This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
2. Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
To assure continued operation, follow the attached
installation instructions and use only shield cables when
connecting to other devices. Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate the
B. Recharge and store the unit within the temperature
range of 5°C~35°(40°F~95°F).
C. Do not charge longer than 24 hours. Excessive charging
or running the unit until battery fully drains will damage
battery. Battery life will be extended if you keep the
D. Battery life naturally shortens slowly over time.
The rechargeable battery incorporated in this product is
Recharged the built in Li-ion battery as previously instructed.
2. Slide the Power Switch to position to power ON/OFF ON
on the unit. The Blue Indicator on the rear of unit will
3. Press and hold the Button repeatedly to switch to
desired playback mode. The unit will sound the prompt
with your selection (see list below):
4. During playback, press and holding the or Buttons
to adjust volume level as desired.
5. When finished listening, slide the POWER ON/OFF
Button to position to shut off the unit.OFF
In power on mode, press the Button to power on
Flashlight, press again to shut it off.
First time use or re-pairing the unit to a new BT Device, pair
1. Power on the unit and enter to BT mode as previously
instructed. The Blue Indicator on the rear of unit will
illuminate and blink. The unit also will sound a prompt
“Bluetooth ready for connection”.
2. Power on the external BT Device and enter to BT
searching mode. Start pairing following the on screen
instructions from the external BT Device. When paired，
the unit will sound a prompt “Bluetooth connected” and
the Blue Indicator will stop blinking.
3. If pairing is complete you may now play music and
answer calls with your external BT Device.
● Press the Button on the unit to pause, press again
to resume normal playback.
● Press and hold the or Buttons to adjust volume
● Press and release the or Buttons repeatedly to
5. If the unit is paired to a Cell Phone and a call is incoming
during an active music session, press the Button to
pause the music playback. Then speak to the built in
microphone to answer the call. When your call is
complete, press the Button to end the call and
resume to music playback.
1. When the external BT Device searched the unit, our
model number “MMA3626” will appear on the display of
2. If while pairing you are asked for a code please try "0000"
Normal operation after pairing:
1. Power on the external BT Device and enter to BT
2. Power on the unit and enter to BT mode as previously
instructed. The Blue Indicator on the rear of unit will
illuminate and blink. The unit also will sound a prompt
“Bluetooth ready for connection”.
3. Wait a few seconds until the unit is automatically paired to
the external BT Device. The unit will sound a prompt
“Bluetooth connected” and the BT Indicator will stop
4. After pairing is complete you may now play music and
answer calls with your external BT Device.
TF (Micro SD) Card Playback Mode:
To play the music in Micro SD Card:
1. In power off mode, insert the Micro SD Card (not
included) into the TF (Micro SD) Card Slot on the rear of
unit with contacts facing up as illustrated below:
2. Power on the unit and enter to TF (Micro SD) Card
mode as previously instructed. The unit also will sound
a prompt “Memory Card" then automatically play the
● Press the Button to pause, press again to resume
● Press the or Buttons repeatedly to skip tracks.
USB Device Playback Mode:
To play the music in USB Device:
1. In power off mode, insert the USB Device (not included)
into the USB Port on the rear of unit as illustrated
Power on the unit and enter the USB mode as
instructed. The unit will sound a prompt “USB”. then
automatically play the music in the it.
● Press the Button to pause, press again to resume
● Press the or Buttons repeatedly to skip tracks.
● Up to 8 GB Micro SD Card/USB Device the unit
● Before replacing Micro SD Card/USB Device, make sure
the unit has been powered off.
● When inserting the Micro SD Card/USB Device, make
sure the direction you selected is correct. Never insert
violently to avoid damaging the Micro SD Card/USB
● If it doesn’t work, please check if the direction is correct.
● You also need to download the desired music in MP3
format into the Micro SD Card/USB Device before insert
Check the following before requesting service:
1 x USB Connection Cable (For charge only)
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
7. Micro USB Port (For charge only)
8. TF (Micro SD) Card Slot
The unit has a built in Li-ion rechargeable battery, recharge it
before use or when the battery is drained as follows:
1. Connect the Micro USB Plug from the supplied USB
Connection Cable to the Micro USB Port on the rear of
2. Connect the full sized USB Plug from the supplied USB
Connection Cable to the USB Port on Computer or USB
Charger (Not included). Charging will automatically start.
● While charging, the Red Indicator on rear of unit will
● While charging, you can also play and listen music at
Your battery will last longer if you're following these simple
guidelines for charging and storing.
A. Before first time use (or recharge it when the battery is
drained), charge it approximately 3 hours.
Recharge the built-in battery as
Increase the volume level by
press and holding the Button
Rise the volume level of the
Reduce the volume level by
press and holding the Button
Reduce the volume level of the
Pair the external BT Device to
Place the external BT device
Built-in DC 3.7V, 400 mAH (1.48WH)
rechargeable Li-ion battery;
DC 5V through DC IN Jack (Micro USB Port)
1.5W per Channel (Total 3 W RMS）
Bluetooth ready for connection
Craig Electronics warrants this product to be free from
manufacturing defects in material and workmanship
under normal use for a period of 180 days from date of
purchase. If service is required, please return the product
to the store where it was purchased for exchange; or,
pack the unit in the original packing material with all
accessories if applicable, a copy of your sales receipt and
a Cashier’s check or Money Order for $12 (to cover
shipping and handling costs) payable to Craig Electronics
Inc. For consumers in Canada, please make sure that the
cashier check or money order is redeemable through a
U.S. bank. Ship your product freight pre-paid. Your unit
will be repaired, replaced or if the unit cannot be repaired
or replaced, a refund will be forwarded to you within four
weeks of receipt of your unit. Please ship your unit to:
This warranty is void if the product has been: a) Used in a
commercial application or rental. b) Damaged through
misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d)
Damaged because it is improperly connected to any other
Note: This warranty does not cover: a) Ordinary
adjustments as outlined in the Owner’s Manual which can
be performed by the customer. b) Damage to equipment
not properly connected to the product. c) Any cost
incurred in shipping the product for repair. d) Damage to
the product not used in the USA.
This warranty is not transferable and only applies to the
original purchase. Any implied warranties, including the
warranty of merchantability, are limited in duration to the
period of this expressed warranty and no warranty
whether expressed or implied shall apply to the product
Under no circumstance shall Craig be liable for any loss or
consequential damage arising out of the use of this
product. This warranty gives specific legal rights.
However, you may have other rights which may vary from
state to state. Some states do not allow limitations on
implied warranties or exclusion of consequential damage.
Therefore, these restrictions may not apply to you.
This product has been manufactured by and is sold under
the responsibility of Craig Electronics Inc, and Craig
Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMART. VERY SMART are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China MMA3626_WC_E0FK1_B0WU
