/wall in accor-

dance with the installation instructions.

WARNING: Batteries shall not be exposed to ex-

cessive heat such as shine, re, or the like.

Note the local country regulations regarding

installation.

Hereby, Carrier Fire & Security Danmark A/S de-

clares that the radio equipment type 3106 is in

compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is

available at the following internet address: www.

cavius.com

The CE mark afxed to this product conrms its

compliance with the European Directives which

apply to the product.

BSI Kitemark™ certied.

Carrier assumes no responsibility for any errors,

which may appear in this manual. Furthermore,

Carrier reserves the right to alter the hardware,

software, and/or specications detailed herein

at any time without notice, and Carrier does not

make any commitment to update the infor mation

served. All trademarks and service marks re-

ferred herein are property of their respective

owners.

Manufacturer: Carrier Fire & Security Danmark A/S,

Ellekær 9A, 2. Th, DK-2730. Made in China.

400147 rev7

CLICK THE HEAT ALARM

FIRMLY INTO THE BASE

TO LOCK

HEAT ALARM

SM ALARMOKE

M N REDAI S POWE

SM ALARMOKE

M N REDAI S POWE

HEAT ALARM

USE THE

ENCLOSED

SCREWS AND

PLUGS

MOUNT THE

SAFETY LOCK

BS 5446-2:2003

Class A1

KM 737251
