Side 1/2
Adam Hall GmbH · Adam-Hall-Str. 1 · 61267 Neu-Anspach · Germany
Tel.: (+49) 60 81 / 94 19 0 · Fax: (+49) 60 81 / 94 19 1000 · eMail: mail@adamhall.com
USER´S MANUAL
CURV 500® SECURITY KIT 2 (W)
SECURITY KIT FOR CURV 500 DUPLEX SATELLITES
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. During installation, observe the applicable safety regulations for your country.
7. Never place sources of ignition, e.g., burning candles, on the equipment.
8. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor equipment - in
this case, observe the special instructions noted below. Do not expose this equipment to flammable materials,
fluids or gases.
9. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with
liquids, such as vases or drinking vessels, on the equipment.
10. Make certain that objects cannot fall into the device.
11. Use this equipment only with the accessories recommended and intended by the manufacturer.
12. Do not open or modify this equipment.
13. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to tripping
hazards.
14. During transport, make certain that the equipment cannot fall down and possibly cause property damage
and personal injuries.
15. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or if
it has been damaged in another way, switch it off immediately and unplug it from the mains outlet (if it is a
powered device). This equipment may only be repaired by authorized, qualified personnel.
16. Clean the equipment using a dry cloth.
17. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.
18. Plastic bags must be kept out of reach of children.
CAUTION – HIGH VOLUME LEVELS WIT H AUDIO PRODUCTS!
This equipment is intended for professional use. Therefore, commercial use of this equipment is subject to the
respectively applicable national accident prevention rules and regulations. As a manufacturer, Adam Hall is ob-
ligated to notify you formally about the existence of potential health risks. Hearing damage due to high volume
and prolonged exposure: When in use, this product is capable of producing high sound-pressure levels (SPL) that
can lead to irreversible hearing damage in performers, employees, and audience members. For this reason, avoid
prolonged exposure to volumes in excess of 90 dB.
To prevent possible hearing damage, avoid listening at high volume levels over long periods of time.
Even exposure to short bursts of loud noise can result in hearing loss. Please keep the volume
constantly at a comfortable level.
MANUFACTURER’S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at: https://cdn-shop.adamhall.com/media/
pdf/Manufacturers-Declarations-LDSYSTEMS_DE_EN_ES_FR.pdf
To request warranty service for a product, please contact Adam Hall GmbH, Adam-Hall-Str. 1, 61267 Neu Anspach
/ Email Info@adamhall.com / 49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled waste disposal.
Please dispose of this product separately from other waste and have it recycled to promote sustainable economic activity.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an environmentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal
CE CONFORMITY
Adam Hall GmbH hereby confirm that this product meets the following guidelines (where applicable):
R&TTE (1999/5/EC) or RED (2014/53/EU) from June 2017 / Low-voltage directive (2014/35/EU)
EMC Directive (2014/30/EU) / RoHS (2011/65/EU) / The full declaration of conformity can be found at www.adam-
hall.com. You can also request it via info@adamhall.com
release button on the side of the satellite. Ensure that the two guide rails of the satellite properly slide into the grooves
of the SmartLink adapter in order to ensure a tight fit and establish a contact for both components. Now release the
button to lock the connection and to bring the button back to its original position. Proceed in the same manner as
described above to add other satellites. When disassembling, please proceed in reverse order.
SPECIFICATIONS
EN
DESCRIPTION
LDCURV500SECKIT2 securing kit for mechanical securing of up to three CURV 500 TS double satellites to the CURV
500 SmartLink adapter. The securing kit is available in both black and white.
COMPONENTS AND INSTALLATION
1
Base element with 90° angle for attaching the CURV 500 SmartLink adapter to the first double satellite in the array.
2
Two metal connecting elements for securing up to three CURV 500 TS double satellites.
3
Six M3 bolts with spring washers for connecting the components.
Remove the corresponding rubber foot on the underside of the SmartLink adapter (see No. 4) and firmly attach the
base element (No. 1) using the previously removed rubber foot or an M3 bolt and spring washer (supplied). Place a
connecting element with the offset side on the base element in such a way that the elongated holes of both elements
are located on top of each other (No. 5), and firmly attach both elements to the first double satellite in the array with
an M3 bolt and spring washer (supplied). Now secure the other double satellites in the array one after the other in the
same way (see No. 6). In order to avoid vibration noise, attach the connecting elements in the middle to the double
satellites (see No. 7). Check all components at regular intervals for completeness and firm grip!
Model name: LDCURV500SECKIT2(W)
Type: Installation Loudspeaker
Accessories
Material: Steel
Surface: Powder Coated
Colour: Black / white
Dimensions bracket base
(LxWxH):
73 x 20 x 2 mm (1x)
Dimensions safety strip
(LxWxH):
242 x 10 x 2 mm (2x)
Screw set: M3 x 10 mm screw + M3 spring
washer (6x)
Weight: 0.095 kg
1
2
3
4
6
7
5
