Side 1/14

Installation Guide

Quality, Design and Innovation

home.liebherr.com/fridge-manuals

Contents

1 General safety instructions................................... 2

2 Setup conditions.................................................... 2

2.1 Space....................................................................... 2

2.2 Setting up multiple appliances.................................. 2

2.3 Electrical connection................................................ 3

3 Appliance dimensions........................................... 3

4 Recess dimensions............................................... 4

4.1 Internal dimensions.................................................. 4

4.2 Ventilation requirements........................................... 4

5 Transporting the appliance................................... 5

6 Unpacking the appliance...................................... 5

7 Setting up the appliance....................................... 5

7.1 After setup................................................................ 5

8 Disposal of packaging........................................... 5

9 Explanatory symbols used................................... 5

10 Reversing the door................................................ 6

11 Fit the appliance into the recess.......................... 8

12 Connecting the appliance..................................... 13

The manufacturer is constantly working to improve all models.

Therefore please understand that we reserve the right to make

design, equipment and technical modifications.

To get to know all the benefits of your new appliance, please

read the information contained in these instructions carefully.

The instructions apply to several models, so there may be

differences. Sections which only apply to certain appliances

are indicated with an asterisk (*).

Instructions for action are marked with a , the results of

action are marked with a .

1 General safety instructions

-Only install, connect and dispose of the appli-

ance in accordance with the instructions.

-The socket must be easily accessible so that

the appliance can be disconnected from the

mains quickly in an emergency. It must not be

behind the back of the appliance.

DANGER indicates a hazardous situation,

which if not avoided, will result in

death or serious injury.

WARNING indicates a hazardous situation,

which if not avoided, could result in

death or serious injury.

CAUTION indicates a hazardous situation,

which if not avoided, will result in

minor or moderate injury.

NOTICE indicates a hazardous situation,

which if not avoided, could result in

damage to property.

Note indicates useful advice and tips.

2 Setup conditions

WARNING

Risk of fire due to moisture!

If live parts or the power cord get wet, this can cause a short

circuit.

u The appliance is designed for use in enclosed spaces. Do

not operate the appliance in open space or in damp areas or

where there is spray.

Normal use

-Only set up and use the appliance in enclosed spaces.

-Only use once installed.

2.1 Space

WARNING

Risk of fire due to refrigerant.

The refrigerant contained within the appliance is environmen-

tally friendly, but flammable. Leaking refrigerant can ignite.

uDo not damage the pipes of the refrigerant circuit.

- If the appliance is installed in a very damp environment

condensate water may form on the outside of the appliance.

Always make sure the installation area is well ventilated. .

-The more refrigerant is in the appliance, the larger the room

must be where the appliance is located. In the case of a

leak, a flammable gas-air mixture may be created in a room

that is too small. For every 8 g of refrigerant, the installation

space must be at least 1 m3 . Specifications regarding the

refrigerant contained within the appliance can be found on

the rating plate inside the appliance.

2.1.1 Installation surface

-The floor of the installation site must be horizontal and level.

- If the floor is not completely even, level the cabinet with

supports.

2.1.2 Installation position

- Do not install the appliance in direct sunlight or next to an

oven, heater, or similar heat source.

-Only install the appliance in solid cabinets.

2.2 Setting up multiple appliances

NOTICE

Risk of damage caused by water condensate!

u Do not install this device directly beside another fridge/

freezer compartment.

NOTICE

Risk of damage caused by water condensate!

uDo not stack the appliance directly on top of another.

These appliances are designed for different types of installa-

tion. Only combine appliances if the appliances are designed

for this. The following table shows the installation options by

model:

Setup type Model

Single All models

Side-by-Side

(SBS)

Model that start with .S...

See the SBS setup for positioning.

General safety instructions

2 * Depending on model and options

Produkt Specifikationer

Mærke:	Liebherr
Kategori:	Køleskab
Model:	ICSe 5103 Pure
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50-60 Hz
Bredde:	541 mm
Dybde:	545 mm
Højde:	1770 mm
Vægt:	54000 g
Produktfarve:	Hvid
Kontroltype:	Berøring
Lampe type:	LED
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	1.4 A
Pakkevægt:	58000 g
Pakkedybde:	622 mm
Pakkebredde:	555 mm
Pakkehøjde:	1829 mm
Årligt energiforbrug:	228 kWh
Placering af apparat:	Indbygget
Dørhængsel:	Højre
Installationsrum bredde:	570 mm
Installationsrum dybde:	550 mm
Installationsrum højde:	1778 mm
Tilsluttet belastning:	182.3 W
Støjniveau:	35 dB
Døråbningsvinkel:	115 °
Energieffektivitetsskala:	A til G
Luftfilter:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	E
Vendbare døre:	Ja
Fryser, netto rumindhold:	81 L
Frysekapacitet:	6 kg/24t
Opbevaringstid under strømafbrydelse:	11 t
Klimaklasse:	SN-T
Brugerdefineret panel klar:	Ingen
Køleskab antal hylder/kurve:	4
Antal grøntsagsskuffer:	1
Æggebakke:	Ja
Køleskabsdøre:	3
Køleskab, netto rumindhold:	183 L
Total netto kapacitet:	264 L
No Frost (køleskab):	Ingen
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Hylder, materiale:	Glas
Ismaskine:	Ingen
Multi-Airflow-system (køleskab):	Ja
Flaskeholder:	Ja
No Frost (fryser):	Ingen
Hurtig frys funktion:	Ingen
Fryser antal hylder/kurve:	3
Åben dør alarm:	Ja
Oprindelsesland:	Tyskland
Super Cool funktion:	Ingen
Feriefunktion:	Ingen
Indbygget kapacitet:	Ja
Automatisk afrimning (køleskab):	Ja
Temperaturalarm:	Ja
Minimal driftstemperatur:	10 °C
Maksimal driftstemperatur:	43 °C
Antal aftagelige hylder:	3
Justerbare hylder:	Ja
Antal æggebakker:	1
Dørmontering:	Dør glider
Antal døre:	2 dør(e)
Fryser, indvendigt lys:	Ingen
Kølesystem:	Dynamisk (blæserassisteret)
Toldproduktkode (TARIC):	8418108099
Smart Frost (fryser):	Ja
Smart Frost (køleskab):	Ja
Antal justerbare hylder:	3
Dørhylde materiale:	Stål
HarvestFresh-teknologi:	Ja
Super frysefunktion:	Ja
Liebherr-teknologier (opbevaring af fødevarer):	EasyFresh, PowerCooling, SuperCool, VarioSpace
